Product Outline for the Cisco C9300L-24P-4G-E 24 Ports Manageable Switch
The Cisco Catalyst 9300 Series is renowned for its high-performance switches designed to meet the demands of modern networks. The 9300L-24P-4G-E is a notable member of this series, equipped with features that cater to the evolving needs of businesses and organizations. These Catalyst 9300 Series support Power over Ethernet Plus (PoE+), a crucial feature that simplifies the deployment of devices like IP cameras and VoIP phones by providing both data and power over a single Ethernet cable.
24-Ports Fixed Uplinks
One of the primary highlights of the Cisco C9300L-24P-4G-E is its 24-Port Fixed Uplinks. These ports provide a reliable and consistent connection, allowing for seamless data transfer within the network. The fixed uplinks ensure stability and reduce the risk of connectivity issues, making the switch suitable for critical applications and high-throughput environments.
Power Over Ethernet Plus (PoE+)
Power Over Ethernet Plus (PoE+) is a critical feature for modern networking equipment, and the Cisco C9300L-24P-4G-E incorporates this capability. PoE+ enables the switch to deliver both data and electrical power over a single Ethernet cable, simplifying the deployment of devices such as IP cameras, phones, and access points. This not only reduces cable clutter but also enhances the flexibility of network design.
4X1G Uplinks
In addition to the fixed uplinks, the Cisco C9300L-24P-4G-E comes equipped with 4X1G uplinks. These additional uplinks offer increased bandwidth and flexibility in network configurations. Businesses can leverage these ports to connect to high-speed networks or aggregate multiple lower-speed connections, optimizing network performance.
Network Advantage
The inclusion of the Network Advantage feature further elevates the capabilities of the Cisco C9300L-24P-4G-E. Network Advantage is a Cisco DNA software package that provides advanced enterprise-class features. These features include enhanced security, automation, and assurance, ensuring that the switch is equipped to meet the evolving demands of modern networking infrastructures.
Layer 3 (L3) Supported
Layer 3 (L3) support is a crucial aspect of routers and switches in enterprise environments. The Cisco C9300L-24P-4G-E is designed with Layer 3 capabilities, enabling it to make routing decisions at the network layer. This feature is essential for creating scalable and efficient networks, allowing the switch to intelligently route traffic based on IP addresses and optimize overall network performance.
Modular Design
The modular design of the Cisco C9300L-24P-4G-E enhances its adaptability and scalability. The switch supports a variety of modules, allowing users to customize the switch based on specific requirements. This flexibility is particularly beneficial for businesses with evolving networking needs, as they can easily upgrade or expand the switch’s capabilities without the need for a complete hardware replacement.
Twisted Pair and Optical Fiber Connectivity
Connectivity options play a crucial role in networking equipment, and the Cisco C9300L-24P-4G-E offers versatile options with support for both Twisted Pair and Optical Fiber connectivity. Twisted Pair connections are commonly used for short-distance data transfer within a building, while Optical Fiber is preferred for longer-distance, high-bandwidth transmissions. The switch’s ability to accommodate both types of connections ensures compatibility with various networking scenarios.
Advanced Features for Catalyst Switch
The C9300L-24P-4G-E Cisco Catalyst 9300L is a 24-port managed switch in the Cisco Catalyst 9300L series. It is designed for use in enterprise networks and offers advanced features such as:
- Cisco DNA software: This software allows for advanced network automation and management capabilities, including network segmentation, device management, and analytics.
- Layer 3 routing: The switch supports advanced routing protocols, including OSPF and BGP, allowing for more efficient use of network resources and better traffic management.
- Security: The switch includes security features such as Cisco TrustSec for network segmentation, as well as support for 802.1X authentication and access control.
- Power over Ethernet Plus (PoE+): The switch supports PoE+ which allows for the delivery of both power and data to devices over a single Ethernet cable, making it useful for powering devices such as IP phones and wireless access points.
- StackWise-480 technology: This technology allows for the switch to be stacked with other switches in the Cisco Catalyst 9300L series, providing increased scalability and ease of management.
- 4x Gigabit Ethernet uplink ports: The switch has 4x Gigabit Ethernet uplink ports, which provide high-speed connectivity to other network devices.
- Quality of Service (QoS): The switch supports Quality of Service (QoS) which allows for prioritization of different types of traffic, such as voice or video, to ensure that critical applications receive the necessary bandwidth.
- Link Aggregation Control Protocol (LACP): This protocol allows for the bundling of multiple physical interfaces together to form a single logical interface, increasing the bandwidth and providing redundancy.
- Advanced Malware Protection (AMP): It helps to detect and prevent malware from entering the network by analyzing and blocking malicious files and traffic.
- Firewall policies: The switch supports firewall policies, which allow administrators to control traffic flow and protect against malicious activity.
Applications and Use Cases
Understanding the capabilities of the Cisco C9300L-24P-4G-E is essential for evaluating its suitability for different applications and use cases.
Enterprise Networking
In enterprise environments, the Cisco C9300L-24P-4G-E shines as a reliable and high-performance switch. The combination of fixed uplinks, PoE+ support, Layer 3 capabilities, and Network Advantage features makes it well-suited for the demands of large-scale networks. It can efficiently handle the diverse connectivity requirements of different departments, devices, and services within an organization.
IP Surveillance
The Power Over Ethernet Plus (PoE+) feature makes the Cisco C9300L-24P-4G-E an excellent choice for IP surveillance deployments. With the ability to deliver both power and data over a single cable, the switch simplifies the installation and management of IP cameras and other surveillance devices. The 24 fixed uplinks ensure a stable connection, making it ideal for surveillance applications where reliability is paramount.
Campus Networking
In campus networking scenarios, where a high density of devices needs to be connected, the Cisco C9300L-24P-4G-E’s 24 fixed uplinks and PoE+ capabilities prove invaluable. The switch can power and connect a multitude of devices, including laptops, smartphones, and access points, providing a robust and scalable solution for educational institutions, corporate campuses, and other large-scale deployments.
Data Center Connectivity
The modular design and support for Optical Fiber connectivity make the Cisco C9300L-24P-4G-E suitable for data center environments. Data centers often require high-speed, long-distance connections, and the switch’s ability to accommodate Optical Fiber ensures seamless connectivity for storage area networks (SANs), server clusters, and other data-intensive applications.
Scalability and High-Speed Connectivity
The C9300L-24P-4G-E Cisco Catalyst 9300L 24-port Managed Switch is designed to provide scalability and high-speed connectivity for enterprise networks. Some of the key features that support scalability and high-speed connectivity include:
- StackWise-480 technology: This technology allows for the switch to be stacked with other switches in the Cisco Catalyst 9300L series, providing increased scalability and ease of management. By stacking multiple switches together, the network can be expanded as needed without requiring additional cabling or management interfaces.
- 4x Gigabit Ethernet uplink ports: The switch has 4x Gigabit Ethernet uplink ports, which provide high-speed connectivity to other network devices. These ports allow for fast and reliable communication between devices on the network, such as servers, routers, and other switches.
- Fiber optic connectivity options: The switch supports fiber optic connectivity options, such as SFP and SFP+ modules, which provide high-speed and reliable communication over long distances. This is especially useful for connecting to remote locations or for use on large campuses.
- Quality of Service (QoS): The switch supports Quality of Service (QoS) which allows for the prioritization of different types of traffic, such as voice or video, to ensure that critical applications receive the necessary bandwidth.
- Link Aggregation Control Protocol (LACP): This protocol allows for the bundling of multiple physical interfaces together to form a single logical interface, increasing the bandwidth and providing redundancy.
General Information of the Cisco C9300L-24P-4G-E Ethernet Switch
- Manufacturer: Cisco
- Part Number or SKU# C9300L-24P-4G-E
- Product Line: Catalyst
- Product Series: 9300
- Product Type: Ethernet Switch
Technical Information
- Total Number of Network Ports: 24
- Uplink Port: Yes
- Modular: Yes
- Stack Port: Yes
- 24 x PoE+ (Power over Ethernet Plus)
- 4 x 10 Gigabit Ethernet Uplink
Performance
- Ethernet Technology: 10 Gigabit Ethernet
- Network Technology: 10GBase-X
I/O Expansions
- Number of Total Expansion Slots: 4
- Shared SFP Slot: No (Small Form-Factor Pluggable)
Network & Communication
- Layer Supported: 3
Management & Protocols
- Manageable: Yes
Power Description
- Power Source: Power Supply
- Redundant Power Supply Supported: Yes
In general, the Cisco C9300L-24P-4G-E Catalyst 9300 series switch stands as a testament to Cisco’s commitment to delivering cutting-edge networking solutions. Its combination of fixed uplinks, PoE+ support, 4X1G uplinks, Network Advantage features, Layer 3 support, and modular design with versatile connectivity options positions it as a versatile and powerful networking tool.
As businesses continue to embrace digital transformation and the demand for high-performance, secure, and scalable networks rises, the Cisco C9300L-24P-4G-E proves to be a valuable asset. Its applications span across various industries, including enterprise networking, IP surveillance, campus networking, and data center connectivity.
