Features and Benefits
The 459960-005 HP Proliant Dl360 G5 Server is a high-performance server designed for small and medium-sized businesses. It is equipped with two Intel Xeon Quad-Core E5420 processors with a clock speed of 2.5GHz, 4GB of RAM, and four Small Form Factor (SFF) drive bays. Here are some of the features and benefits of this server:
- High Performance: The two Intel Xeon Quad-Core E5420 processors with a clock speed of 2.5GHz provide high levels of performance for demanding applications such as database management, virtualization, and high-performance computing.
- Compact Form Factor: The server's compact form factor is ideal for businesses with limited space. It can be easily mounted in a rack or placed on a desktop.
- SFF Drive Bays: The server comes with four SFF drive bays that can accommodate up to four 2.5-inch hard drives or solid-state drives. This allows businesses to store and access large amounts of data easily.
- Network Connectivity: The server comes with two Gigabit Ethernet ports, providing high-speed connectivity for networked devices. It also supports a range of networking protocols, making it easy to integrate into existing network infrastructures.
- Management and Monitoring: The server comes with a range of management and monitoring tools, including Integrated Lights-Out (iLO) management, which enables remote management of the server through a web-based interface. It also supports HP Insight Control, which provides comprehensive management and monitoring capabilities for both physical and virtual servers.
- Security Features: The server comes with a range of security features, including BIOS security, Trusted Platform Module (TPM), and network security features such as support for VLANs, SSL encryption, and secure network boot. These features ensure the protection of sensitive data and prevent unauthorized access to the server.
- Operating System Compatibility: The server supports a range of operating systems, including Microsoft Windows Server, Red Hat Enterprise Linux, and VMware ESXi. This allows businesses to choose the operating system that best meets their needs and provides flexibility in deploying and managing the server.
- Scalability: The server's memory can be expanded up to 32GB, allowing for improved performance and responsiveness. It also has two expansion slots for additional storage or networking options.
- Cost-effective: The 459960-005 HP Proliant Dl360 G5 Server is an affordable solution for small and medium-sized businesses. It provides high-performance capabilities without breaking the bank.
Server Management and Monitoring Tools
The 459960-005 HP Proliant Dl360 G5 Server is equipped with a range of management and monitoring tools to ensure its optimal performance and reliability. Here are some of the server management and monitoring tools available with this server:
- Integrated Lights-Out (iLO): iLO is a web-based interface that provides remote management capabilities for the server. It allows administrators to monitor server health, access the server console remotely, and perform remote power management functions.
- HP Systems Insight Manager (SIM): SIM is a comprehensive management tool that provides centralized management and monitoring of multiple servers. It allows administrators to monitor server health, receive alerts, and perform system maintenance tasks.
- HP Insight Control: Insight Control is a suite of management tools that provides comprehensive management and monitoring capabilities for both physical and virtual servers. It includes features such as virtual machine management, server deployment, and proactive monitoring.
- HP Smart Update Manager (SUM): SUM is a tool that simplifies the firmware and driver update process. It allows administrators to update multiple servers at once, reducing downtime and ensuring that servers are running on the latest firmware and drivers.
- HP Systems Management Homepage (SMH): SMH is a web-based interface that provides a central location for monitoring server health and performing maintenance tasks. It provides detailed information on server hardware, system status, and performance data.
- HP Active Health System (AHS): AHS is a diagnostic tool that continuously monitors the server's hardware and system health. It provides detailed information on server health and identifies potential issues before they become critical.
- HP Insight Online: Insight Online is a cloud-based service that provides proactive monitoring and analysis of server health. It provides real-time alerts and notifications, allowing administrators to take corrective action before issues affect server performance.
The 459960-005 HP Proliant Dl360 G5 4sff - 2p Intel Xeon Quad-Core E5420/ 2.5GHz, 4GB Server is designed to provide a high level of security to protect critical business data and applications. Here are some of the security features of this server:
- Trusted Platform Module (TPM): The server is equipped with a TPM, a microchip that provides hardware-based security. The TPM is used to store cryptographic keys, passwords, and other sensitive data, providing an extra layer of protection against unauthorized access.
- Secure Boot: Secure Boot is a feature that ensures the server boots up only with trusted software. It verifies the integrity of the firmware, operating system, and other software components before they are loaded, preventing malware or other malicious software from loading during startup.
- Access Control: The server provides various access control mechanisms to restrict access to sensitive data and applications. Administrators can set up user accounts with different levels of access privileges, and authentication can be enforced using passwords, smart cards, or biometric authentication.
- Data Encryption: The server supports data encryption to protect data in transit and at rest. It supports various encryption technologies such as SSL, TLS, and IPsec to secure network communication, and it supports data-at-rest encryption using self-encrypting drives.
- Firewall and Intrusion Detection: The server is equipped with a firewall to block unauthorized access to the network. It also includes intrusion detection and prevention features that monitor network traffic and detect and prevent attacks.
- Physical Security: The server is designed to provide physical security features such as locking bezels and cable management arms. These features help prevent unauthorized access to the server hardware and protect against theft.
- BIOS Protection: The server's BIOS can be password-protected to prevent unauthorized access to the system settings. The BIOS also supports secure boot and other security features to protect against malware attacks.
General Information about this HP 459960-005
- Manufacturer: HP
- Part Number or SKU# 459960-005
- Product Type : Server
- Product Name : Proliant Dl360 G5 Server - 2-way 1u Rack Server ( Smart Buy)
Processor & Chipset of 2.5GHz 4-Core Server
- Cpu : Intel Xeon E5420 / 2.5 Ghz
- Number Of Cores : Quad-core
- Cpu Qty : 2
- Max Cpu Qty : 2
- 64-bit Computing : Yes
- Cpu Upgradability : Upgradable
- Cpu Socket : Lga771 Socket
- Chipset Type : Intel 5000p
- Front Side Bus : 1333 Mhz
- Type : L2 Cache
- Installed Size : 24 Mb
- Cache Per Processor : 12 Mb ( 2 X 4mb (4mb Per Core Pair)
Memory Information for Proliant Dl360 4GB Server
- Installed Size : 4 Gb / 64 Gb (max)
- Technology : Ddr2 Sdram - Advanced Ecc
- Effective Memory Speed : 667 Mhz
- Rated Memory Speed : 667 Mhz
- Memory Specification Compliance : Pc2-5300
- Form Factor : Fb-dimm 240-pin
- Slots : 8 (total) / 6 (empty)
- Features : Memory Mirroring, Fully Buffered, Online Spare Memory
- Configuration Features : 2 X 2 Gb
- Upgrade Rule : 2 Modules At A Time
- Type : 1 X Raid - Plug-in Card - Pcie X4
- Controller Interface Type : Sata 1.5gb/s / Sas
- Storage Controller Name : Smart Array P400i With 256mb Bbwc
- Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10
- Buffer Size : 256 Mb
- Type : 1 X Ide - Integrated
- Controller Interface Type : Ide/ata
Network & Communication
- Type : Integrated
- Interface (bus) Type : Pci Express X4
- Ethernet Ports : 2 X Gigabit Ethernet
- Ethernet Controller : Hp Nc373i
- Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Controller : Integrated Lights-out 2 Standard
- Features : Wake On Lan (wol), Acpi Support
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Expansions & Connectivity
- Expansion Bays Total (free) :
- 1 (total) / 0 (free) X External 5.25 Slim Line
- 4 (total) / 4 (free) X Hot-swap 2.5 Sff
Expansion Slots Total (free) :
- 2 (total) / 0 (free) X Cpu
- 8 (total) / 6 (free) X Fb-dimm 240-pin
- 1 (total) / 1 (free) X Pcie X8 - Low-profile
- 1 (total) / 1 (free) X Pcie X8 - Full-length, Full-height
Interfaces & Ports
- 1 X Ps/2 Keyboard
- 1 X Ps/2 Mouse
- 1 X Serial
- 1 X Vga
- 4 X Usb (1 Front, 2 Rear, 1 Internal)
- 2 X Lan (gigabit Ethernet)
- 1 X Hp Ilo
- Features : Administrator Password, Power-on Password, Keyboard Password, Disk Configuration Lock, Diskette I/o Control, Parallel Port I/o Control, Serial Port I/o Control
- Compliant Standards : Acpi 1.0b
- Device Type : Power Supply - Hot-plug
- Power Redundancy : Yes
- Power Redundancy Scheme : 1+1
- Installed Qty : 2
- Max Supported Qty : 2
- Nominal Voltage : Ac 120/230 V (50/60 Hz)
- Power Provided : 1000 Watt
