Description
Product overview of the HP 765538-L21
The HP Intel Xeon Six-Core E5-2609V3 processor is a high-performance computing solution designed to meet the needs of businesses and organizations with demanding workloads. This powerful processor features a clock speed of 1.9GHz and 15MB L3 Cache, and is designed to work with HP’s DL60 Gen9 server platform. In this article, we will discuss the specifications and features of this processor in detail.
Processor Specifications
The HP Intel Xeon Six-Core E5-2609V3 processor is built on Intel’s 22nm manufacturing process and is designed to fit into a Socket FCLGA2011-3 motherboard. This processor features six physical cores and can handle up to 12 threads thanks to Intel’s Hyper-Threading technology. It has a base clock speed of 1.9GHz and a maximum turbo frequency of 2.4GHz. This processor also features a thermal design power (TDP) of 85 watts, making it an efficient option for high-performance computing applications.
Cache Memory
The HP Intel Xeon Six-Core E5-2609V3 processor has a 15MB L3 Cache, which is a type of high-speed memory that is used to store frequently accessed data. The cache memory helps to reduce the latency of data access, resulting in faster computing performance. The 15MB L3 Cache is shared between all six cores of the processor, allowing for efficient data sharing and reducing the need for data transfers between different cores.
QPI Speed
The HP Intel Xeon Six-Core E5-2609V3 processor has a QPI (Quick Path Interconnect) speed of 6.4GT/s. The QPI speed is a measure of how fast the processor can communicate with other system components, such as memory and input/output devices. A faster QPI speed can result in better system performance, especially in applications that require frequent data transfers.
Processor Architecture
The HP Intel Xeon Six-Core E5-2609V3 processor is based on Intel’s Haswell architecture. This architecture features a number of improvements over previous architectures, including better performance, improved energy efficiency, and support for advanced features such as AVX2 (Advanced Vector Extensions 2). AVX2 is a set of instructions that can improve the performance of certain applications, especially those that involve heavy use of floating-point operations.
Server Compatibility
The HP Intel Xeon Six-Core E5-2609V3 processor is designed to work with HP’s DL60 Gen9 server platform. The DL60 Gen9 is a rack-mounted server that is designed for high-density computing environments. This server supports up to two Intel Xeon E5-2600 v3 series processors, making it an ideal choice for businesses and organizations that require high-performance computing capabilities.
Overall, the HP Intel Xeon Six-Core E5-2609V3 processor is a powerful computing solution that is designed to meet the demands of high-performance computing applications. It features six physical cores and a clock speed of 1.9GHz, along with a 15MB L3 Cache and a QPI speed of 6.4GT/s. This processor is based on Intel’s Haswell architecture and is designed to work with HP’s DL60 Gen9 server platform. It is an efficient and powerful option for businesses and organizations that require high-performance computing capabilities.
General Information
- Manufacturer: HP
- Product Type : Server Processor
- Model Number or SKU# 765538-L21
- Product Model : E5-2609V3
Technical Information
- Processor Core : Six-Core
- Quickpath Interconnect(Qpi) Speed : 6.4GT/S
- No Of Qpi Links: 2
- Instruction Set : 64-Bit
- Instruction Set Extensions : AVX
Cache Memory Detail
- L3 Cache : 15MB
- Lithography : 22 NM
- Max Thermal Design Power (Tdp) : 85W
- Compatible Processor Socket : FCLGA2011-3
