Understanding the Cisco C3850-NM-4-1G 4 Ports Expansion Module
The Cisco C3850-NM-4-1G is a Gigabit Ethernet Expansion Module designed for Catalyst 3850 switches. In this comprehensive guide, we’ll explore the features, applications, and benefits of this expansion module, translating technical details into simple and accessible language.
Overview: Cisco C3850-NM-4-1G Gigabit Ethernet Expansion ModuleExpansion Module for Catalyst 3850 Switches
The C3850-NM-4-1G is an expansion module specifically crafted for Cisco Catalyst 3850 switches. As an expansion module, its primary purpose is to enhance the capabilities of the Catalyst 3850 switch, providing additional Gigabit Ethernet connectivity options and expanding its overall functionality.
Gigabit Ethernet Speeds: 1 Gigabit Per Second (GBPS)
This expansion module operates at Gigabit Ethernet speeds, offering a data transfer rate of 1 Gigabit per second (GBPS). This high-speed capability is essential for handling data-intensive tasks and ensuring swift communication within the network.
4X1GE Ports: Enhanced Connectivity
Equipped with 4 ports, referred to as 4X1GE (4 ports supporting 1 Gigabit Ethernet), this expansion module significantly enhances the switch’s connectivity options. These ports can accommodate various devices, such as computers, servers, and other networking equipment, providing versatile connectivity within the network.
SFP (mini-GBIC) Compatibility: 4 Ports
The C3850-NM-4-1G features Small Form-Factor Pluggable (SFP) ports, also known as mini-GBIC ports. These ports offer flexibility by supporting different types of SFP transceivers, allowing for both copper and fiber optic connections. The module includes 4 SFP ports, providing a range of options for network expansion.
Expansion Slots: 4 x
With 4 expansion slots, this module allows for further customization and scalability. These slots enable the addition of more modules or interfaces as per the evolving needs of the network, ensuring adaptability to changing requirements.
Applications in Networking Environments
Increased Network Capacity
The C3850-NM-4-1G is instrumental in boosting network capacity by adding additional Gigabit Ethernet ports. This is particularly beneficial in scenarios where more devices need to be connected, supporting the growth and demands of the network.
Flexibility in Connectivity
The SFP ports provide flexibility in connectivity options. Whether it’s short-distance copper connections or longer-distance fiber optic links, the module caters to diverse networking needs, allowing for a mix of connection types within the same network.
Enhanced Data Transfer
With Gigabit Ethernet speeds, the expansion module facilitates enhanced data transfer capabilities. This is crucial for applications that require rapid data exchange, such as video streaming, large file transfers, and real-time communication within the network.
Key Features: Simplified
Gigabit Ethernet Speeds for Fast Data Transfer
Operating at 1 Gigabit per second, the C3850-NM-4-1G ensures high-speed data transfer, contributing to the overall efficiency of the network.
4X1GE Ports for Versatile Connectivity
The 4 ports supporting 1 Gigabit Ethernet each provide versatile connectivity options, accommodating various devices and networking equipment.
SFP Ports for Flexibility
The inclusion of 4 SFP ports allows for flexibility in choosing the type of connection, whether copper or fiber optic, based on the specific requirements of the network.
Expansion Slots for Scalability
With 4 expansion slots, the module supports scalability, enabling the addition of more modules or interfaces to meet the evolving needs of the network.
Performance of Expansion Module
The ExC3850-NM-4-1G is a network module that can be used to expand the connectivity and performance of a Cisco Catalyst 3850 series switch. It provides four additional 1 Gigabit Ethernet (1GE) uplink ports, allowing you to increase the number of available network connections and improve the overall performance of the switch.
Some of the key features of the ExC3850-NM-4-1G include:
- Four 1GE SFP uplink ports: These ports provide high-speed connectivity to other network devices, such as servers, storage systems, and other switches. The SFP ports can be configured with a variety of SFP transceivers, depending on the type of connectivity you need (e.g. fiber, copper).
- Enhanced performance: The ExC3850-NM-4-1G module is designed to work seamlessly with the Cisco Catalyst 3850 series switches, providing high-speed, low-latency connectivity to help improve the overall performance of the network.
- Advanced features: The module supports a range of advanced features, such as Quality of Service (QoS), link aggregation, and jumbo frames, to help optimize network performance and improve the user experience.
Reliability of Catalyst Network Module
The Cisco C3850-NM-4-1G is a network module for the Cisco Catalyst 3850 series switches that provides four Gigabit Ethernet ports for connecting to end devices. It is designed to be a reliable and high-performance networking solution for enterprise environments.
Some of the features that contribute to the reliability of the C3850-NM-4-1G include:
- High-quality components: The network module uses high-quality components that are designed to withstand the rigors of enterprise networking environments.
- Redundancy: The network module can be used in conjunction with other network modules and the switch’s built-in redundancy features to provide increased reliability and uptime.
- Quality of Service (QoS): The network module supports advanced QoS features that allow you to prioritize different types of network traffic, ensuring that mission-critical applications and services receive the necessary bandwidth and network resources.
- Enhanced security: The network module supports advanced security features that help protect against network threats and unauthorized access, improving the overall security and reliability of the network.
Multicast traffic management involves controlling the flow of multicast traffic within a network to optimize its performance and ensure that it reaches its intended destinations. Cisco Catalyst 3850 4X1GE Expansion Module (C3850-NM-4-1G) is a network expansion module that can be installed in the Cisco Catalyst 3850 series switches to increase their port capacity and enhance their capabilities.
Multicast Traffic Management
The C3850-NM-4-1G expansion module has four 1 Gigabit Ethernet (GE) ports, which can be used to connect devices and network segments to the switch. These ports can also be used to manage multicast traffic by configuring various multicast features and settings in the switch.
Some of the multicast features that can be configured on the Cisco Catalyst 3850 switch include:
- IGMP snooping: This feature allows the switch to listen in on IGMP messages exchanged between multicast routers and hosts. By doing so, the switch can determine which ports need to receive multicast traffic and which can be pruned to optimize bandwidth usage.
- PIM snooping: This feature allows the switch to snoop on Protocol Independent Multicast (PIM) messages exchanged between multicast routers. By doing so, the switch can determine which multicast streams need to be forwarded to which ports and can prune unnecessary streams to conserve bandwidth.
- IGMP filtering: This feature allows the switch to filter out unwanted multicast traffic by blocking IGMP messages from specific hosts or groups. This can help to reduce network congestion and improve performance.
- Multicast VLAN registration: This feature allows the switch to register multicast groups with specific VLANs. By doing so, the switch can limit the scope of multicast traffic to specific VLANs and reduce the amount of traffic that needs to be forwarded.
Main Specification about this Cisco C3850-NM-4-1G
- Manufacturer: Cisco
- Model Number or SKU# C3850-NM-4-1G
- Product Series: Catalyst 3850
- Product Type: Expansion Module
Technical Information for Network Module
- Total Number of Ports 4
- Port Speed: 10/100/1000
- Port Type: SFP
- MTBF: 7,052,100 Hours
- Application/Usage: Data Networking
- Application/Usage: Optical Network
I/O Expansions of Expansion Module
- Interface Provided: 4 – SFP (mini-GBIC)
- Compatible Slot 1 x expansion slot
Network & Communication
- Connectivity Technology: Wired
- Data Link Protocols: Gigabit Ethernet
- Data Transfer Rate: 1 GBPS
- Form Factor: Plug-in module
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Compatibility
- Cisco Catalyst 3850-12S-E
- Cisco Catalyst 3850-12S-S
- Cisco Catalyst 3850-12S-X
- Cisco Catalyst 3850-12X48U-E
- Cisco Catalyst 3850-12X48U-S
- Cisco Catalyst 3850-24P-BA
- Cisco Catalyst 3850-24P-E
- Cisco Catalyst 3850-24P-L
- Cisco Catalyst 3850-24P-S
- Cisco Catalyst 3850-24S-E
- Cisco Catalyst 3850-24S-S
- Cisco Catalyst 3850-24T-E
- Cisco Catalyst 3850-24T-L
- Cisco Catalyst 3850-24T-S
- Cisco Catalyst 3850-24U-E
- Cisco Catalyst 3850-24U-L
- Cisco Catalyst 3850-24U-S
- Cisco Catalyst 3850-24XU-E
- Cisco Catalyst 3850-24XU-S
- Cisco Catalyst 3850-48F-E
- Cisco Catalyst 3850-48F-L
- Cisco Catalyst 3850-48F-S
- Cisco Catalyst 3850-48P-E
- Cisco Catalyst 3850-48P-L
- Cisco Catalyst 3850-48P-S
- Cisco Catalyst 3850-48T-E
- Cisco Catalyst 3850-48T-L
- Cisco Catalyst 3850-48T-S
- Cisco Catalyst 3850-48U-E
- Cisco Catalyst 3850-48U-L
- Cisco Catalyst 3850-48U-S
These switches are compatible with a variety of software and hardware components, including:
- Cisco IOS XE 3.6.xE or later
- Cisco IOS XE 3.7.xE or later
- Cisco IOS XE 3.3.xSE or later
- Cisco IOS XE 3.4.xSE or later
- Cisco IOS XE 3.5.xE or later
- Cisco IOS XE 3.6.xSE or later
- Cisco IOS XE 3.7.xSE or later
- Cisco Catalyst 3850 Series StackWise-480 and StackPower cables
- Cisco Catalyst 3850 Series Network Modules
- Cisco Catalyst 3850 Series power supplies
In Summary, the Cisco C3850-NM-4-1G Gigabit Ethernet Expansion Module serves as a valuable enhancement for Catalyst 3850 switches, contributing to increased network capacity, flexibility in connectivity, and enhanced data transfer capabilities. Its Gigabit Ethernet speeds, 4X1GE ports, SFP compatibility, and expansion slots make it a versatile and adaptable solution for networking environments. This guide aimed to simplify the technical details, providing a clear understanding of the key features and applications of the C3850-NM-4-1G in simple and accessible language.
