Description
Introduction to the Switching Module
The DS-X9224-96K9 is a Cisco switching module that provides 24 ports of 8 Gbps Fibre Channel connectivity for use in data center environments. It is designed to provide high performance, low latency, and high availability for storage area network (SAN) deployments.
This switching module is compatible with Cisco MDS 9000 Series Multilayer Switches, including the Cisco MDS 9500 Series Multilayer Directors and the Cisco MDS 9200 Series Multiservice Switches. It supports a range of Fibre Channel protocols, including FC-AL, FC-GS, FC-PH, FC-PLDA, FC-SW, and FC-VI.
The DS-X9224-96K9 offers a range of advanced features to optimize Fibre Channel connectivity, including virtual SANs (VSANs), Fibre Channel over Ethernet (FCoE) support, and quality of service (QoS) features. It also includes redundant hot-swappable power supplies and fans to ensure high availability and uptime.
Diagnostic and Monitoring Tools
The DS-X9224-96K9 Cisco 24 Ports 8 Gbps Fibre Channel Switching Module provides several diagnostic and monitoring tools to help ensure optimal performance and diagnose issues. Here are some of the key tools:
- Show Commands: The switch provides several show commands that can be used to view the status of the switch, the ports, and the connected devices. Examples include “show interface brief”, “show port-channel summary”, “show zone status”, and “show flogi database”.
- Syslog: The switch can be configured to send syslog messages to a syslog server, which can be used to monitor the switch and identify any issues.
- SNMP: The switch supports Simple Network Management Protocol (SNMP), which allows for remote monitoring and management of the switch.
- Call Home: The switch can be configured to automatically send system and fault information to Cisco TAC (Technical Assistance Center) using the Call Home feature.
- Fabric Manager: The switch can be managed using Cisco Fabric Manager, which provides a graphical user interface (GUI) for configuring and monitoring the switch.
- Port Mirroring: The switch supports port mirroring, which allows traffic from one port to be copied to another port for analysis.
- Trace Route: The switch supports the trace route command, which can be used to diagnose network connectivity issues.
- SFP Diagnostics: The switch supports SFP (Small Form-factor Pluggable) diagnostics, which can be used to monitor the health of the SFP modules installed in the switch.
Features and Benefits
The DS-X9224-96K9 Cisco 24 Ports 8 Gbps Fibre Channel Switching Module offers a range of features and benefits that make it an excellent choice for SAN deployments in data center environments. Here are some of its key features and benefits:
- High Performance: The DS-X9224-96K9 supports 8 Gbps Fibre Channel connectivity, providing high-speed data transfer rates to meet the needs of demanding applications.
- High Availability: The switching module includes redundant hot-swappable power supplies and fans to ensure maximum uptime and availability. It also supports virtual SANs (VSANs) for better isolation and resiliency.
- Advanced Fibre Channel Features: The DS-X9224-96K9 supports a range of Fibre Channel protocols, including FC-AL, FC-GS, FC-PH, FC-PLDA, FC-SW, and FC-VI. It also supports Fibre Channel over Ethernet (FCoE) for unified storage and networking.
- Quality of Service (QoS) Features: The switching module includes QoS features to prioritize traffic and ensure that critical applications receive the bandwidth they need.
- Ease of Management: The DS-X9224-96K9 can be managed through Cisco Fabric Manager, a web-based management tool that simplifies configuration, monitoring, and troubleshooting.
- Investment Protection: The switching module is compatible with Cisco MDS 9000 Series Multilayer Switches, allowing customers to easily upgrade and expand their SANs as needed.
- Energy Efficiency: The DS-X9224-96K9 is designed for energy efficiency, with features such as power-saving mode, temperature sensors, and fan-speed control to reduce power consumption and extend the life of the hardware.
General Information
- Manufacturer Cisco
- MPN: DS-X9224-96K9
- Product Name 24 Port SFP (mini-GBIC) Module
- Product Type Expansion Module
Technical Information
- Application/Usage Data Networking
Performance
- Data Transfer Rate 8 Gbps Gigabit Ethernet
I/O Expansions
- Expansion Slots 24 x SFP (mini-GBIC)
Dimension and Weight
- Form Factor Hot-swappable
- Height 1.8 Inch
- Width 14.4Inch
- Depth 16 Inch
- Weight (Approximate) 10.25 Lbs
