Product Overview for the Cisco IE-3000-4TC-E 4 Ports Managed Switch
In the dynamic landscape of networking, the demand for reliable and efficient switches is paramount. The Cisco IE-3000-4TC-E, belonging to the Ethernet 3000 Series, stands out as a robust and versatile managed switch designed to meet the evolving needs of modern connectivity. This comprehensive guide explores the key features, benefits, and applications of the IE-3000-4TC-E, shedding light on how it can elevate your network infrastructure.
Understanding the Ethernet 3000 Series
The Ethernet 3000 Series by Cisco represents a family of switches engineered for industrial environments. These switches are built to withstand harsh conditions while delivering high-performance connectivity. The IE-3000-4TC-E, as a member of this series, inherits these traits and goes beyond to offer a tailored solution for various networking scenarios.
Key Features
- Port Configuration: The IE-3000-4TC-E is equipped with 4 ports, providing a balance between scalability and efficiency. These ports support Fast Ethernet (10/100 Mbps) connectivity, ensuring reliable data transfer for a wide range of applications.
- Managed Switch Capabilities: As a managed switch, the IE-3000-4TC-E offers advanced features for network administrators. It allows for greater control over the network, enabling tasks such as VLAN configuration, Quality of Service (QoS) implementation, and traffic monitoring.
- Industrial Design: Designed for industrial use, this switch is built to withstand challenging conditions. It is ruggedized to operate in extreme temperatures, making it suitable for deployment in manufacturing plants, outdoor installations, and other demanding environments.
- Security Protocols: Security is a top priority in networking, and the IE-3000-4TC-E doesn’t disappoint. It supports various security protocols, including IEEE 802.1X authentication, to ensure that only authorized devices can access the network.
- Redundancy Features: To enhance reliability, the switch incorporates redundancy features such as Rapid Spanning Tree Protocol (RSTP) and Dual Homing, ensuring seamless operation even in the event of a network failure.
Applications
- Industrial Automation: The industrial sector demands robust networking solutions, and the IE-3000-4TC-E fits the bill perfectly. Its rugged design and reliability make it an ideal choice for connecting automation devices in manufacturing plants.
- Critical Infrastructure: In scenarios where uninterrupted connectivity is crucial, such as in power distribution or transportation systems, the IE-3000-4TC-E plays a vital role. Its resilience to harsh conditions ensures continuous operation in critical infrastructure networks.
- Surveillance Systems: For video surveillance systems, a stable and high-bandwidth network is essential. The IE-3000-4TC-E’s managed capabilities, combined with its security features, make it a suitable choice for building robust surveillance networks.
- Smart Buildings: As buildings become smarter with IoT devices and automation, the need for reliable networking infrastructure grows. The IE-3000-4TC-E supports the demands of smart buildings, offering connectivity for a multitude of devices while maintaining network integrity.
Routing and Switching Protocols
The Cisco Industrial Ethernet 3000 (IE 3000) series managed switch, such as the IE-3000-4TC-E model, supports a variety of routing and switching protocols to help you build and manage your industrial network. Some of the routing and switching protocols supported by this switch include:
- Routing Information Protocol (RIP) and Open Shortest Path First (OSPF): These are Interior Gateway Protocols (IGPs) that are used to exchange routing information within a single autonomous system (AS).
- Border Gateway Protocol (BGP): BGP is an Exterior Gateway Protocol (EGP) that is used to exchange routing information between different autonomous systems.
- Virtual Router Redundancy Protocol (VRRP): VRRP is a protocol that allows for the automatic assignment of available virtual routers to clients.
- Link Aggregation Control Protocol (LACP): It allows you to bundle multiple physical ports together to form a single logical link, providing higher bandwidth and redundancy.
- Quality of Service (QoS): The switch supports various QoS features, such as traffic prioritization and rate limiting, which help ensure that critical industrial control and automation traffic are given priority over less critical traffic.
- Virtual LANs (VLANs): The switch supports VLANs, which allow you to segment your network into multiple virtual networks for better security and traffic management.
- IEEE 802.1X: The switch supports the IEEE 802.1X standard, which allows you to authenticate devices that connect to the switch using a RADIUS server.
- SNMP and Syslog: The switch supports SNMP and Syslog, which allow you to remotely manage and monitor the switch and receive alerts when certain events occur.
- DHCP: DHCP allows the assignment of IP addresses to devices dynamically, reducing administrative overhead.
- SSH and SSL: The switch supports SSH and SSL for secure remote management and monitoring of the switch.
- Flexible Netflow (FNF): It allows you to monitor and troubleshoot the network traffic and can be used for various purposes such as Network Accounting, Security, and Performance Monitoring.
- Cisco IOS software security features: These include features like Secure boot, Cryptographic hardware acceleration, Control plane protection, and so on.
Quality of Service (QoS) Capabilities
The IE-3000-4TC-E Cisco Industrial Ethernet 3000 Series 4 Ports Managed Switch offers Quality of Service (QoS) capabilities for optimizing network performance. The QoS features include:
- Class of Service (CoS): Assigns a priority level to network traffic based on its CoS value, allowing for prioritization of critical traffic over non-critical traffic.
- Traffic Shaping: Regulates the flow of network traffic to ensure that bandwidth-intensive applications do not consume too much bandwidth, causing other important applications to suffer.
- Traffic Policing: Controls the rate of incoming traffic to prevent network congestion, ensuring reliable performance for mission-critical applications.
- Queuing: Provides multiple queues for network traffic, allowing for efficient and fair distribution of available bandwidth.
- 802.1p prioritization: Supports 802.1p priority tagging, allowing network administrators to assign priority levels to different types of network traffic.
These QoS features provide the flexibility and control needed to manage network traffic and ensure reliable performance for critical applications in industrial environments.
General Information about this Cisco IE-3000-4TC-E
- Manufacturer: Cisco
- Part Number or SKU# IE-3000-4TC-E
- Product Series: 3000
- Product Name: 3000-4TC Industrial Ethernet Switch
- Product Type: Ethernet Switch
Interfaces / Ports of Ethernet Switch
- Total Number of Network Ports: 4
- Number of Network (RJ-45) Ports: 6
- Port/Expansion Slot Details: 4 x Fast Ethernet Network
- Port/Expansion Slot Details: 2 x Gigabit Ethernet Network
- Port/Expansion Slot Details: 2 x Gigabit Ethernet Expansion Slot
Performance for SFP Managed Switch
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 10/100/1000Base-T
- Network Technology: 10/100Base-TX
I/O Expansions of 6 Ports Switch
- Number of Total Expansion Slots: 6
- Expansion Slot Type: SFP
- Shared SFP Slot: Yes
- Number of SFP Slots: 2
Network & Communication
- Form Factor: DIN rail mountable
- Remote Management Protocol: HTTP, HTTPS, SNMP 1, SNMP 2, SNMP 3, SSH-2, Telnet
- Compliant Standards: IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x
- Status Indicators: Port status, System
- Ports Qty: 4
- Routing Protocol: BGP-4, EIGRP, EIGRP for IPv6, HSRP, IGRP, IS-IS, OSPF, OSPF for IPv6, PIM-DM, PIM-SM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng
- MAC Address Table Size: 8K entries
- Subcategory: Network hubs and switches
- Advanced Switching: Layer 3
- Manageable: Yes
- Jumbo Frame Support: 9018 bytes
Environmental Parameters
- Min Operating Temperature: -40 °F
- Max Operating Temperature: 140 °F
- Humidity Range Operating: 5 – 95% (non-condensing)
- Min Storage Temperature: -40 °F
- Max Storage Temperature: 185 °F
Features
- Access Control List (ACL) support, Broadcast Storm Control, DHCP snooping, Dynamic ARP Inspection (DAI), IGMP snooping, MAC address filtering, Multicast Storm Control, PROFINET v2, Quality of Service (QoS), Spanning Tree Protocol (STP) support, Unicast Storm Control, Virtual Route Forwarding-Lite (VRF-Lite), VLAN support
Memory
- Standard Memory: 128 MB
- Memory Technology: DRAM
- Flash Memory: 64 MB
Power Description
- Power Source: Power Supply
Miscellaneous
- Rack Mounting Kit: Optional
- Compliant Standards: ANATEL, AS/NZS 3548 Class A, BSMI CNS 13438 Class A, C-Tick, CB, China RoHS, CISPR 11, CISPR 22, CISPR 24, CSA, CSA 22.2 No. 142, CSA C22.2 No. 60950-1, Directive 2011/65/EU, EN 50121-3-2, EN 50121-4, EN 60945, EN 60950-1, EN 61000-4-10, EN 61000-4-11, EN 61000-4-16, EN 61000-4-17, EN 61000-4-18, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61326-1, EN50155, EN55022, EN55024, FCC Part 15 A, IEC 60533, IEC 60950-1, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-16, IEC 61000-4-17, IEC 61000-4-18, IEC 61000-4-2, IEC 61000-4-29, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IEC 61850-3, IP20, KCC, KN22 Class A, KN24, NEMA TS-2, NOM, RoHS, TUV GS, UL, UL 508, UL 60950-1, VCCI Class A
In general, the Cisco IE-3000-4TC-E is a powerhouse in the realm of managed switches. Its industrial design, advanced features, and application versatility make it a reliable choice for a spectrum of networking needs. Whether it’s supporting industrial automation, securing critical infrastructure, facilitating surveillance systems, or empowering smart buildings, this switch proves its mettle. Consider the IE-3000-4TC-E if you’re seeking a robust and scalable solution to propel your network into the future.
