Product Details of Cisco UCS-CPU-E52698E
The UCS-CPU-E52698E is a powerful processor manufactured by Cisco and Intel. It belongs to the Intel Xeon E5-2600 v4 product family, which is designed for use in data center applications. The processor has a 20-core configuration and a base clock speed of 2.2GHz. It also features a 50MB L3 cache and a QPI speed of 9.6GT/s. The processor is compatible with Socket FCLGA2011 and has a thermal design power of 135W. In this article, we will discuss in detail the specifications and features of the UCS-CPU-E52698E processor.
Processor Architecture
The UCS-CPU-E52698E processor is based on the Broadwell-EP microarchitecture, which is the successor to the Haswell-EP microarchitecture. It is manufactured using a 14nm process, which allows for better energy efficiency and higher clock speeds. The processor has a total of 20 cores, each with a base clock speed of 2.2GHz. The processor also supports Intel Hyper-Threading Technology, which allows for up to 40 threads to be executed simultaneously. This makes the processor ideal for applications that require a high degree of parallelism.
Cache and Memory
The UCS-CPU-E52698E processor has a 50MB L3 cache, which is shared between all the cores. This helps to improve performance by reducing the amount of time it takes for the processor to access frequently used data. The processor also supports DDR4 memory with a maximum capacity of 1.5TB. The memory operates at a speed of 2400MHz, which is the maximum speed supported by the processor. The memory is divided into four channels, each of which can support up to three DIMMs.
Thermal Design Power
The thermal design power (TDP) of the UCS-CPU-E52698E processor is 135W. This is the maximum amount of power that the processor can dissipate while operating at its base clock speed. The TDP is an important consideration when selecting a processor for use in a data center environment. A processor with a higher TDP will require more cooling, which can increase the overall energy consumption of the data center.
QPI Speed
The UCS-CPU-E52698E processor features a QPI speed of 9.6GT/s. QPI stands for QuickPath Interconnect, which is a high-speed interconnect technology developed by Intel. QPI is used to connect processors to each other and to other components in a computer system, such as memory and I/O controllers. A higher QPI speed means that data can be transferred between components more quickly, which can improve overall system performance.
Socket Compatibility
The UCS-CPU-E52698E processor is compatible with Socket FCLGA2011, which is a socket used for Intel Xeon E5-2600 v4 processors. The socket has a pin count of 2011 and supports quad-channel DDR4 memory. It is important to ensure that the processor and socket are compatible before installing the processor in a computer system.
General Information
- Manufacturer: Cisco
- Part Number or SKU# UCS-CPU-E52698E
- Product Model: E5-2698V4
- Product Type : Processor
Technical Information
- Processor Core : 20-Core
- Clock Speed : 2.2GHz
- Max Turbo Frequency : 3.6GHz
- Quick path Interconnect(QPI) Speed : 9.6GT/S
- No Of QPI Links: 2
- Instruction Set : 64-Bit
- Instruction Set Extensions : AVX 2.0
- L3 Cache : 50mb
- Lithography : 14nm
- MAX Thermal Design Power TDP:135W
- Compatible Processor Socket :FCLGA2011
