Description
Product Overview of the Cisco WS-C2960X-24PD-L
The Cisco WS-C2960X-24PD-L is a powerful member of the Catalyst 2960-X Series, renowned for its advanced features and reliability. In this detailed explanation, we will explore the various aspects of this 24-port Layer 2 switch. From its manageable configuration to its rack-mountable design and Small Form-Factor Pluggable Plus (SFP+) expansion slots, we’ll delve into the specifications, features, and applications that make this switch a valuable asset in networking.
The Cisco WS-C2960X-24PD-L belongs to the Catalyst 2960-X Series, a family of switches designed to deliver enhanced performance, efficiency, and security in network operations. With 24 manageable ports, a Layer 2 operating mode, and Small Form-Factor Pluggable Plus (SFP+) expansion slots, this switch is well-suited for various networking scenarios.
Technical Specifications
Port Configuration: 24 Ports
The WS-C2960X-24PD-L is equipped with 24 ports, providing ample connectivity options for devices within a network. This extensive port configuration makes it suitable for both small and medium-sized enterprises, allowing for the efficient connection of computers, printers, and other networked devices.
Manageability: Layer 2
Operating at Layer 2 of the OSI model, this switch efficiently handles data movement within the local network. Layer 2 switches are integral to creating a bridged network and ensuring seamless communication between devices. The manageable configuration enhances control over network settings and facilitates optimized performance.
Expansion Slots: 2x Small Form-Factor Pluggable Plus (SFP+)
Featuring 2 Small Form-Factor Pluggable Plus (SFP+) expansion slots, the WS-C2960X-24PD-L provides additional flexibility in connectivity options. These slots support SFP+ modules, enabling high-speed data transfer over fiber optic cables and extending the reach of the network.
Features of Cisco WS-C2960X-24PD-L
Enhanced Network Performance
With 24 ports supporting Gigabit Ethernet speeds, the WS-C2960X-24PD-L ensures high-performance data transfer within the network. This feature is particularly crucial in scenarios where large volumes of data need to be transmitted quickly, contributing to an efficient and responsive network.
Layer 2 Functionality for Local Data Movement
The Layer 2 functionality of the switch facilitates the movement of data within the local network. This enhances network performance by efficiently directing traffic between connected devices, ensuring that data reaches its destination promptly.
Rack-Mountable Design for Space Optimization
The 1U rack-mountable design is a space-saving feature that makes the WS-C2960X-24PD-L suitable for data center environments. Efficient use of rack space is essential for organizations with a multitude of networking equipment, and this switch’s design addresses this need.
SFP+ Expansion Slots for High-Speed Connectivity
The inclusion of 2 SFP+ expansion slots adds versatility to the switch’s connectivity options. These slots support SFP+ modules, allowing for high-speed data transfer over fiber optic cables. This is advantageous for scenarios where long-distance, high-speed connectivity is required.
Applications of Cisco WS-C2960X-24PD-LEnterprise Networks
The WS-C2960X-24PD-L is well-suited for enterprise networks where reliability and performance are paramount. Its 24-port configuration ensures connectivity for a variety of devices within an organization, contributing to the seamless flow of information and supporting the productivity of employees.
Data Centers
In data center environments, where space optimization and high-speed data transfer are critical, the WS-C2960X-24PD-L excels. Its rack-mountable design allows for efficient use of space in server racks, and the high-performance Gigabit Ethernet ports support the demands of data-intensive applications.
High-Performance Computing (HPC) Environments
High-Performance Computing (HPC) environments, characterized by the need for rapid data processing, benefit from the switch’s enhanced network performance. The SFP+ expansion slots provide options for high-speed connectivity, meeting the demands of HPC applications.
Fiber Optic Connectivity Scenarios
The inclusion of SFP+ expansion slots makes the switch suitable for scenarios where fiber optic connectivity is preferred or required. This is common in situations where long-distance connections are necessary, such as connecting buildings in a campus network or establishing connections between data centers
Power Over Ethernet (PoE) Capabilities
The WS-C2960X-24PD-L Cisco Catalyst 2960-X Series 10 Gigabits Ethernet 24-Ports PoE Manageable Layer 2 Ethernet Switch has several Power over Ethernet (PoE) capabilities that allow it to provide power to connected devices over the Ethernet cable.
- PoE support: The switch supports the IEEE 802.3af and 802.3at PoE standards, which allows it to provide power to devices such as IP phones, wireless access points, and security cameras.
- PoE Power Budget: The switch has a PoE power budget of 370W, which allows it to provide power to connected devices while preventing overloading the switch’s power supply.
- PoE+ Support: The switch also supports the IEEE 802.3at PoE Plus standard which provides up to 30W of power per port, providing more power to devices such as IP cameras and Access points.
- Power inline with Data: The switch also supports inline power to the connected devices, which allows the switch to provide power and data over the same cable.
- PoE Management: The switch also has a web interface that allows you to manage and monitor the PoE power usage of the connected devices.
- PoE redundancy: The switch also supports a redundant power supply, which allows you to install a second power supply as a backup in case the primary power supply fails. This can help ensure that the switch continues to operate even in the event of a power failure.
- Power redundancy with stack: The switch also supports stack power, where if one switch in the stack fails the other switches take over to provide power to the stack, this way the stack is never without power.
The PoE capabilities of the WS-C2960X-24PD-L Cisco Catalyst 2960-X Series 24-Ports PoE Manageable Layer 2 Ethernet Switch allow it to provide power to connected devices over the Ethernet cable, eliminating the need for additional power sources and making it a cost-effective solution for powering PoE-enabled devices.
Switching Capacity and Bandwidth
The WS-C2960X-24PD-L Cisco Catalyst 2960-X Series 24-Ports PoE Manageable Layer 2 Ethernet Switch has a switching capacity of 176 Gbps and a maximum forwarding rate of 130.95 Mbps. This means that the switch is able to handle a high volume of traffic and forward packets quickly.
In terms of bandwidth, each port on the switch supports a maximum of 10/100/1000Mbps with auto-negotiation. This allows the switch to support high-bandwidth applications and services, such as video streaming and large file transfers.
Additionally, the switch supports Link Aggregation Control Protocol (LACP) which allows you to bundle multiple physical ports together to increase bandwidth. This allows you to increase the available bandwidth on the switch to support high-bandwidth applications and services.
The switch also supports Quality of Service (QoS) which allows you to prioritize certain types of traffic, such as voice and video, over less critical traffic. This can help ensure that important traffic is delivered in a timely manner and does not get bogged down by less important traffic.
The switch also supports jumbo frames of up to 9216 bytes which allows for larger packets to be transmitted on the network, this is useful for certain applications such as video conferencing, large file transfer, etc.
General Information about this Cisco WS-C2960X-24PD-L
- Manufacturer: Cisco
- Model Number or SKU# WS-C2960X-24PD-L
- Product Line: Catalyst
- Product Series: 2960-X
- Product Type: Ethernet Switch
Interfaces/Ports for 24 Ports Ethernet Switch
- Total Number of Network Ports 24
- Number of PoE (RJ-45) Ports 24
- Port/Expansion Slot Details 2 x10 Gigabit Ethernet Expansion Slot
- Port/Expansion Slot Details 24 x Gigabit Ethernet Network
Performance of Catalyst 2960-X Managed Switch
- Media Type Supported Twisted Pair
- Ethernet Technology 10 Gigabit Ethernet
- Ethernet Technology Gigabit Ethernet
- Network Technology 10/100/1000Base-T
I/O Expansions for 10 Gigabit Ethernet Switch
- Number of Total Expansion Slots: 2
- Expansion Slot Type: SFP+
Network & Communication
- Layer Supported: 2
Management & Protocols
- Manageable: Yes
Power Description
- PoE (RJ-45) Port: Yes
- Input Voltage: 110 V AC
- Input Voltage: 220 V AC
Miscellaneous
- Green Compliant Yes
- Green Compliance Certificate/Authority RoHS
In summary, the Cisco WS-C2960X-24PD-L Catalyst 2960-X Series switch stands out as a reliable and versatile solution for various networking environments. Its 24-port configuration, Layer 2 functionality, rack-mountable design, and SFP+ expansion slots make it a valuable asset for enterprise networks, data centers, and scenarios requiring high-speed fiber optic connectivity. The switch’s focus on enhanced performance, manageability, and flexibility positions it as a key component for building and maintaining efficient and responsive networks. As technology evolves, the WS-C2960X-24PD-L continues to be a trusted choice for meeting the evolving demands of modern networking.
