Description
Additional Features
Additional Feature of 664693-001 HP 32GB 1X32GB 1333MHz PC3-10600 ECC DDR3 SDRAM is Error Correction Code (ECC) memory. ECC memory is a type of memory that can detect and correct errors that occur during data transfer. This is done by adding extra bits to each memory cell, which are used to detect and correct errors. This feature is especially important in environments where data integrity is critical, such as servers, workstations, and other mission-critical systems. ECC memory can detect and correct single-bit errors and detect multi-bit errors. This feature helps to prevent data corruption and system crashes, ensuring that your system runs smoothly and reliably. Additionally, ECC memory increases the reliability and uptime of the systems by detecting and correcting memory errors before they can cause system crashes or data corruption. This feature is particularly useful for environments where data integrity is critical and downtime is not an option
Memory Type and Form Factor
The memory type of the 664693-001 HP 32GB 1X32GB 1333MHz PC3-10600 ECC DDR3 SDRAM is DDR3 SDRAM (Double Data Rate 3 Synchronous Dynamic Random Access Memory). DDR3 is a type of memory that is commonly used in computers and servers. It is known for its high speed and low power consumption, which makes it ideal for use in systems that require a lot of memory and demand high performance.
The form factor of the 664693-001 HP 32GB 1X32GB 1333MHz PC3-10600 ECC DDR3 SDRAM is a DIMM (Dual In-line Memory Module). A DIMM is a type of memory module that is typically used in desktop computers and servers. It has a rectangular shape and a number of pins on the bottom that are inserted into the memory slot on the motherboard. DIMMs come in different capacities and speeds, and are designed to be easily installed and removed for upgrades or repairs.
Installation Instructions
Installation instructions for the 664693-001 HP 32GB 1x32GB 1333MHz PC3-10600 ECC DDR3 SDRAM RAM module would include steps for physically installing the module into a compatible system. The instructions would typically include the following steps:
- Power off the computer and unplug it from the power source.
- Remove the computer’s cover.
- Locate the memory slots on the motherboard.
- Determine the number of available memory slots and the type of memory already installed in the system.
- Carefully align the notches on the memory module with the notches on the memory slot.
- Gently press the module into the slot at a 45-degree angle, making sure it is fully seated.
- Carefully press down on the memory module until the tabs on either side of the slot lock into place.
- Replace the computer’s cover and plug it back in.
- Power on the computer and check the amount of memory installed in the system
- Make sure to check the motherboard manual for any specific instructions for your system.
It’s important to note that it’s best practice to ground yourself and handle the memory with care to avoid any potential damage to the component.
General Information
- Brand Name HP
- MPN: 664693-001
- Type: Memory (RAM)
- RAM Type: PC3-10600
- Product Name: 32GB DDR3 SDRAM Memory Module
- Option Part Number: 647903-B21
- SKU: 664693-001
- Assembly Number: 647654-081
Technical Information
- Storage Capacity: 32GB
- Memory Technology: DDR3 SDRAM
- Chips Organization: X4
- Number Of Modules: 1 X 32GB
- Bus Speed: 1333mhz DDR3-1333/PC3-10600
- Data Integrity Check: Ecc
- Registered Or Buffered: Buffered
- Ram Features: Hp Smart Memory,Load-Reduced Dimm (Lrdimm),Low Voltage , Quad Rank
- Cas Latency Timings: Cl9
- Platform Support: HP Proliant Server
Physical Characteristics
- Dimensions (W X D X H) : 8.89 X 19.81 X 1.91 Cm (3.5 X 7.8 X 0.75 In)
- Weight: 0.45 Kg (1 Lb)
Compatibility
- Proprietary HP Proliant Server – Dl160 Gen8
- Proprietary HP Proliant Server – Dl360e Gen8
- Proprietary HP Proliant Server – Dl360p Gen8
- Proprietary HP Proliant Server – Dl380e Gen8
- Proprietary HP Proliant Server – Dl380p Gen8
- Proprietary HP Proliant Server – Dl560 Gen8
- Proprietary HP Proliant Server – Ml350p Gen8
- Proprietary HP Proliant Server – Bl420c Gen8
- Proprietary HP Proliant Server – Bl460c Gen8
- Proprietary HP Proliant Server – Bl660c Gen8
- Proprietary HP Proliant Server – Ws460c Gen8
