Description
Product Information of the J4169-69001 HP Jetdirect
The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server is a network interface card (NIC) that provides high-performance printing capabilities to HP printers. This internal print server is designed to work with a wide range of HP printers, allowing multiple users to access the printer over a network connection. In this article, we will provide an in-depth explanation of the J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server, its features, benefits, and how it works.
Features and Benefits
The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server comes with several features that make it an ideal choice for businesses and organizations that require fast and reliable network printing capabilities. Some of the key features of this print server include
- Compatibility: The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server is compatible with a wide range of HP printers, including LaserJet, DesignJet, and OfficeJet printers.
- Fast printing: This print server is designed to provide fast printing speeds, with data transfer rates of up to 100 Mbps.
- Ethernet connectivity: The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server comes with Ethernet connectivity, which allows multiple users to access the printer simultaneously over a network connection.
- Easy installation: Installing this print server is easy and straightforward, and it can be done without the need for any special tools or technical expertise.
- Security: The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server comes with built-in security features, including password protection and encryption, to ensure that confidential documents are protected.
How it Works
The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server works by connecting directly to the printer’s internal EIO slot. Once connected, the print server allows multiple users to access the printer simultaneously over a network connection. The print server acts as a bridge between the printer and the network, converting print jobs into network packets that can be transmitted over the network.
To use the J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server, you will need to connect it to a network using an Ethernet cable. Once connected, you can configure the print server using a web browser by entering its IP address in the browser’s address bar. From here, you can configure the print server’s settings, including its network settings, security settings, and other options.
Compatibility
The J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server is compatible with a wide range of HP printers, including LaserJet, DesignJet, and OfficeJet printers. To determine if your printer is compatible with this print server, you should check the printer’s documentation or contact HP support for assistance.
Installation
Installing the J4169-69001 HP Jetdirect 610n Ethernet 10/100base-Tx Internal Print Server is easy and straightforward. To install the print server, you will need to follow these steps:
- Turn off the printer and unplug it from the power source.
- Open the printer’s EIO slot cover and locate the EIO slot.
- Insert the print server into the EIO slot and secure it in place using the screws provided.
- Connect the print server to a network using an Ethernet cable.
- Turn on the printer and wait for it to initialize.
General Information
- Manufacture : HP
- Part Number or SKU# J4169-69001
- DeviceType: Print Server Internal
Networking
- Connectivity Technology : Wired
- Cabling Type : Ethernet 10Base-T, Ethernet 100Base-Tx
- Data Link Protocol : Ethernet, Fast Ethernet
- Data Transfer Rate : 100 MBPS
- Status Indicators : Port Transmission Speed
- Compliant Standards : IEEE 802.3, IEEE 802.3u
Expansion / Connectivity
- Interfaces : 1 X Network – Ethernet 10base-T/100Base-Tx – Rj-45 – 1
- Compatible Slots : 1 X Expansion Slot
