Description
More Specification about this HPE P11694-B21
The P11694-B21 HP Xeon 8-core Gold 6234 3.3GHz 24.75mb Cache 10.4GT/s Upi Speed Socket FCLGA3647 14nm 130w Processor is a high-performance CPU designed for use in servers and other data center applications. This processor is manufactured by HP and is part of their Xeon Gold product line, which is known for its high clock speeds, large cache sizes, and high core counts. In this article, we will provide a detailed overview of this processor, including its specifications, performance characteristics, and key features.
Specifications
The P11694-B21 HP Xeon 8-core Gold 6234 processor is built using 14nm manufacturing process technology and has a TDP (thermal design power) of 130 watts. It has 8 cores and 16 threads, which means it can execute up to 16 processes simultaneously. This processor has a base clock speed of 3.3GHz and a turbo boost frequency of up to 3.9GHz. The processor supports DDR4 memory and has a maximum memory speed of 2933MHz. The processor has a cache size of 24.75MB, which is shared between all 8 cores. It also has a UPI (Ultra Path Interconnect) speed of 10.4GT/s, which enables faster communication between CPUs and other components in a system.
Socket and Compatibility
The P11694-B21 HP Xeon 8-core Gold 6234 processor uses the FCLGA3647 socket, which is a high-end server socket that supports Intel Xeon Scalable Processors. This socket is designed to provide high performance and scalability, and it supports up to 6 memory channels and up to 768GB of memory. This socket is also compatible with other Xeon Scalable Processors, including the Xeon Platinum and Xeon Silver product lines.
Performance
The P11694-B21 HP Xeon 8-core Gold 6234 processor is designed for high-performance computing and is ideal for use in data centers, cloud computing environments, and other applications that require a lot of processing power. The processor’s high core count and large cache size make it well-suited for running multiple virtual machines or executing parallel workloads. The processor’s UPI speed also enables faster communication between CPUs, which can improve overall system performance.
Key Features
The P11694-B21 HP Xeon 8-core Gold 6234 processor has several key features that make it a popular choice for high-performance computing applications. Some of these features include:
- Turbo Boost Technology 2.0: This feature enables the processor to automatically increase its clock speed when necessary, which can improve performance in applications that require bursts of processing power.
- Hyper-Threading Technology: This feature enables the processor to execute up to 2 threads per core, which can improve performance in multi-threaded applications.
- Intel Virtualization Technology: This feature enables the processor to run multiple virtual machines simultaneously, which can improve efficiency and reduce costs in virtualized environments.
- Advanced Vector Extensions (AVX): This feature enables the processor to perform floating-point calculations at a faster rate, which can improve performance in scientific and engineering applications.
Finally, the P11694-B21 HP Xeon 8-core Gold 6234 3.3GHz 24.75mb Cache 10.4GT/s Upi Speed Socket FCLGA3647 14nm 130w Processor is a high-performance CPU designed for use in servers and other data center applications. Its high core count, large cache size, and UPI speed make it well-suited for running multiple virtual machines or executing parallel workloads.
Product Features
- product Manufacturer : HP
- Type: Processor
- Sub Type : Intel Xeon 8-core
- part number: P11694-B21
- product Model : Gold 6234
Technical Information
- Processor core : 8-core
- Clock speed : 3.30GHz
- Max turbo frequency : 4.00GHz
- Ultrapath interconnect(UPI) speed : 10.4GT/s
- No. Of upi links : 3
- Instruction set : 64-bit
- Instruction set extensions : intel® sse4.2, intel® avx, intel® avx2, intel® avx-512
Cache Memory Detail
- cache : 24.75MB
- Lithography : 14NM
- Max thermal design power (TDP) : 130W
- Compatible processor socket : FCLGA3647
- memory specifications :
- Max memory size (dependent on memory type) : 1TBGB
- Memory types : DDR4-2933
- Maximum memory speed : 2933MHz
- Max no. Of memory channels : 6
- Ecc memory supported : yes
