Description
Performance Benchmarks
The performance benchmarks for the HPE Proliant DL360p G8 server with the 733733-001 model number depend on the specific workload and configuration of the server. However, here are some general performance benchmarks based on the server’s specifications:
- Processor: The Intel Xeon E5-2630v2 hexa-core processor is capable of handling up to 12 threads and has a base clock speed of 2.6GHz, which can be boosted up to 3.1GHz with Intel Turbo Boost technology. This processor is designed for high-performance computing and can handle demanding workloads such as virtualization, database management, and scientific computing.
- Memory: The server comes with 16GB of DDR3 SDRAM, which is a decent amount of memory for most applications. However, this can be upgraded to up to 768GB using the 24 available DIMM slots. This allows the server to handle large databases or other memory-intensive workloads.
- Storage: The server supports up to 8 small form factor (SFF) SAS, SATA, or SSD hot-plug drives, which provide fast and reliable storage for demanding workloads. The Smart Array P420i RAID controller with 1GB FBWC ensures data protection and enhances performance.
- Network: The server features an embedded 4-port Gigabit Ethernet network adapter, which provides fast and reliable network connectivity.
Extended Support Services
HPE offers various extended support services for the HPE Proliant Dl360p G8 server, which can help customers maximize their investment and minimize downtime. These services include:
- HPE Foundation Care: This is a flexible, cost-effective support service that provides proactive and reactive support for HPE servers. It includes hardware and software support, access to HPE technical resources, and software updates.
- HPE Proactive Care: This service provides a personalized, proactive support experience that can help prevent issues before they occur. It includes all the features of HPE Foundation Care, as well as proactive monitoring, personalized reports, and a dedicated account manager.
- HPE Datacenter Care: This service provides comprehensive support for datacenter environments, including servers, storage, networking, and software. It includes a dedicated support team, proactive management, and customized reports.
- HPE Proactive Select: This service allows customers to choose from a menu of proactive services, including performance analysis, firmware management, and capacity planning. Customers can select the services that best meet their needs and budget.
- HPE Defective Media Retention: This optional service allows customers to keep any failed hard drives or other storage media, which can help protect sensitive data and intellectual property.
Expansion and Connectivity
The 733733-001 HPE Proliant Dl360p G8 server comes with a variety of expansion and connectivity options, including:
- Expansion slots: 2 PCIe 3.0 slots (x8, x16) for additional adapters
- Drive bays: 8 SFF hot-plug drive bays for SAS, SATA, or SSD drives
- Internal storage: up to 16TB of internal storage capacity with the addition of optional drive cages
- Network connectivity: 4x Gigabit Ethernet ports with TCP/IP offloading engine (TOE) support
- USB ports: 5 USB 2.0 ports (2 front, 2 rear, 1 internal) and 1 USB 3.0 port (rear)
- Serial ports: 1 serial port (rear)
- VGA port: 1 VGA port (rear)
- Optional HPE FlexibleLOM: provides a choice of 1GbE or 10GbE network connectivity or converged network adapter (CNA) for Fibre Channel over Ethernet (FCoE)
General Information
- Manufacturer : Hewlett Packard Enterprise(HPE)
- Manufacturer Part Number : 733733-001
- Type: Server
- Sub-Type: Proliant Dl360P
- Product Name : Proliant Dl360p G8 – 2-Way 1u Rack Server (Base Model)
Processor & Chipset
- Processor Type : Intel Xeon E5-2630v2 / 2.6 GHz
- Number Of Cores : 6-Core
- 64-Bit Computing : Yes
- Installed Qty : 1
- Max Supported Qty : 2
- Upgradability : Upgradable
- Chipset Type : Intel C600
Cache Memory
- Cache Memory Type : L3 Cache
- Installed Size : 15 Mb
- Cache Per Processor : 15 Mb
Memory
- Installed Size : 16 Gb
- Maximum Size : 384 Gb
- Technology : Ddr3 Sdram
- Form Factor : Dimm 240-Pin
- Configuration Features : 2 X 8 Gb
Ram Supported
- Pc3-14900 – 384 GB – Registered
- Pc3-14900 – 768 GB – Load-Reduced
- Pc3-14900 – 128 GB – Unbuffered – Advanced Ecc
Storage & Storage Controller
- Hard Drive : None
- Card Reader Type : Card Reader
- Supported Flash Memory Cards : Sd Memory Card
- Storage Controller Type : 1 X Raid – Integrated – Pci Express 3.0 X8
- Controller Interface Type : Sata 6gb/S / Sas 6gb/S
- Storage Controller Name : Smart Array P420i With 1gb Fbwc
- Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
- Buffer Size : 1 GB
Display & Graphics Controllers
- Graphics Controller Type : Integrated
- Graphics Processor : Matrox G200
- Video Interfaces : Vga
Network & Communication
- Networking : Plug-In Card Pci Express X4
- Ethernet Ports : 4 X Gigabit Ethernet
- Ethernet Controller(S) : Hp 331flr
- Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol : Ipmi 2.0, Smash Clp
- Remote Management Controller : Integrated Lights-Out 4
- Features : Wake On Lan (Wol), Pxe Support
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
