Description
8 Gigabit Ethernet Ports
8 Gigabit Ethernet ports refer to a number of Ethernet ports that support data transfer speeds of up to 1 Gbps (gigabit per second) on a network switch or router. These ports are designed to handle high-speed data transmissions and are commonly used in local area networks (LANs) to connect computers, servers, storage devices, and other networked devices.
Gigabit Ethernet is a faster version of the original Ethernet standard, which supported speeds of 10 Mbps (megabits per second). With the increasing demand for bandwidth-intensive applications such as video streaming and large file transfers, Gigabit Ethernet has become the standard for most modern networks. The 8 Gigabit Ethernet ports on a network switch or router provide a high-speed, reliable connection for multiple devices, allowing organizations to optimize their network performance and support their business needs.
Advanced Security Features
Advanced security features refer to the measures that protect a network from unauthorized access or attack. These features are designed to help secure the network and its connected devices, ensuring that sensitive data and systems are protected. Some common advanced security features found in network devices include:
- Access Control Lists (ACLs): restrict access to specific network resources based on rules defined by the administrator.
- Virtual Private Network (VPN) support: secure encrypted connections between remote users and the network.
- 802.1x Authentication: a port-based security standard that requires devices to provide proof of their identity before accessing the network.
- Firewall: monitors and filters incoming and outgoing network traffic based on security rules.
- Intrusion Detection and Prevention (IDP): detect and prevent potential security threats by analyzing network traffic for patterns that indicate an attack.
- Denial-of-Service (DoS) protection: prevent network overload and ensure network availability by blocking unauthorized or malicious network traffic.
- Encryption: secure sensitive data by encoding it before transmission.
Advanced security features help ensure that a network is protected from a wide range of security threats and allow administrators to set and enforce policies to maintain network security.
Configuration and Management
Configuration and management refer to the processes of setting up and maintaining a network device, such as a switch or router, to meet the needs of an organization’s network infrastructure. Configuration involves setting up various parameters, such as IP addresses, VLANs, and port configurations, that define how the device will operate within the network. Management involves the ongoing monitoring and maintenance of the device to ensure that it continues to operate correctly and efficiently.
In the context of JL681-61001, configuration and management can be performed through a web interface or through a command-line interface (CLI). The device can be accessed remotely over a network, allowing network administrators to make changes to its configuration as needed. The device may also support features such as firmware updates, backup and restore functions, and detailed logging and reporting.
Effective configuration and management of network devices is critical for ensuring the reliability, performance, and security of a network. By implementing these processes, organizations can proactively address potential issues and maintain a stable and efficient network environment.
General Information about the HPE JL681-61001
- Manufacturer: HPE
- Part Number or SKU# JL681-61001
- Type: Networking
- Switch Type : 8 Port Switch
Performance
- Ports: 8 X 10/100/1000 (poe+) + 2 X Gigabit Sfp
- Throughput: 14.88 Mpps ¦ Switching Capacity: 20 Gbps ¦ Latency (100 Mbps): 5.2 ?s ¦ Latency (1 Gbps): 3 ?s
- Capacity: Routing Table Entries (static): 32
- Mac Address Table Size: 8000 Entries
- Jumbo Frame Support: 9216 Bytes
- Routing Protocol: Igmpv2, Igmp, Static Ipv4 Routing, Mstp, Rstp, Stp
- Remote Management Protocol: Snmp, Rmon, Snmp 3, Snmp 2c, Http, Https, Tftp, Scp, Dhcp, Ipv4, Ipv6
Features
- Flow Control, Dhcp Support, Arp Support, Trunking, Vlan Support, Auto-uplink (auto Mdi/mdi-x), Igmp Snooping, Port Mirroring, Manageable, Ipv6 Support, Half Duplex Mode, Full Duplex Mode, Spanning Tree Protocol (stp) Support, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Jumbo Frames Support, Trusted Platform Module (tpm), Ipv4 Support, Lacp Support, Lldp Support, Link Aggregation Control Protocol (lacp), Class Of Service (cos), Snmp Support, 1.5mb Packet Buffer, Bridge Protocol Data Unit (bpdu), Lldp-med, Energy-efficient Ethernet (eee)
- Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1ab (lldp), Ieee 802.3at, Ieee 802.3az, Ieee 802.2af
Processor
- 1 X Arm Cortex-a9: 800 Mhz
- Ram: 512 Mb
- Flash Memory: 256 Mb
Expansion / Connectivity
- Interfaces
- 8 X 1000base-t Rj-45
- 2 X Gigabit Lan Sfp
Power
- Power Device: Internal Power Supply
- Power Provided: 150.2 Watt
- Power Over Ethernet (poe): poe+
- Poe Budget: 124 W
- Voltage Required: Ac 120/230 V (50/60 Hz)
