Description
Mixed Use SSD
The HPE P18430-K21 is a 7.68 terabyte (TB) solid state drive (SSD) that uses the Serial ATA (SATA) interface and connects to a computer through a 6 gigabits per second (GB/s) SATA interface. This SSD is designed for mixed use, which means it is optimized for both read-intensive and write-intensive workloads. The specific model has been introduced by HPE for use in their server and storage systems.
Mixed-use SSDs are typically used in environments where data is both read and written frequently, such as in data centers or enterprise storage systems. The SATA interface provides a cost-effective and widely supported storage option, it also allows for ease of integration and offers a large capacity storage solution that is compatible with many systems, it is widely adopted in data centers, enterprise storage, and can be used for a variety of workloads like databases, virtualization, and backups.
It is worth noting that SATA SSDs generally have lower performance and lower endurance compared to NVMe SSDs. So it would not be ideal for high-performance computing tasks such as gaming, video editing, and running large databases. It’s best to use in systems where capacity and compatibility are more important than high performance.
Smart Carrier
The Smart Carrier HPE P18430-K21 is a solid-state drive (SSD) produced by Hewlett Packard Enterprise (HPE). The drive has a storage capacity of 7.68 terabytes and uses the SATA III (6 Gbps) interface to connect to a host system. It is likely a enterprise level SSD with high-end feature like higher endurance, reliability and security
It is probably intended for use in data centers or other enterprise-level environments where high storage capacity and fast data transfer speeds are important.
Exceptional Reliability
The HPE P18430-K21 is a high-performance SSD designed for mixed-use workloads, meaning it is suitable for a wide range of applications that require a balance of performance and endurance.
One of its key features is its exceptional reliability, which is achieved through a combination of advanced technologies and rigorous testing. The drive is built to withstand the demands of a data center environment, and is designed to provide consistent performance even in the face of heavy workloads.
Other features that contribute to the exceptional reliability of the drive include the use of high-quality NAND flash memory, advanced error correction and data protection, and advanced wear leveling algorithms. Additionally, the drive undergoes extensive testing and validation to ensure it meets or exceeds industry standards for reliability.
The drive also supports advanced security features such as hardware-based encryption that helps to protect data and ensure compliance with security regulations.
General Information about this HPE P18430-K21
- Manufacturer: HPE
- Part Number or SKU# P18430-K21
- Device Type: Solid State Drive
- Spare Part Number: P18486-001
- Interface: SATA-6GBPS
Technical Information of 7.68TB Solid State Drive
- Capacity: 7.68 TB Storage
- Form Factor: 2.5 Inch SFF
- Plug Type: Hot Pluggable
- Connectivity: Single Port
- Carrier Type: Smart Carrier (SC)
- Workload Type: Read Intensive
- Features: Digitally Signed Firmware (DS)
- Bundled with: HPE Smart Carrier (SC)
- NAND Flash Memory Type: Triple-Level Cell (TLC)
- Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
- Height: 7.00 mm (0.3 inch)
Performance Information for SATA 6GBPS SSD
- 30 Days Writes: 9111
- Endurance DWPD (Drive Writes Per Day): 0.65
- Drive Transfer Rate: 6 Gb/sec (external)
- MAX Seq Reads Throughput (MiB/s): 505
- Max Seq Writes Throughput (MiB/s): 495
- Random Read Avg. Latency uSec (4KiB,Q1): 126
- Random Write Avg. Latency uSec (4KiB,Q1): 87
- Random Read IOPS (4KiB, Q=16): 67000
- Random Write IOPS (4KiB, Q=16): 11500
- Max Random Read IOPS (4KiB): 76000@Q32
- Max Random Write IOPS (4KiB): 11800@Q4
Dimensions & Weight for 2.5 Inch Solid State Drive
- Height: 0.63 inch
- Width: 3.10 inch
- Depth: 5.45 inch
- Weight: 1.50 lbs
Power Consumption
- Idle Time: 1.25 Watt
- Random Read: 2.01 Watt
- Random Write: 2.01 Watt
- Sequential Read: 2.26 Watt
- Sequential Write: 2.76 Watt
- Random Read/Write: 2.01 Watt
- Maximum: 2.76 Watt
Compatibility Information
- HPE Nimble Storage dHCI Medium Solution with HPE ProLiant DL325 Gen10 Plus (2.5inch), Medium Solution with HPE ProLiant DL360 Gen10 (2.5inch), Small Solution with HPE ProLiant DL360 Gen10 (2.5inch)
- HPE ProLiant DL Series: BL460c Gen10 (2.5inch), DL180 Gen10 (2.5inch), DL180 Gen10 Entry (2.5inch), DL325 Gen10 Base (2.5inch), DL325 Gen10 Plus (2.5inch), DL325 Gen10 Plus All-NVMe Flash Node for Qumulo (2.5inch), DL325 Gen10 Plus for Weka Expansion Tracking (2.5inch), DL325 Gen10 Solution (2.5inch), DL360 Gen10 (2.5inch), DL360 Gen10 All Flash Server for Weka (2.5inch), DL360 Gen10 Base (2.5inch), DL360 Gen10 Compute Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 Entry (2.5inch), DL360 Gen10 High Performance (2.5inch), DL360 Gen10 Low (2.5inch), DL360 Gen10 Network Choice (2.5inch), DL360 Gen10 Performance (2.5inch), DL360 Gen10 Performance for Cohesity DataPlatform (2.5inch), DL360 Gen10 SMB (2.5inch), DL360 Gen10 SMB Network Choice (2.5inch), DL360 Gen10 Solution (2.5inch), DL385 Gen10 Plus (2.5inch), DL385 Gen10 Plus Entry (2.5inch)
- HPE ProLiant ML Series: ML30 Gen10 (2.5inch), ML30 Gen10 Entry (2.5inch), ML30 Gen10 Performance (2.5inch), ML30 Gen10 Solution (2.5inch)
- HPE Synergy 480 Gen10 Plus Base Compute Module (2.5inch), 660 Gen10 Base Compute Module (2.5inch), 660 Gen10 Compute Module (2.5inch), 660 Gen10 Entry Compute Module (2.5inch), 660 Gen10 Performance Compute Module (2.5inch), 660 Gen10 Premium Compute Module (2.5inch)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
