Description
Facilities of Digitally Signed Hot Pluggable SSD
Digitally signed hot pluggable solid state drives, such as the HPE PCI-Express 1.92TB 2.5 inch Smart Carrier SFF, offer several important benefits for computer systems. These facilities include:
- Digital Signing: The digital signature ensures that the solid state drive is genuine and has not been tampered with. This enhances the security and reliability of the data stored on the drive.
- Hot Pluggability: This allows the drive to be easily and safely removed and replaced without shutting down the system. This feature makes it possible to upgrade or replace drives without disrupting normal system operations.
- PCI-Express: PCI-Express is a high-speed data transfer interface that allows for fast data transfer rates between the drive and the computer system.
- Large Storage Capacity: The 1.92TB storage capacity of the drive allows for a large amount of data to be stored, making it ideal for demanding applications such as high-performance databases, video editing, and scientific simulations.
- Small Form Factor: The 2.5 inch form factor of the drive is compact and allows for easy integration into small computer systems, making it ideal for use in server environments where space is limited.
The digitally signed hot pluggable solid state drive provides enhanced security, reliability, performance, and flexibility, making it a valuable addition to any computer system.
Monitoring and Troubleshooting
Monitoring and troubleshooting are essential tasks that are performed to ensure the health and performance of the HPE PCI-Express 1.92TB 2.5 inch Smart Carrier SFF Digitally Signed Hot Pluggable Solid State Drive (SSD).
Monitoring:
- The SSD can be monitored using various tools and software to check its health status and performance.
- The HPE System Management Homepage can be used to monitor the SSD’s temperature, firmware version, and health status.
- The SSD’s SMART attributes can be monitored using software tools such as CrystalDiskInfo, Hard Disk Sentinel, or HD Tune. These tools provide information about the SSD’s read/write performance, remaining life, and temperature.
Troubleshooting:
- If the SSD is not functioning properly, the following steps can be taken for troubleshooting:
- Check the firmware version and update it if necessary.
- Check the health status of the SSD using HPE System Management Homepage or other software tools.
- Check the connections and cables to make sure they are properly attached.
- If the SSD is still not functioning properly, it may need to be replaced.
In conclusion, monitoring and troubleshooting are important tasks that ensure the performance and health of the HPE PCI-Express 1.92TB 2.5 inch Smart Carrier SFF Digitally Signed Hot Pluggable SSD. By using various tools and software, the SSD’s status can be monitored and any issues can be addressed promptly.
Power Management of 1.92TB SSD
Power management is a feature that enables the HPE PCI-Express 1.92TB 2.5 inch Smart Carrier SFF Digitally Signed Hot Pluggable Solid State Drive to conserve energy and reduce power consumption when the drive is not in use. The power management feature uses a combination of hardware and software to monitor the activity of the drive and reduce power consumption when the drive is idle. This results in lower power consumption and reduced heat generation, which can prolong the lifespan of the drive and reduce the overall cost of ownership. The power management feature is also useful for data centers and other high-density storage environments, where power consumption and heat generation can be significant issues.
Main Information of HPE P20017-K21
- Brand Name: HPE
- Model Number or SKU # P20017-K21
- Device Type: Solid State Drive – Hot-Swap
- Capacity: 1.92TB
- Form Factor: 2.5 inch SFF
- Interface: NVMe U.3 PCIe
- NAND Flash Memory Type: Triple-Level Cell (TLC)
- Connectivity: Single Port
- Plug Type: Hot Pluggable
- Carrier Type: Smart Carrier NVMe (SCN)
- Workload Type: Read Intensive
- Features: Digitally Signed Firmware (DS), x4 Lanes
- Bundled with: HPE Smart Carrier NVMe (SCN)
- Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
- Height: 15.00 mm (0.60 inch)
Performance of HPE 1.92TB
- Lifetime Writes: 3424
- Endurance DWPD (Drive Writes Per Day): 1
- Drive Transfer Rate: PCIe NVMe (external)
- MAX Seq. Reads Throughput (MiB/s): 6500
- MAX Seq. Writes Throughput (MiB/s): 2700
- Random Read IOPS (4KiB, Q=16): 180000
- Random Write IOPS (4KiB, Q=16): 100000
- MAX Random Read IOPS (4KiB): 950000@Q256
- MAX Random Write IOPS (4KiB): 100000@Q128
Expansion & Connectivity of HPE PCI-E
- Interfaces: 1 x PCI-E NVMe
- Compatible Bay: 2.5 Inch SFF
Power Consumption
- Idle Time: 6.30 Watt
- Random Read: 15.10 Watt
- Random Write: 11.60 Watt
- Sequential Read: 14.00 Watt
- Sequential Write: 14.10 Watt
- Random Read/Write: 12.20 Watt
- Maximum: 15.10 Watt
Product Dimensions & Weight
- Height: 0.63 inch
- Width: 3.10 inch
- Depth: 5.45 inch
- Weight: 1.50 lbs
Compatibility Information of HPE PCI-E Read Intensive
Designed for
- HPE ProLiant DL Series: DL325 Gen10 (2.5 inch), DL325 Gen10 Base (2.5 inch), DL325 Gen10 Entry (2.5 inch), DL325 Gen10 Performance (2.5 inch), DL325 Gen10 SMB Solution (2.5 inch), DL325 Gen10 Solution (2.5 inch), DL360 Gen10 All Flash Server for Datera (2.5 inch), DL360 Gen10 Low (2.5 inch), DL360 Gen10 Network Choice (2.5 inch), DL360 Gen10 Network Choice for SAP HANA Compute Block (2.5 inch), DL360 Gen10 Premium (2.5 inch), DL360 Gen10 Remote Office Branch Office Server for Cohesity DataPlatform (2.5 inch), DL360 Gen10 Server for CTERA (2.5 inch), DL360 Gen10 SMB (2.5 inch), DL360 Gen10 SMB Network Choice (2.5 inch), DL360 Gen10 Solution (2.5 inch), DL360 Gen10 Special Server (2.5 inch), DL380 Gen10 All Flash Server for Datera (2.5 inch), DL380 Gen10 Entry SMB (2.5 inch), DL380 Gen10 for Cohesity DataPlatform (2.5 inch), DL380 Gen10 Hybrid Server for Datera (2.5 inch), DL380 Gen10 Network Choice (2.5 inch), DL380 Gen10 Network Choice for CTERA (2.5 inch), DL380 Gen10 Network Choice for SAP HANA Compute Block (2.5 inch), DL380 Gen10 NVMe All Flash Server for Datera (2.5 inch), DL380 Gen10 SMB (2.5 inch), DL380 Gen10 SMB Networking Choice (2.5 inch), DL380 Gen10 Solution (2.5 inch), DL385 Gen10 (2.5 inch), DL385 Gen10 Base (2.5 inch), DL385 Gen10 Entry (2.5 inch), DL385 Gen10 High-Performance (2.5 inch), DL385 Gen10 Performance (2.5 inch), DL385 Gen10 SMB (2.5 inch), DL385 Gen10 Solution (2.5 inch), DL580 Gen10 (2.5 inch), DL580 Gen10 Base (2.5 inch), DL580 Gen10 Entry (2.5 inch), DL580 Gen10 Performance (2.5 inch)
- HPE ProLiant ML Series: ML350 Gen10 (2.5 inch), ML350 Gen10 Base (2.5 inch), ML350 Gen10 Entry (2.5 inch), ML350 Gen10 High Performance (2.5 inch), ML350 Gen10 Performance (2.5 inch), ML350 Gen10 SMB (2.5 inch), ML350 Gen10 Solution (2.5 inch), ML350 Gen10 Special Server (2.5 inch), ML350 Gen10 Sub-Entry (2.5 inch)
- HPE Synergy Series: 480 Gen10 Compute Module (2.5 inch), 480 Gen10 Premium Backplane Compute Module (2.5 inch), 480 Gen10 Standard BackPlane Compute Module (2.5 inch), 480 Gen10 w/o Drives Compute Module (2.5 inch), 660 Gen10 Compute Block (2.5 inch), 660 Gen10 Compute Module (2.5 inch), 660 Gen10 Premium Compute Module (2.5 inch)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
