Description
Features and Benefits
The Lenovo ThinkSystem SD530 HW RAID Kit (4C57A16216) offers the following features and benefits:
Features:
- Supports Lenovo ThinkSystem SD530 Server
- Provides hardware RAID support for ThinkSystem SD530
- RAID levels supported: 0, 1, 5, 6, 10, 50, 60
- Easy to install and use with intuitive RAID management software
Benefits:
- Improves data reliability and security with hardware-based RAID protection
- Increases storage performance with RAID support
- Supports multiple RAID levels to meet different data protection and performance requirements
- Simple to manage with intuitive RAID management software.
Management and Monitoring
The Lenovo 4C57A16216 Thinksystem Sd530 HW Raid Kit can be managed and monitored using the following methods:
- BIOS setup: The BIOS setup allows you to configure the RAID settings, monitor the status of the RAID arrays, and perform basic management tasks.
- RAID controller software: The RAID controller software provides a graphical interface for managing and monitoring the RAID arrays. It allows you to create, delete, and manage RAID arrays, monitor the status of the arrays, and perform advanced management tasks.
- Server management software: The server management software provides a centralized platform for managing and monitoring the entire server, including the RAID arrays. It allows you to monitor the status of the server, perform maintenance tasks, and manage the RAID arrays from a single interface.
- SNMP: Simple Network Management Protocol (SNMP) allows you to monitor the RAID arrays remotely. You can use SNMP to receive alerts and notifications when there is a change in the status of the arrays.
- Email notifications: The RAID controller software can be configured to send email notifications when there is a change in the status of the arrays. This allows you to monitor the status of the arrays remotely and receive alerts in real-time.
Operating System Compatibility
The Lenovo 4C57A16216 Thinksystem Sd530 HW Raid Kit is compatible with the following operating systems:
- Windows Server 2019
- Windows Server 2016
- Windows Server 2012 R2
- Windows Server 2012
- Windows Server 2008 R2
- Windows 10
- Windows 8.1
- Windows 7
- Red Hat Enterprise Linux 7.x
- Red Hat Enterprise Linux 6
General Information about this Lenovo 4C57A16216
- Manufacturer: Lenovo
- Part Number or SKU# 4C57A16216
- Product Series: 530
- Product Type: SAS Controller
Technical Information for SAS Controller
- Form Factor: Plug-in Card
- Host Interface: PCI-E 3.0 x8
- Controller Type: SAS-12GBPS
- RAID Supported : Yes
- RAID Levels: 0, 1, 10, 5, 50, JBOD
- Device Supported: Server
- Memory
- Cache Memory No
Interfaces/Ports of Lenovo 6-Ports Controller
- Total Number of SAS Ports 6
- Number of SAS Ports (Internal) 6
- SAS Connector Details 2x SlimSAS x4
Miscellaneous
- Platform Supported: PC
- Environmentally Friendly: Yes
- Environmental Certification: WEEE, RoHS
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
