Description
Recommended System Requirements
The HPE 3.84TB SATA-6GBPS Read Optimized Solid State Drive (P23489-B21) is designed to work with systems that have the following recommended system requirements:
- SATA-6GBPS interface: The drive is designed to work with systems that have a SATA-6GBPS interface, which is the latest SATA interface that supports a maximum data transfer rate of 6 Gbps.
- Server hardware: The drive is recommended to be used with server hardware, as it is optimized for read-intensive workloads and high-availability environments.
- Operating system: The drive is compatible with various operating systems, including Windows, Linux, and VMware, among others.
- System memory: The drive may benefit from having sufficient system memory, as larger memory sizes can improve system performance and stability.
- Power supply: The drive requires a system with a stable power supply that meets the requirements of the drive and the system it is installed in.
It is important to note that these are the recommended system requirements, and the drive may still function properly in systems that do not meet these requirements. However, using the drive in a system that does not meet these requirements may result in reduced performance and stability.
Bulk Data Applications
The HPE 3.84TB SATA-6GBPS Read Optimized Solid State Drive (P23489-B21) is designed for bulk data applications that require fast read speeds and large storage capacities. This drive is optimized for read-intensive workloads such as content delivery, big data analytics, data warehousing, and backup and archive applications.
The drive’s high read performance and large storage capacity make it ideal for applications that require rapid access to large amounts of data. For example, in content delivery applications, the drive can store a large number of high-resolution video files and quickly serve them to clients over the internet. In big data analytics, the drive can store and quickly process large datasets to produce insights and predictions.
In backup and archive applications, the drive can store multiple versions of large files and quickly retrieve them as needed. This is important in industries such as media and entertainment where large amounts of data are generated and must be stored for later use.
Power Management of 3.84TB SSD
Power management refers to the process of controlling and optimizing the power consumption of a device, in this case, the HPE 3.84TB SATA-6GBPS Read Optimized Solid State Drive (P23489-B21). This process helps to reduce the power consumption of the drive, which in turn helps to reduce the overall energy consumption and costs.
The power management features of the drive may include power-saving modes that reduce the drive’s power consumption when it is idle or not in use. This helps to reduce the overall energy consumption of the drive, which in turn reduces the environmental impact and operating costs. Additionally, the drive may also include power management features that help to optimize the drive’s performance, such as automatically adjusting the power consumption of the drive based on the workload and data access patterns.
In conclusion, power management is an important aspect of the HPE 3.84TB SATA-6GBPS Read Optimized Solid State Drive (P23489-B21) as it helps to optimize the drive’s power consumption, reduce energy costs, and improve the overall performance and reliability of the drive.
Detail Features of HPE P23489-B21
- Brand Name: HPE
- Model Number or SKU # P23489-B21
- Device Type: Solid State Drive – Hot-Swap
- Capacity: 3.84 TB
- NAND Flash Memory Type: Quad-Level Cell (QLC)
- Connectivity: Single Port
- Form Factor: 2.5 inch SFF
- Interface: SATA 6Gbps
- Plug Type: Hot Pluggable
- Carrier Type: Smart Carrier (SC)
- Workload Type: Very Read Optimized
- Features: Digitally Signed Firmware
- Bundled with: HPE Smart Carrier
- Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
- Height: 7 mm
Performance of HPE P23489-B21 3.84 SSD
- Lifetime Writes: 630
- Endurance DWPD (Drive Writes Per Day): 0.09
- Drive Transfer Rate: 6 Gb/sec (external)
- MAX Seq. Reads Throughput (MiB/s): 490
- MAX Seq. Writes Throughput (MiB/s): 330
- Random Read Average Latency uSec (4KiB,Q1): 175
- Random Write Average Latency uSec (4KiB,Q1): 141
- Random Read IOPS (4KiB, Q=16): 53000
- Random Write IOPS (4KiB, Q=16): 7000
- Max Random Read IOPS (4KiB): 65000@Q32
- Max Random Write IOPS (4KiB): 7100@Q1
Expansion & Connectivity of HPE 3.84TB SATA-6GBPS SSD
- Interfaces: 1 x SATA 6 GB/s
- Compatible Bay: 2.5 Inch SFF
Power Consumption
- Idle Time: 1.70 Watt
- Random Read: 2.20 Watt
- Random Write: 2.20 Watt
- Sequential Read: 3.29 Watt
- Sequential Write: 5.30 Watt
- Random Read/Write: 2.20 Watt
- Power MAX: 5.30 Watt
Product Dimensions & Weight
- Height: 0.63 inch
- Width: 3.10 inch
- Depth: 5.45 inch
- Weight: 1.50 lbs
Compatibility Information of HPE Very Read Optimized SSD
Designed for
- HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10 (2.5inch), Medium Solution with HPE ProLiant DL325 Gen10 Plus (2.5inch), Medium Solution with HPE ProLiant DL360 Gen10 (2.5inch), Small Solution with HPE ProLiant DL360 Gen10 (2.5inch)
- HPE ProLiant DL Series: DL180 Gen10 Base (2.5inch), DL180 Gen10 Entry (2.5inch), DL180 Gen10 SMB (2.5inch), DL20 Gen10 (2.5inch), DL20 Gen10 Entry (2.5inch), DL20 Gen10 Performance (2.5inch), DL20 Gen10 solution (2.5inch), DL325 Gen10 (2.5inch), DL325 Gen10 Base (2.5inch), DL325 Gen10 Entry (2.5inch), DL325 Gen10 Performance (2.5inch), DL325 Gen10 Plus (2.5inch), DL325 Gen10 Plus All-NVMe Flash Node for Qumulo (2.5inch), DL325 Gen10 Plus for Weka Expansion Tracking (2.5inch), DL325 Gen10 SMB Solution (2.5inch), DL325 Gen10 Solution (2.5inch), DL360 Gen10 All Flash Server for Weka (2.5inch), DL360 Gen10 Compute Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 Network Choice (2.5inch), DL360 Gen10 Performance for Cohesity DataPlatform (2.5inch), DL360 Gen10 Premium (2.5inch), DL360 Gen10 SMB (2.5inch), DL360 Gen10 SMB Network Choice (2.5inch), DL360 Gen10 Special Server (2.5inch), DL380 Gen10 All Flash Server for Datera (2.5inch), DL380 Gen10 Entry SMB (2.5inch), DL380 Gen10 for SAP HANA Compute Block (2.5inch), DL380 Gen10 Hybrid Server for Datera (2.5inch), DL380 Gen10 Network Choice (2.5inch), DL380 Gen10 Network Choice for CTERA (2.5inch), DL380 Gen10 Network Choice for SAP HANA Compute Block (2.5inch), DL380 Gen10 Server for CTERA (2.5inch), DL380 Gen10 SMB (2.5inch), DL380 Gen10 SMB Networking Choice (2.5inch), DL380 Gen10 Solution (2.5inch), DL385 Gen10 Plus (2.5inch), DL385 Gen10 Plus Entry (2.5inch), DL385 Gen10 SMB (2.5inch), DL385 Gen10 Solution (2.5inch), DL388 Gen10 (2.5inch), DL560 Gen10 for SAP HANA Compute Block (2.5inch)
- HPE ProLiant ML Series: ML30 Gen10 (2.5inch), ML30 Gen10 Entry (2.5inch), ML30 Gen10 Performance (2.5inch), ML30 Gen10 Solution (2.5inch), ML350 Gen10 High Performance (2.5inch), ML350 Gen10 SMB (2.5inch), ML350 Gen10 Special Server (2.5inch)
- HPE Synergy 480 Gen10 Plus Base Compute Module (2.5inch)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
