Configuration and Management of 10-2672-03
The 10-2672-03 Cisco 40GB QSFP+ Transceiver Module can be easily configured and managed through Cisco's network management software. This software provides a central location for monitoring and managing all Cisco network devices, including the 10-2672-03 module.
The management software allows for easy configuration of the module, such as setting up port properties and monitoring module status. It also provides detailed information about the module, including firmware version, diagnostic information, and module statistics.
The management software can be accessed through a web browser or a command-line interface, providing a flexible and user-friendly experience. In addition, the management software can be used to monitor multiple devices and configurations, making it easy to manage a large network environment.
Furthermore, the 10-2672-03 Cisco 40GB QSFP+ Transceiver Module can be managed remotely, allowing for network administrators to monitor and manage the module from any location with an internet connection. This remote management capability provides greater flexibility and helps to reduce downtime.
Troubleshooting Tips
The 10-2672-03 Cisco 40GB QSFP+ Transceiver Module is a high-quality and reliable network component, but like any technology, it may experience issues or failures. Here are some troubleshooting tips to help resolve common issues with the module:
- Check Connections: Ensure that the module is properly connected to the switch or router and that the connections are secure.
- Verify LED Status: Check the LED status on the module to see if it is indicating any error codes or warnings.
- Update Firmware: Check to see if there is an updated firmware version for the module and install it if necessary.
- Test with Known Good Cable: If there are issues with the fiber connection, try testing the module with a known good cable to determine if the cable is the cause of the problem.
- Replace the Module: If all else fails, the module may need to be replaced. Check with Cisco for warranty and replacement options.
- Consult Documentation: The module comes with detailed documentation and technical specifications, which can be a valuable resource for troubleshooting issues.
- Contact Technical Support: If the issue cannot be resolved, Cisco's technical support team is available to assist with troubleshooting and resolve any technical issues.
Power Consumption of Transceiver Module
The 10-2672-03 Cisco 40GB QSFP+ Transceiver Module is designed to be energy-efficient, consuming less power compared to other transceiver modules on the market. The power consumption of the module is rated at 1.5 watts, making it an environmentally-friendly and cost-effective solution for upgrading network infrastructure.
The module features a power-saving design that reduces energy consumption while still delivering high-performance capabilities. This is achieved through the use of advanced power management technologies, such as low power mode, which reduces power consumption when the module is not in use.
In addition, the hot-swappable design of the module allows for easy installation and maintenance without disrupting the network, reducing the power consumption required for these activities. The module is also designed to meet industry standards for power consumption, such as the Energy-Efficient Ethernet (EEE) standard, further reducing energy costs.
Main Information about this Cisco 10-2672-03
- Manufacturer: Cisco
- Part Number or SKU # 10-2672-03
- Product Type: QSFP+ Transceiver Module
Technical Information of Transceiver Module
- Connectivity Technology Wired
- Cabling Type 40GBASE-SR4
- Data Link Protocol 40 Gigabit LAN
- Data Transfer Rate 40GBPS
- Optical Wave Length 850 nm
- Max Transfer Distance 492 ft
- Compliant Standards IEEE 802.3ba
Expansions And Connectivity of 40GBPS Transceiver
- Interfaces 1 x 40Gb Ethernet - MPO multi-mode
- Compatible Slots 1 x QSFP+
Miscellaneous
- Form Factor Plug-in module
- Color Beige
- Compliant Standards Laser Class 1, ELV, RoHS, IEC 60825-1, GR-326-CORE, MSA, GR-20-CORE, GR-1435-CORE
Building a fiber-optic network calls for a lot of planning and consideration of many factors. Transceivers are part of the many devices used to build optical fiber systems. A transceiver serves the combined roles of a transmitter and a receiver in that it transmits and receives signals. They are most common in communication equipment such as cellular phones, cordless telephone sets, and radio. Small form factors are required as networks become dense and space is limited, which sees transceivers included in chipsets.
In local area networks (LAN), a transceiver is used to connect a computer to printers and other devices on the network. Usually, the transceiver is integrated into the Network Interface Card (NIC)
Typical Roles of a Transceiver
- Used to convert frequencies from IF to RF.
- Widespread use in wireless communication to transmit data – voice, data, and video.
- RF transceivers are used in communication devices to support radio and TV signal transmission, digital signals transmission, and satellite communication.
- Collision detection – detection of simultaneous signals on the network.
- Transceivers can be deployed to provide a jabber function to interrupt transmission of long data stream outputs.
Look no further for all types of transceivers including fiber optic transceivers, wireless transceivers, Ethernet transceivers, and RF transceivers. All these transceivers have different characteristics and support full-duplex communication, but the principle behind their work remains the same. Different types of transceivers will have varying numbers of ports used in transceiver networking connections.
RF Transceivers: these devices are used to transmit video or voice data over a wireless medium. Commonly used for satellite communication, radio transmission, and ITE/WiMax/WLAN networks. The radio transceiver works by silencing the receiver when it is transmitting. There is an electronic switch that facilitates the connection of both the receiver and transmitter on the same antenna. The switch protects the receiver from damage that may be caused by the transmitter output.
Fiber Optic Transceivers: Also referred to as optical modules or fiber optical transceivers. Used to transmit data in fiber optic technology. The network must also have electronic components to encode or decode data into light signals.
Ethernet Transceivers: Basically used to connect electronic devices in a network so that they are able to transmit and receive data. It is also referred to as a media access unit (MAU). The best application of these transceivers is in the specification of IEEE 802.3 and Ethernet. Ethernet transceivers will detect a collision, provide Ethernet interface processing, convert digital data, and provide access to the network.
Wireless Transceivers: Wireless transceivers are a fundamental component necessary for data delivery in wireless networks. These transceivers have two layers. The physical layer has a baseband processor and RF front end. The processor converts a bitstream to a collection symbol flow for data transmission. The second layer is a MAC layer for link traffic control in contacting wireless links, improving data throughput, and preventing collisions.
We guarantee our customers high quality and reliability for all our transceiver networking solutions, irrespective of the type and size of your network.
