Ultra320 SCSI
146GB-10K RPM
146GB-15K RPM
18GB-15K RPM
300GB-10K RPM
300GB-15K RPM
36GB-10K RPM
36GB-15K RPM
73GB-10K RPM
73GB-15K RPM
The ultra320 SCSI hard drive generation is the immediate upgrade of its predecessor, the ultra160 SCSI. The newer generation ultra320 SCSI HDD comes about as an implementation of the SCSI-3 Parallel Interface-4 (SPI-4) standards.
Over its lifetime, the SCSI standard is widely used in servers and high-end workstations. It is possible to install SCSI HDDs in a desktop PC that has one or more IDE disk drives. The IDE drive acts as the boot drive, while the SCSI hard drive provides additional storage capacity. SCSI is not commonly used in desktop PCs, although it allows the addition of a scanner and several other drives such as DVD-RAM, CD-Rs, and Zip drives to a single SCSI cable chain. USB and FireWire have gradually replaced the SCSI as alternate interfaces in the latest desktop PCs.
In-network servers, SCSI allows for the setting up of several hard drives in the RAID configuration to reduce the risk of loss of data. The configuration supports hot-swapping – the changing of hard drives while the system is still operating.
Ultra320 SCSI HDD just as the name suggests delivers 320 Mbps top speed and provides a faster bus at 80 MHz and a wider data path at 16 bit. Connections with the Ultra320 SCSI HDDs just like with SCSI devices can be daisy-chained since they have two ports – the incoming and the outgoing cables. Besides, SCSI has a strong commitment to backward compatibility with previous generations, which explains its widespread use as an I/O interface and the elimination of the need for substantial investments in equipment and infrastructure. Migration to the ultra320 SCSI HDD is smooth whether it is from the Ultra160 SCSI or other generations of the SCSI standard because of backward compatibility.
The ultra320 SCSI hard drive takes on technologies such as domain validation, cyclic redundancy check, and dual-edge clocking first introduced by ultra160 SCSI. Additionally, the ultra320 SCSI hard drive introduces protocol changes and other technologies that enhance performance and support reliable data transfer speeds at 320 Mbps. We have the following ultra320 SCSI HDD options: 146GB-10K RPM, 146GB-15K RPM, 300GB-10K RPM, 300GB-15K RPM, 36GB-10K RPM, 36GB-15K RPM, 73GB-10K RPM, 73GB-15K RPM, and 18GB-15K RPM to meet your performance and storage requirements.
The standard features of the ultra320 SCSI hard drive include:
- Two-fold increase in transfer speed: The ultra320 SCSI hard drive increases the transfer rate by 100% from the previous generation at the rate of 320 Mbps. The technology allows greater transfer rates, effectively leading to greater performance in environments of extended data transfer and support for many devices on a single bus.
- Support for SCSI packet protocol: By enabling packet protocols, the ultra320 SCSI HDD helps to reduce command overhead by using dual transition (DT) data phases to transfer data, commands, and statuses rather than asynchronous phases that are generally slow. Packet protocol allows for the transfer of multiple commands in one connection as well as increased performance through minimal command overhead and maximum bus utilization.
- Quick Arbitration and Selection (QAS): the technology helps reduce control release overhead between devices at the SCSI bus. QAS is all about reducing command overhead and maximizing utilization of the bus.
- Read/Write Data Streaming facilitates the reduction of overhead associated with data transfer through the sending of a LUN Q-TAG (LQ) data stream packet, which is subsequently followed by multiple data packets. Greater write data streaming is achieved since the bus turnaround delay is eliminated between LQ and data packets.
- The flow control feature facilitates the initiator to enhance the pre-fetching of data for writes and enhance the flushing of FIFOs for reads.
Showing 1–12 of 82 results
-
SEAGATE Cheetah ST373455LC 73.4gb 15000rpm 80pin Ultra320 Scsi Hard Disk Drive. 16mb Buffer 3.5 Inch Low Profile. Refurbished
Request for quote -
Seagate ST3146707LC Cheetah 146GB 10K RPM SCSI Ultra320 8MB Hard Drive | Refurbished
Request for quote -
Seagate ST3146855LC Cheetah 146GB Hard Drive 15K RPM Ultra320 80Pin SCSI | Refurbished
Request for quote -
Seagate ST3300007LC Cheetah 300GB 10K RPM HDD Ultra320 80Pin SCSI | Refurbished
Request for quote -
Seagate ST3300007LW 300GB Hard Disk Drive Cheetah 10K RPM HDD Ultra320 68Pin SCSI HDD | New Bulk Pack
Request for quote -
Seagate ST3300007LW Cheetah 300GB 10K RPM HDD Ultra320 68Pin SCSI | Refurbished | Dell OEM
Request for quote -
Seagate ST336607LC 36GB 10K RPM Ultra 320 SCSI Hard Drive | Refurbished
Request for quote -
Seagate ST336607LW 36GB LFF 10K RPM Hard Drive Ultra 320 SCSI 8MB PC Cache Cheetah | Refurbished
$384.00 -
Seagate ST336753LC 36GB 15K RPM 8MB Buffer SCSI Hard Drive | Refurbished | Dell OEM
$30.00 -
Seagate ST336753LW 36GB Hard Disk 15K RPM 8MB Ultra320 SCSI 68Pin | New Bulk Pack
$40.00 -
Seagate ST336753LW 36GB Hard Drive 15K RPM 8MB Ultra320 SCSI 68Pin | Refurbished
Request for quote -
Seagate ST373207LC Cheetah 73GB 10K RPM Hard Drive 8MB Ultra320 SCSI | Refurbished
Request for quote
Showing 1–12 of 82 results
