Overview of the C1000-24T-4X-L Catalyst 1000 Switch
In the ever-evolving landscape of networking infrastructure, the C1000-24T-4X-L Catalyst 1000 Switch stands out as a reliable and efficient solution. This comprehensive guide aims to provide a detailed understanding of this fixed-managed switch, highlighting its key features, specifications, and benefits. From its physical attributes to its performance capabilities. The C1000-24T-4X-L is a member of the Catalyst 1000 series, known for its stability and versatility in managing network traffic. This fixed managed switch is designed to offer seamless connectivity, combining 24 ports of 10/100/1000 Ethernet with 4 x 10 Gigabit Small Form-factor Pluggable Plus (SFP+) uplink ports. Its rack-mountable design and single fixed power supply make it a convenient choice for various networking setups.
Key Attributes of Catalyst Manageable Ethernet SwitchPort Configuration
The switch boasts 24 ports, each supporting Ethernet speeds of 10/100/1000. This versatility in port configurations accommodates a range of devices, from traditional computers to high-speed servers, providing a scalable solution for growing network demands. Additionally, the inclusion of 4 x 10 Gigabit SFP+ uplink ports enhances the switch’s capacity to handle large data volumes efficiently.
Rack-Mountable Design
The C1000-24T-4X-L is designed with practicality in mind. Its rack-mountable form factor allows for easy integration into standard network racks, optimizing space and facilitating organized cable management. This feature is particularly beneficial in environments where space utilization is a critical consideration.
Single Fixed Power Supply
With a single fixed power supply, the switch simplifies the installation process. This not only reduces the complexity of setup but also ensures consistent power delivery to the connected devices. The reliability of a fixed power supply is essential for maintaining uninterrupted network operations.
Key Features for the C1000-24T-4X-L Layer 2 SwitchManaged Switch Capabilities
The C1000-24T-4X-L falls into the category of managed switches, providing administrators with the tools needed to optimize and secure the network. The ability to monitor and control network traffic enhances overall performance and aids in the identification and resolution of potential issues.
Layer 2 Functionality
This Catalyst 1000 switch operates at Layer 2 of the OSI model, focusing on data link layer functionalities. This includes the efficient management of Ethernet frames, enabling the switch to make forwarding decisions based on MAC addresses. Layer 2 switches are known for their speed and simplicity in handling local traffic.
Gigabit Ethernet Support
With 24 Gigabit Ethernet ports, the switch ensures high-speed data transfer within the local network. Whether handling large file transfers or supporting bandwidth-intensive applications, the Gigabit Ethernet support caters to the increasing demand for faster and more reliable connectivity.
10 Gigabit SFP+ Uplink Ports
The inclusion of 4 x 10 Gigabit SFP+ uplink ports elevates the switch’s capabilities to handle data-intensive tasks. These uplink ports provide a faster connection to servers or other switches, enabling seamless communication between devices and reducing latency in data transmission.
Benefits of the C1000-24T-4X-L Catalyst 1000 SwitchScalability
The switch’s 24 Ethernet ports and 4 x 10 Gigabit SFP+ uplink ports contribute to its scalability. As network requirements evolve, the C1000-24T-4X-L can easily accommodate additional devices and higher data loads without compromising performance.
Reliability
A reliable network infrastructure is crucial for the smooth operation of businesses and organizations. The C1000-24T-4X-L, with its fixed power supply and sturdy design, ensures a stable and consistent network connection, minimizing downtime and potential disruptions.
Enhanced Network Management
As a managed switch, the C1000-24T-4X-L provides administrators with the tools needed to monitor and control network traffic. This enhanced level of network management facilitates troubleshooting, security implementation, and the optimization of data flow within the network.
Use Cases
- Small to Medium-sized Enterprises (SMEs): The C1000-24T-4X-L is well-suited for SMEs seeking a reliable and cost-effective networking solution. Its scalability allows SMEs to expand their network infrastructure as their business grows, while the managed switch capabilities provide essential tools for efficient network management.
- Data Centers: In data center environments where high-speed data transfer is imperative, the C1000-24T-4X-L’s 10 Gigabit SFP+ uplink ports shine. These ports facilitate quick and seamless communication between switches and servers, making it an ideal choice for data-intensive tasks common in data center operations.
- Education Institutions: Educational institutions often require a robust network infrastructure to support the increasing demand for online learning resources. The C1000-24T-4X-L, with its Gigabit Ethernet ports and managed switch functionalities, provides a reliable solution for connecting classrooms, labs, and administrative offices.
Extraordinary Performance
The Cisco Catalyst 1000 24-Port Ethernet Switch (model number C1000-24T-4X-L) is designed to provide high-performance network connectivity for small and medium-sized businesses.
In terms of performance, the switch supports wire-speed switching and forwarding for all ports, allowing for fast and efficient data transfer. This means that the switch can process data at the maximum rate supported by the connected devices and network cables. Additionally, the switch supports Quality of Service (QoS), which can be used to prioritize network traffic and ensure that critical applications have sufficient bandwidth.
The switch also supports Energy Efficient Ethernet (EEE) which helps to reduce power consumption and improve energy efficiency, this is done by putting the ports on a low-power idle state when no data is being transmitted.
The C1000-24T-4X-L also supports advanced features such as Link Aggregation Control Protocol (LACP) and Hot Standby Router Protocol (HSRP) which can be used to increase network redundancy and availability. This means that if one link fails, the switch can automatically redirect traffic to another link without any interruption.
Power and Innovation
The Cisco Catalyst 1000 24-Port Ethernet Switch (model number C1000-24T-4X-L) is designed to provide power-efficient and innovative networking solutions for small and medium-sized businesses.
- In terms of power efficiency, the switch supports Energy Efficient Ethernet (EEE) which can be used to reduce power consumption and improve energy efficiency. EEE is a set of standards that allows network devices to reduce their power consumption when there is no network traffic. This can help to reduce the overall power consumption of the network and save on energy costs.
- In terms of innovation, the switch supports advanced features such as Quality of Service (QoS) which can be used to prioritize network traffic based on the importance of the data. This allows for efficient use of bandwidth and ensures that critical applications have sufficient bandwidth. Additionally, the switch supports VLANs (Virtual Local Area Networks) which can be used to segment a network into smaller, virtual networks for improved security and management.
- The C1000-24T-4X-L also supports advanced security features such as Access Control Lists (ACLs) which can be used to restrict access to the network based on IP address or other parameters. It also supports Cisco TrustSec, which is a security solution that helps to protect against unauthorized access and threats by creating secure network segments.
General Information for Cisco C1000-24T-4X-L 24 Ports Switch
- Manufacturer: Cisco
- Part Number or SKU# C1000-24T-4X-L
- Device Type: Managed Switch with 24 ports
Technical Specifications of Managed Switch
- Enclosure Type: Rack-mountable
- Port Type: Gigabit Ethernet
- Number of Ports: 24
- Ports Detail: 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)
Power for 24 Ports Managed Switch
- Power Device: Internal power supply
- Installed Qty: 1
- Voltage Required: AC 120/230 V (50 – 60 Hz)
Memory
- Processor: ARM, 800 MHz
- RAM: 512 MB
- Flash Memory: 256 MB
- Status Indicators: Status
Interfaces
- 24 x 1000Base-T RJ-45
- 4 x 10GBase-X SFP+ uplink
- 1 x management RJ-45
- 1 x mini-USB Type B
- 1 x USB Type A
Miscellaneous
- MTBF: 2,026,793 hours
- Compliant Standards:
- CISPR 22 Class A
- CISPR 24
- EN 61000-3-2
- EN 61000-3-3
- EN55024
- AS/NZS 60950-1
- ICES-003 Class A
- EN 61000-4-5
- RoHS
- UL 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- Directive 2011/65/EU
- VCCI Class A
- KN24
- KN22 Class A
- EN 55022 Class A
- FCC CFR47 Part 15 A
- CNS 13438 Class A
- EN 300 386
- CAN/CSA-C22.2 No. 60950-1-07 Second Edition
- AS/NZS CISPR22 Class A
Finally, the C1000-24T-4X-L Catalyst 1000 Switch stands out as a reliable, scalable, and efficient networking solution. Its blend of Gigabit Ethernet ports, 10 Gigabit SFP+ uplink ports, and managed switch capabilities make it a versatile choice for various environments, from small businesses to data centers and educational institutions. The switch’s emphasis on ease of installation, maintenance, and reliability positions it as a valuable asset in the ever-expanding realm of networking technology. Whether you are looking to upgrade your current network infrastructure or embark on a new networking project, the C1000-24T-4X-L proves to be a worthy investment.
