Description
Product Specifications
The Dell 342-1814 is a 600GB SAS hard disk drive designed for use in Dell PowerEdge servers or other compatible server systems that support SAS drives. The drive has a spindle speed of 15,000 RPM, making it suitable for high-performance applications that require low latency and fast access times. In this article, we will take a closer look at the Dell 342-1814 and its features.
SAS Interface
SAS (Serial Attached SCSI) is a high-speed interface used for connecting storage devices, such as hard disk drives and solid-state drives, to servers and other computer systems. SAS is a successor to the earlier SCSI (Small Computer System Interface) standard and provides faster data transfer rates, better reliability, and greater scalability.
The Dell 342-1814 hard disk drive uses the SAS interface, which provides a maximum data transfer rate of 3Gbps (Gigabits per second). This high-speed interface enables the drive to deliver fast data access times, making it suitable for high-performance applications such as databases, virtualization, and online transaction processing.
Spindle Speed
The spindle speed of a hard disk drive refers to the rate at which the disk platters rotate. The faster the spindle speed, the faster the drive can access data stored on the disk. The Dell 342-1814 has a spindle speed of 15,000 RPM, which is among the highest spindle speeds available for hard disk drives. This makes the drive ideal for applications that require high-speed data access, such as database servers or online transaction processing systems.
Drive Capacity
The Dell 342-1814 has a storage capacity of 600GB, which is a large amount of storage space for a hard disk drive. This makes the drive suitable for storing large amounts of data, including databases, multimedia files, and virtual machine images. The drive’s large capacity also means that it can be used as a primary storage device, rather than just for backup or archive storage.
Form Factor
The Dell 342-1814 has a form factor of 3.5 inches, which is the standard size for hard disk drives used in servers and other enterprise-level computer systems. The 3.5-inch form factor provides a larger surface area for the disk platters, which allows for greater storage capacity and faster data transfer rates.
Hot Swap Capability
The Dell 342-1814 is a hot-swappable hard disk drive, which means that it can be removed and replaced without shutting down the server or disrupting its operation. This feature allows for easy maintenance and upgrades, as well as reducing the risk of data loss due to drive failure.
In Summary, the Dell 342-1814 is a high-performance hard disk drive designed for use in enterprise-level server systems. Its 600GB storage capacity, 15,000 RPM spindle speed, and SAS interface make it ideal for applications that require fast data access and high reliability, such as databases, virtualization, and online transaction processing systems. Its 3.5-inch form factor and hot-swappable design make it easy to install and maintain, while its compatibility with Dell PowerEdge servers ensures seamless integration with existing systems.
General Information about the Dell 342-1814
- Manufacturer: Dell
- Part Number or SKU# 342-1814
- Product Type: Hard Disk Drive
- Product Name: 600GB 15K RPM SAS-3GBPS
Technical Specifications
- Capacity: 600GB
- Interface: SAS
- Data transfer rate: 3Gbps
- Rotational speed: 15,000 RPM
- Form factor: 3.5 inches
- Hot-swappable: Yes
- Included accessories: Drive tray/caddy
Performance
- Spindle Speed 15000 RPM
- Drive Transfer Rate : 600MBPS
Dimensions & Weight
- Width : 4 Inch
- Depth : 5.8 Inch
- Height : 1 Inch
- Weight : 1.52 Lbs
Compaitibility
- Poweredge 2900
- Poweredge 2970
- Poweredge C2100
- Poweredge C1100
- Poweredge R200
- Poweredge R210
- Poweredge R300
- Poweredge R310
- Poweredge R320
- Poweredge R410
- Poweredge R415
- Poweredge R420
- Poweredge R510
- Poweredge R515
- Poweredge R520
- Poweredge R710
- Poweredge R720
- Poweredge R720xd
- Poweredge R900
- Poweredge R905
- Poweredge T100
- Poweredge T105
- Poweredge T110
- Poweredge T300
- Poweredge T310
- Poweredge T320
- Poweredge T410
- Poweredge T420
- Poweredge T610
- Poweredge T710
- Powervault Dr4100
- Powervault Md1000
- Powervault Md3000
- Powervault Md3200
- Powervault Md3200i
- Powervault Nx3000
- Powervault Nx3100
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
