Description
Product Overview
Dell EMC Networking has been a trusted provider of network switches and related infrastructure equipment for businesses of all sizes. The K0C5M Dell EMC Networking N3024ET-ON switch is a high-performance, managed switch with 24 ports that is designed for use in data centers and other high-traffic environments. In this article, we will explore the key features and benefits of the K0C5M Dell EMC Networking N3024ET-ON switch.
Features
The K0C5M Dell EMC Networking N3024ET-ON switch is a managed switch with 24 ports that supports Gigabit Ethernet and 10 Gigabit Ethernet. The switch is designed to be rack-mountable and is ideal for use in data centers and other high-traffic environments where a high level of performance and reliability is required.
The switch is equipped with a range of advanced features that make it easy to manage and maintain. These features include support for SNMP (Simple Network Management Protocol), which allows for centralized management of the switch, as well as support for VLANs (Virtual Local Area Networks) and link aggregation, which allow for improved network performance and reliability.
The switch also features advanced security features, such as support for 802.1x authentication and MAC address filtering, which help to ensure that only authorized devices are able to connect to the network. Additionally, the switch supports ACLs (Access Control Lists), which allow network administrators to control access to specific network resources.
The K0C5M Dell EMC Networking N3024ET-ON switch is designed to be highly scalable, allowing businesses to expand their network as needed. The switch supports stacking, which allows multiple switches to be connected together to create a single, virtual switch. This makes it easy to manage and maintain large, complex networks.
Benefits
The K0C5M Dell EMC Networking N3024ET-ON switch offers several key benefits, including:
High-performance network connectivity: With support for Gigabit Ethernet and 10 Gigabit Ethernet, the switch provides fast and reliable network connectivity for high-traffic environments.
Advanced management features: The switch supports SNMP, VLANs, and link aggregation, which make it easy to manage and maintain large, complex networks.
Advanced security features: The switch supports 802.1x authentication, MAC address filtering, and ACLs, which help to ensure that only authorized devices are able to connect to the network.
Highly scalable: The switch supports stacking, which allows businesses to expand their network as needed.
Rack-mountable design: The switch is designed to be rack-mountable, making it easy to install in data centers and other high-traffic environments.
In summary, the K0C5M Dell EMC Networking N3024ET-ON switch is a high-performance, managed switch with 24 ports that is designed for use in data centers and other high-traffic environments. The switch is equipped with a range of advanced features that make it easy to manage and maintain, including support for SNMP, VLANs, link aggregation, and advanced security features. Additionally, the switch is highly scalable and rack-mountable, making it an ideal choice for businesses that require reliable and high-performance network connectivity.
Main Information about the Dell K0C5M
- Manufacturer: Dell
- Part Number or SKU# K0C5M
- Device Type: Networking Switch
Technical Information
- Enclosure Type : Rack-mountable 1u
- Subtype : Gigabit Ethernet
- Ports : 24 X 10/100/1000 + 2 X 10 Gigabit Sfp+ + 2 X Combo 1000base-t
Performance
- Switching Fabric Bandwidth: 212 GBPS ¦ Forwarding Performance: 158 MPPS ¦ Stacking Bandwidth: 21 GBPS
- Capacity : Ipv4 Routes (static): 1024 ¦ Ipv6 Routes (static): 1024 ¦ Ipv4 Routes (dynamic): 8160 ¦ Ipv6 Routes (dynamic): 4096 ¦ Maximum Member Ports Per Lag: 8 ¦ Maximum Dynamic Ports Per Switch Stack: 144 ¦ Lag Groups: 128 ¦ Ospf Routes: 8160 ¦ Rip Routes: 512 ¦ Ecmp Next Hops Per Route: 4 ¦ Ecmp Groups: 64 ¦ Vlan Routing Interfaces: 128 ¦ Vlans Supported: 4094 ¦ Multicast Entries (ipv4): 1536 ¦ Multicast Entries (ipv6): 512 ¦ Arp Entries: 6144 ¦ Ndp Entries: 400 ¦ Acl: 100 ¦ Maximum Rules Per Acl: 1023 ¦ Max Acl Rules System-wide: 4096 ¦ Maximum Acl Rules Per Interface (ipv4) Egress Rules: 1024 ¦ Maximum Acl Rules Per Interface (ipv4) Ingress Rules: 3072 ¦ Maximum Acl Rules Per Interface (ipv6) Egress Rules: 512 ¦ Maximum Acl Rules Per Interface (ipv6) Ingress Rules: 1021 ¦ Maximum Vlan Interfaces With Acls Applied: 24
- Mac Address Table Size : 32k Entries
- Routing Protocol : Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, Mld
- Remote Management Protocol : Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Http, Tftp, Ssh-2
- Encryption Algorithm : Md5, Aes, Ssl, Tls
- Authentication Method : Radius, Tacacs+, Secure Shell V.2 (ssh2)
Features
- Flow Control, Mdi/mdi-x Switch, Auto-negotiation, Arp Support, Vlan Support, Port Mirroring, Diffserv Support, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Ipv6 Support, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Stp Root Guard, Ipv4 Support, Lldp Support, Link Aggregation Control Protocol (lacp), Energy Efficient Ethernet, Management Information Base (mib), Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Neighbor Discovery Protocol (ndp), Tagged Vlan, Redundant Fans, Protocol-based Vlans Support
- Compliant Standards : IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1d, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (lacp), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ag, IEEE 802.1ab (lldp), IEEE 802.3az, IEEE 802.3ax
- Ram : 2 Gb
- Flash Memory : 1 Gb
Expansion / Connectivity
- interfaces :
- 24 X Gigabit Lan Rj-45 ¦ 2 X 10gbit Lan Sfp+ ¦ 2 X Gigabit Lan Rj-45 ¦ 1 X Serial (rs-232) Rj-45 Management ¦ 1 X Usb Type A ¦ 2 X Network Stack Device
Power
- Power Device : Internal Power Supply – Hot-plug
- Installed Qty : 1 (installed) / 2 (max)
- Power Redundancy : Optional
- Power Redundancy Scheme : 1+1 (with Optional Power Supply)
- Power Provided : 200 Watt
- Power Consumption Operational : 67.1 Watt
