Performance and Reliability
The 364326-001 HP 300GB 10K RPM Ultra-320 SCSI 68-Pin LVD Internal Hard Drive is a high-performance storage device designed for use in enterprise-level servers and storage systems. It uses the Ultra-320 SCSI interface to connect to a host controller and communicate with the system.
The drive has a storage capacity of 300GB, which is a large amount of storage space for storing large amounts of data, such as videos, images, and other multimedia content. It has a rotation speed of 10,000 RPM (revolutions per minute), which is faster than standard hard drives and allows for faster data transfer and access times.
The drive also features the Ultra-320 SCSI interface, which is a high-speed data transfer standard that allows for faster data transfer between the drive and the host controller. This is useful for applications that require high-speed data transfer, such as video editing and large data backups.
The drive also features a 68-Pin LVD (Low Voltage Differential) connector, which is a type of SCSI connector that is designed for use in high-speed data transfer applications. It provides a higher data transfer rate compared to other SCSI connectors, and it is commonly used in high-performance storage systems.
The drive is an internal hard drive, which means it is installed inside the server or storage system, and not externally. This allows for better performance and more secure data storage.
The 364326-001 HP 300GB 10K RPM Ultra-320 SCSI 68-Pin LVD Internal Hard Drive is not designed for scalability in terms of adding multiple drives to increase storage capacity. It is a single drive unit with a storage capacity of 300GB and it is not expandable.
However, it is still possible to increase storage capacity by adding multiple drives to a server or storage system. This can be done by connecting multiple hard drives to a host controller through the Ultra-320 SCSI interface, and then creating a RAID (Redundant Array of Independent Disks) configuration. RAID configurations can provide enhanced data protection and increase storage capacity by combining multiple hard drives into a single logical drive.
It's important to note that the system you are connecting the drive to must be compatible with the Ultra-320 SCSI interface and the 68-Pin LVD connector. Additionally, it's also important to check the system's RAID capabilities, compatibility, and the number of connectors available for multiple drives.
The 364326-001 HP 300GB 10K RPM Ultra-320 SCSI 68-Pin LVD Internal Hard Drive is designed with a 3.5-inch form factor. A form factor refers to the physical size and shape of a hard drive.
The 3.5-inch form factor is the most common size for internal hard drives and it is used in both desktop and enterprise-level servers and storage systems. The 3.5-inch form factor is physically larger than the 2.5-inch form factor, which is commonly used in laptops and smaller servers and storage systems.
The 3.5-inch form factor allows for more storage capacity and higher performance than smaller form factors. It also provides more room for internal components, such as read/write heads, and allows for better cooling.
The drive can be easily installed in systems that support the 3.5-inch form factor and it is compatible with most servers and storage systems that support the Ultra-320 SCSI interface and the 68-Pin LVD connector. It's important to check the system's compatibility and the number of connectors available for the drive before installing it.
Manufacturer : HP
MPN : 364326-001
Type : Internal Hard Drive (HDD)
HDD Type : Ultra-320 SCSI
SKU : 364326-001
Product Type Internal Hard Drive
Form Factor 3.5-inch
Capacity 300 GB
Spindle Speed 10K RPM
Drive Interface Type Ultra-320 SCSI
Connector Type 68-Pin
Dimension and Weight
Width : 4 Inch
Depth : 5.8 Inch
Height : 1 Inch
Weight : 1.52 Lbs
About Refurbished Products
The ultra320 SCSI hard drive generation is the immediate upgrade of its predecessor, the ultra160 SCSI. The newer generation ultra320 SCSI HDD comes about as an implementation of the SCSI-3 Parallel Interface-4 (SPI-4) standards.
Over its lifetime, the SCSI standard is widely used in servers and high-end workstations. It is possible to install SCSI HDDs in a desktop PC that has one or more IDE disk drives. The IDE drive acts as the boot drive, while the SCSI hard drive provides additional storage capacity. SCSI is not commonly used in desktop PCs, although it allows the addition of a scanner and several other drives such as DVD-RAM, CD-Rs, and Zip drives to a single SCSI cable chain. USB and FireWire have gradually replaced the SCSI as alternate interfaces in the latest desktop PCs.
In-network servers, SCSI allows for the setting up of several hard drives in the RAID configuration to reduce the risk of loss of data. The configuration supports hot-swapping - the changing of hard drives while the system is still operating.
Ultra320 SCSI HDD just as the name suggests delivers 320 Mbps top speed and provides a faster bus at 80 MHz and a wider data path at 16 bit. Connections with the Ultra320 SCSI HDDs just like with SCSI devices can be daisy-chained since they have two ports - the incoming and the outgoing cables. Besides, SCSI has a strong commitment to backward compatibility to previous generations, which explains its widespread use as an I/O interface and elimination of the need for substantial investments in equipment and infrastructure. Migration to the ultra320 SCSI HDD is smooth whether it is from the Ultra160 SCSI or other generations of the SCSI standard because of backward compatibility.
The ultra320 SCSI hard drive takes on technologies such as domain validation, cyclic redundancy check, and dual-edge clocking first introduced by ultra160 SCSI. Additionally, the ultra320 SCSI hard drive introduces protocol changes and other technologies that enhance performance and support reliable data transfer speeds at 320 Mbps. We have the following ultra320 SCSI HDD options: 146GB-10K RPM, 146GB-15K RPM, 300GB-10K RPM, 300GB-15K RPM, 36GB-10K RPM, 36GB-15K RPM, 73GB-10K RPM, 73GB-15K RPM, and 18GB-15K RPM to meet your performance and storage requirements.
The standard features of the ultra320 SCSI hard drive include:
- Two-fold increase in transfer speed: The ultra320 SCSI hard drive increases the transfer rate by 100% from the previous generation at the rate of 320 Mbps. The technology allows greater transfer rates, effectively leading to greater performance in environments of extended data transfer and support for many devices on a single bus.
- Support for SCSI packet protocol: By enabling packet protocols, the ultra320 SCSI HDD helps to reduce command overhead by using dual transition (DT) data phases to transfer data, commands, and statuses rather than asynchronous phases that are generally slow. Packet protocol allows for the transfer of multiple commands in one connection as well as increased performance through minimal command overhead and maximum bus utilization.
- Quick Arbitration and Selection (QAS): the technology helps reduce control release overhead between devices at the SCSI bus. QAS is all about reducing command overhead and maximizing utilization of the bus.
- Read/Write Data Streaming facilitates the reduction of overhead associated with data transfer through the sending of a LUN Q-TAG (LQ) data stream packet, which is subsequently followed by multiple data packets. Greater write data streaming is achieved since the bus turnaround delay is eliminated between LQ and data packets.
- The flow control feature facilitates the initiator to enhance the pre-fetching of data for writes and enhance the flushing of FIFOs for reads.
