Description
Introduction to HPE 5820AF
The HPE 5820AF is a stackable managed switch from Hewlett Packard Enterprise (HPE). This switch is part of the HPE 5820 Series and is model number JG219-61101.
This switch is designed for small to medium-sized businesses and offers 24 ports of Gigabit Ethernet connectivity. It is a Layer 3 switch, meaning it can perform more advanced routing functions, making it ideal for use in larger network environments.
The switch is stackable, which means it can be combined with other 5820AF switches to form a single, larger switch. This provides more ports and increased network capacity, as well as easier management of the entire network.
In addition to its advanced routing capabilities, the HPE 5820AF is a managed switch, meaning it can be configured and managed through a web interface or command line interface. This allows for greater control over the network and the ability to monitor network activity and performance.
Managed Switch with Comprehensive Management Tools
The JG219-61101 HPE 5820AF 24 Ports L3 Stackable Managed Switch is a high-performance switch designed for data center and enterprise networks. This switch offers 24 Gigabit Ethernet ports, which can be stacked to form a single logical switch with up to eight units. This switch is designed to provide comprehensive management tools to make network administration easier and more efficient.
The switch supports L3 routing, allowing it to perform advanced network functions such as inter-VLAN routing, policy-based routing, and Internet Protocol (IP) services. This switch is also equipped with comprehensive management tools, including a graphical user interface (GUI), Command Line Interface (CLI), and Simple Network Management Protocol (SNMP) support.
The switch supports virtual LANs (VLANs), which allow network administrators to segment their network into multiple broadcast domains. This reduces network congestion, improves security, and increases network scalability.
The HPE 5820AF 24 Ports L3 Stackable Managed Switch is also equipped with advanced security features, including access control lists (ACLs) and quality of service (QoS) for improved network performance and security. Additionally, the switch supports Energy Efficient Ethernet (EEE) and is designed to be power efficient, reducing the cost of energy consumption.
24 Gigabit Ethernet Ports
The JG219-61101 HPE 5820AF 24 Ports L3 Stackable Managed Switch is a high-performance network switch designed for enterprise and data center environments. It features 24 Gigabit Ethernet ports, which allow for high-speed network connectivity and data transfer.
The switch is stackable, meaning multiple units can be connected together to create a single, larger network. This allows for increased network scalability and flexibility.
The switch is also managed, meaning that it can be remotely configured, monitored, and managed from a central location. This allows for improved network efficiency and reduced downtime.
In addition to its standard Gigabit Ethernet ports, the switch also has Layer 3 capabilities, which allow for advanced routing and network segmentation. This makes it an ideal solution for complex network environments that require more sophisticated network management.
Specifications
- Manufacturer: HP
- Manufacturer Part Number: JG219-61101
- Type: Networking
- Sub-Type: Switch 24 Ports
- Device Type : Switch – 24 Ports – L3 – Managed – Stackable
- Enclosure Type : Rack-Mountable – 1u
- Ports : 24 X 1 Gigabit / 10 Gigabit Sfp+ + 2 X 10/100/1000
- Performance : Throughput : 360 Mpps Routing/Switching Capacity : 484 Gbps
- Mac Address Table Size : 32k Entries
- Jumbo Frame Support : Yes
- Routing Protocol : Ospf, Bgp-4, Is-Is, Rip-1, Rip-2, Bgp, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-Sm, Static Ip Routing, Pim-Dm, Igmpv3, Ospfv3, Pim-Ssm, Msdp, Ripng, Mldv2, Mld
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Http, Https, Cli
- Encryption Algorithm : Ssl
- Authentication Method : Radius, Tacacs+, Secure Shell V.2 (Ssh2)
- Features : Flow Control, Layer 2 Switching, Dhcp Support, Bootp Support, Arp Support, Vlan Support, Igmp Snooping, Dos Attack Prevention, Port Mirroring, Broadcast Storm Control, Ipv6 Support, Weighted Fair Queuing (Wfq), Weighted Random Early Detection (Wred), Sflow, Rapid Spanning Tree Protocol (Rstp) Support.
- Compliant Standards : Ieee 802.1p, Ieee 802.3x, Ieee 802.1x, Ieee 802.3ah, Ieee 802.1ag
- Ram : 512 Mb – Sdram
Expansion / Connectivity
- Interfaces : 2 X 10base-T/100base-Tx/1000base-T – Rj-45 Serial : 1 X Console – Rj-45 – Management 24 X Sfp+ Hi-Speed Usb : 1 X 4 Pin Usb Type A 1 X Rj-45 – Management
Power
- Power Device : Power Supply – Hot-Plug – Plug-In Module
- Installed Qty : 0 (Installed) / 2 (Max)
- Power Redundancy : Optional
- Power Redundancy Scheme : 1+1
- Voltage Required : Ac 120/230 V ( 50/60 Hz )
