Description
Advanced Network Security
JG299-61001 HP SP A3600-24 V2 Ei is a 24-port managed rack-mountable switch designed for advanced network security. It is part of the HP A3600 series of switches and is designed to meet the needs of small and medium-sized businesses.
The switch is managed, which means it can be configured and monitored through a web-based interface or command-line interface. This allows administrators to control the flow of data, prioritize traffic, and monitor network activity.
One of the key features of the JG299-61001 is its advanced network security. This switch is equipped with security features such as 802.1X authentication, Dynamic Host Configuration Protocol (DHCP) snooping, and access control lists (ACLs). These features provide an extra layer of protection for the network against unauthorized access, hacking, and other security threats.
In terms of performance, the JG299-61001 supports high-speed data transfer, with a switching capacity of up to 52 Gbps. This allows for fast and efficient communication between devices connected to the network.
Deployment and Configuration
JG299-61001 HP SP A3600-24 V2 Ei is a 24-port managed rack-mountable switch that is designed for deployment and configuration in large-scale network environments. This switch supports advanced management features and provides high-performance networking for organizations of all sizes.
Deployment:
To deploy this switch, it needs to be mounted in a 19-inch standard rack. The switch can be mounted either vertically or horizontally. Once the switch is mounted, it should be connected to power and to the network. The switch can be powered through its AC power supply or through its DC power supply.
Fainaly, the JG299-61001 HP SP A3600-24 V2 Ei switch can be configured through a web-based interface or through a command line interface (CLI). The web-based interface provides a user-friendly interface that allows administrators to easily configure the switch’s settings. The CLI provides a more advanced method for configuring the switch and is useful for advanced administrators.
Some of the configuration options available include
- VLAN Configuration: This switch supports multiple VLANs, which can be configured through the web-based interface or the CLI.
- Port Configuration: The switch’s 24 ports can be configured for different speeds and duplex settings.
- Quality of Service (QoS): The switch supports QoS, which allows administrators to prioritize network traffic based on the type of data being transmitted.
- Security: The switch supports a range of security features, including 802.1X authentication, Access Control Lists (ACLs), and SSH encryption.
Exceptional Reliability
JG299-61001 HP SP A3600-24 V2 Ei is a 24 port managed rack-mountable switch that provides exceptional reliability for businesses looking to upgrade their network infrastructure. This switch features advanced network management features and is equipped with 24 Gigabit Ethernet ports. It is designed for deployment in large enterprise networks and offers the ideal combination of affordability, performance, and reliability. The switch provides advanced security features, including 802.1x authentication, to help protect against unauthorized access to your network. It also offers robust Quality of Service (QoS) capabilities, allowing you to prioritize bandwidth for critical applications. Additionally, the switch is designed with a redundant power supply to ensure continuous network operation even in the event of a power failure. With these features, the JG299-61001 HP SP A3600-24 V2 Ei is an excellent choice for businesses looking to upgrade their network infrastructure with reliable and secure switching technology.
Main Information
- Manufacturer: HP
- Part Number or SKU# JG299-61001
- Type: Networking
- Sub-Type: Switch 24 Ports
- Device Type : Switch – 24 Ports – L4 – Managed – Stackable
- Enclosure Type : Rack-Mountable – 1u
Technical Information
- Ports : 24 X 10/100 + 4 X Gigabit Sfp + 2 X Shared 10/100/1000
- Performance : Throughput : 9.5 Mpps
- Routing/Switching Capacity : 12.8 Gbps
- Jumbo Frame Support : 9216
- Routing Protocol : Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-Sm, Pim-Dm, Igmpv3, Ospfv3, Pim-Ssm, Msdp, Static Ipv4 Routing, Static Ipv6 Routing, Ecmp, Ripng, Bgp-4+
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Http, Https, Cli
- Encryption Algorithm : Ssl
- Authentication Method : Secure Shell (Ssh), Radius, Secure Shell V.2 (Ssh2)
Protocol System & Features
- Features : Flow Control, Routing, Layer 2 Switching, Dhcp Support, Arp Support, Vlan Support, Auto-Uplink (Auto Mdi/Mdi-X), Igmp Snooping, Ipv6 Support, Sflow, Spanning Tree Protocol (Stp) Support, Rapid Spanning Tree Protocol (Rstp) Support, Virtual Route Redundancy Protocol (Vrrp) Support, Multiple Spanning Tree Protocol (Mstp) Support, Trivial File Transfer Protocol (Tftp) Support, Access Control List (Acl) Support, Quality Of Service (Qos), Committed Access Rate (Car), Jumbo Frames Support, Mld Snooping, Device Link Detection Protocol (Dldp) Support, Rapid Ring Protection Protocol (Rrpp) Support, Bidirectional Forwarding Detection (Bfd), Endpoint Admission Defense (Ead), Stp Root Guard
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3i, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1ad, Ieee 802.1v, Ieee 802.1ab (Lldp)
- Ram : 256 Mb – Sdram
Mamory
- Flash Memory : 128 Mb
Expansion / Connectivity
- Interfaces : 24 X 10base-T/100base-Tx – Rj-45
- 4 X Sfp (Mini-Gbic)
- Serial : 1 X Console – Rj-45
- 2 X 10base-T/100base-Tx/1000base-T – Rj-45
Power
- Power Device : Power Supply
- Voltage Required : Ac 120/230 V ( 50/60 Hz )
