The 790317-001 HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter is a type of network interface card (NIC) designed by Hewlett Packard Enterprise (HPE) for use in servers or workstations.
This particular network adapter is capable of providing dual 10 Gigabit Ethernet connectivity to a host system, meaning that it has two separate ports for connecting to two different networks simultaneously. The network adapter is designed to fit into a PCI Express 3.0 x8 slot on the motherboard of the host system.
As for operating system and software support, the HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter is compatible with a range of operating systems including Microsoft Windows Server 2012, Windows Server 2016, Windows Server 2019, Red Hat Enterprise Linux 7 and 8, and SUSE Linux Enterprise Server 12 and 15.
In addition to operating system support, the network adapter is also compatible with a range of network management and configuration software from HPE, including the HPE Smart Update Manager, HPE Systems Insight Manager, and HPE Intelligent Provisioning. These software tools enable IT administrators to manage and configure the network adapter and its associated network connections from a centralized console, making it easier to deploy and manage in large-scale network environments.
Installation and Configuration Requirements
The 790317-001 HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter is a high-performance network interface card designed for use in HPE servers. This adapter allows for the connection of two 10 Gigabit Ethernet network ports using SFP+ transceivers.
To install and configure this network adapter, the following requirements must be met:
- System compatibility: The server must be compatible with the HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter. Check the HPE website for compatibility information.
- Driver installation: The appropriate driver for the network adapter must be installed on the server. The driver can be downloaded from the HPE website or provided with the adapter.
- Hardware installation: The network adapter must be installed in a PCI Express 3.0 x8 slot on the server. The installation instructions can be found in the HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter User Guide.
- SFP+ transceivers: The network adapter requires SFP+ transceivers to connect to the network. The appropriate transceivers must be installed and configured for the network.
- Network configuration: The network adapter must be configured with the appropriate network settings, such as IP address, subnet mask, and gateway. This can be done through the server’s operating system or through the network adapter’s configuration utility.
Compatibility with HPE and Non-HPE Systems
The 790317-001 HPE Ethernet 10GB Dual Port PCI Express 3.0 x8 562FLR-SFP+ Network Adapter is designed to be compatible with a wide range of HPE and non-HPE systems.
Compatibility with HPE Systems: This network adapter is specifically designed and tested to work seamlessly with HPE servers and other HPE equipment. It is compatible with HPE ProLiant DL and ML Gen9 and Gen10 servers, HPE Apollo 2000 and 4000 systems, HPE Synergy, and other HPE systems that have a PCIe 3.0 x8 slot available.
Compatibility with Non-HPE Systems: The 790317-001 network adapter is also compatible with a wide range of non-HPE systems that have a PCIe 3.0 x8 slot available. However, it is important to note that while the adapter may be physically compatible with a non-HPE system, it may not be officially supported or tested by HPE.
Before installing the adapter in a non-HPE system, it is recommended to consult the system documentation to confirm compatibility and to ensure that the system’s firmware and drivers are up to date. It is also recommended to contact the adapter’s manufacturer or HPE support for further assistance and compatibility information.
Detail Description
- Manufacturer: HPE
- MPN: 790317-001
- Type: Networking
- Adapter-Type: Network Adapter 10 Gigabit
- SKU: 790317-001
- Option Part Number: 727054-B21
- Data Rate: Two ports, each at 20 Gb/s bi-directional; 40 Gb/s aggregate bi-directional theoretical bandwidth.
- Form Factor: Flexible LOM
- Bus Type: PCI Express 3.0 (Gen 3) x8
- IEEE Compliance: 802.3, 802.1ab, 802.3x, 802.3ad, 802.1p/ 802.1q, 802.3ae, 802.1Qau
Networking
- Network Processor: Intel® X710 Controller
- Ports: 10 Gigabit SFP+ x 2
- Connectivity Technology: Wired
- Data Link Protocol: 10 GIGE
- Data Transfer Rate: 10 GBPS
- Capacity: Jumbo frame size: 9.5 KB
- Status Indicators: Status, link/activity
- Features: Wake on LAN (WOL), PXE support
Processor / Memory
- Processor: 1 Intel (Intel® X710 Controller)
Expansion / Connectivity
- Interfaces: 2 x 10Gb Ethernet – SFP+
Power Specifications
- Power Consumption: <12 Watt
Environmental Parameters
- Min Operating Temperature: 0°C (32 °F)
- Max Operating Temperature: 55°C (131 °F)
- Operating Humidity Range: 10 – 90% (non-condensing)
Miscellaneous
- RoHS Compliance: 6 of 6
Agency Approvals
- USA: FCC Part 15 Class A
- Canada: ICES-003, Issue 4
- Japan: VCCI V3 (2010.04) Class A
- International: EN55022:2006 + A1:2007 Class A, EN55024:1998+A1:2011+A2, EN61000-3-2:2006, EN61000-3-3:2008
- Taiwan: BSMI, CNS13438 (2006) Class A
- Australia/New Zealand (AS/NZS): EN55022:2006+A12007 Class A
- Korea: KN22 Class A, KN24
Software / System Requirements
- Operating System Required: SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x, Oracle Solaris 10, VMware ESX 4.1, VMware ESXi 4.1, Microsoft Windows Server 2012
Product Dimensions & Weight
- Width: 9.50 inch
- Height: 2.25 inch
- Depth: 7.50 inch
- Weight: 1.00 lbs
Compatibility Information
- HPE ProLiant DL Series: DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL60 Gen9, DL80 Gen9, DL120 Gen9, DL160 Gen9, DL180 Gen9, DL360 Gen9, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Performance, DL360 Gen10 Solution, DL380 Gen9, DL380 Gen10, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 High Performance, DL380 Gen10 Performance, DL380 Gen10 Solution, DL385 Gen10, DL385 Gen10 Base, DL385 Gen10 Entry, DL385 Gen10 High-Performance, DL385 Gen10 Performance, DL385 Gen10 Solution, DL560 Gen9, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL580 Gen9, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance Servers
- HPE ProLiant XL Series: XL230a Gen9 NHP Compute Tray (12G), XL450 Gen10 Servers
- HPE Apollo 2000 Series: XL170r Gen9, XL190r Gen9 Servers
- HPE Apollo 4200 Gen9 Server
- HPE Apollo 4500 XL450 Gen9 Server
- HPE Apollo 4520 Gen9 Server
- HPE Apollo 6000 Series: XL230a Gen9, XL250a Gen9s Servers
- HPE Apollo 6500 XL270d Gen9 Server
- HPE StoreEasy 1850, 3850 Gateway Single Node
