Description
Overview and Features
The HPE 1420 5GBPS PoE+ Switch (JH328A) is a rack-mountable switch that offers 5 ports of Gigabit Ethernet connectivity with Power over Ethernet (PoE) support. This switch is designed for small and medium-sized businesses, and can be used in a variety of network environments, including branch offices, campus networks, and data centers.
The HPE 1420 5GBPS PoE+ Switch offers a range of features that make it easy to set up and manage. It has a web-based management interface, which allows for easy configuration and monitoring of the switch. Additionally, the switch supports SNMP, RMON, and sFlow, which can be used for network monitoring and troubleshooting.
One of the key feature of the switch is its Power over Ethernet (PoE) support, which allows you to provide power to connected devices, such as wireless access points, IP phones and security cameras, over the Ethernet cable. The switch supports PoE+ (IEEE 802.3at) which allows you to provide up to 30W of power per port, providing sufficient power to run high-power devices such as PTZ cameras and wireless access points.
Other key features of the HPE 1420 5GBPS PoE+ Switch include support for Quality of Service (QoS) and Traffic Prioritization, Energy Efficient Ethernet (EEE) support, and IPv6 support. It also support for VLAN and Link Aggregation, enabling you to segment your network and increase bandwidth.
Power over Ethernet (PoE) Support
The HPE 1420 5GBPS PoE+ Switch (JH328A) supports Power over Ethernet (PoE) which allows you to provide power to connected devices over the Ethernet cable. This eliminates the need for a separate power supply for devices such as wireless access points, IP phones, and security cameras, making installation and maintenance more convenient.
The switch supports PoE+ (IEEE 802.3at) which allows you to provide up to 30W of power per port. This provides sufficient power to run high-power devices such as PTZ cameras and wireless access points. The switch also supports PoE power budget of 63 watts, which means it can support power to multiple devices.
The switch also supports PoE scheduling, which allows you to schedule when PoE is provided to connected devices. This feature can be useful for devices that only need to be powered on during specific hours, such as security cameras. Additionally, the switch also has a PoE power management feature that allows you to monitor the power consumption of connected devices and adjust the power budget accordingly.
Energy Efficient Ethernet (EEE) Support
Energy Efficient Ethernet (EEE) is a set of standards that helps to reduce the power consumption of Ethernet devices, such as switches, without impacting their performance. The HPE 1420 5GBPS PoE+ Switch (JH328A) supports Energy Efficient Ethernet (EEE) which helps in reducing the power consumption of the switch when the network is idle or under low traffic load.
When a switch supports EEE, it can enter a low-power idle state when there is no network activity. This reduces the power consumption of the switch, and can help to lower energy costs and reduce the environmental impact of your network.
When a device connected to the switch becomes active, the switch quickly exits the low-power idle state and resumes normal operation. This ensures that there is no impact on network performance and that data is transmitted and received without delay.
Specifications:Brand: HPE
Part Number: JH328A
Type: Networking
Sub-Type: Switch 5 Ports
Device Type : Switch – 5 Ports – Unmanaged
Enclosure Type : Desktop, Rack-Mountable 1u
Ports : 5 X 10/100/1000
Power Over Ethernet (POE) : POE+
Performance : Switching Capacity : 10 GBPS ¦ Throughput (64-Byte Packet Size) : 7.4 MPPS ¦ Latency (100 Mbps) : 3 µs ¦ Latency (1000base-T) : 2.6 µs
Mac Address Table Size : 2048 Entries
Jumbo Frame Support : 9216 Bytes
Features : Flow Control, Full Duplex Capability, Auto-Negotiation, Auto-Uplink (Auto MDI/MDI-X), Half Duplex Mode, Quality Of Service (QOS), Fanless, Diffserv Code Point (DSCP) Support
Compliant Standards : IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az
Power : Ac 120/230 V ( 50/60 Hz ) 300 Ma
Flash Memory : 1 MB
EXPANSION / CONNECTIVITY :
Interfaces : 5 X 1000 Base-T – Rj-45
Power Device : Internal Power Supply
Voltage Required : Ac 120/230 V ( 50/60 Hz )
Electric Current Required : 300 Ma
Power Consumption Operational : 40 Watt
