Product Overview of the HPE JL686A Switch
In the rapidly evolving landscape of networking technologies, the HPE JL686A Aruba 1930 48G Switch stands out as a powerful and versatile solution. This managed switch offers a myriad of features designed to meet the demands of modern businesses. This comprehensive review will delve into the key aspects of the JL686A Aruba 1930 48G Switch, providing an in-depth understanding of its specifications, capabilities, and the benefits it brings to the table.
Specifications- The HPE JL686A Aruba 1930 48G Switch boasts an impressive array of specifications, making it a robust choice for network infrastructure. With 48 Gigabit Ethernet ports, it provides ample connectivity for a multitude of devices. Additionally, the switch supports Power over Ethernet (PoE) on four of its ports, facilitating the seamless integration of devices that require both data and power, such as IP cameras and VoIP phones.
- For enhanced flexibility and scalability, the switch features four Small Form-Factor pluggable (SFP) ports, enabling the connection of fiber optic or copper uplink modules. This ensures high-speed data transfer and accommodates diverse network requirements. The switch further distinguishes itself with a substantial power budget of 370W, ensuring reliable PoE support for connected devices.
- The 48 Gigabit ports on the Aruba 1930 48G Switch deliver non-blocking performance, providing a high-throughput foundation for data-intensive applications. Whether it's video streaming, large file transfers, or real-time communication, this switch is designed to handle the demands of a modern network environment.
- The switch operates as a managed device, offering advanced features for network administrators. With a web-based interface, users can easily configure and monitor the switch, making it an accessible option for both seasoned IT professionals and those new to network management. The inclusion of Layer 2 switching features enhances network efficiency and security, while VLAN support allows for the segmentation of the network for improved traffic management.
- PoE Capability: One of the standout features of the Aruba 1930 48G Switch is its Power over Ethernet functionality. The switch supports PoE on four ports, simplifying the deployment of devices like security cameras and wireless access points. This eliminates the need for separate power sources, streamlining installation and reducing cable clutter.
- The 370W power budget ensures that the switch can deliver sufficient power to connected devices, even in scenarios where multiple PoE devices are in use. This capability not only enhances the overall efficiency of the network but also contributes to cost savings by eliminating the need for additional power infrastructure.
- Uplink Flexibility with SFP Ports: In addition to its Gigabit Ethernet ports, the Aruba 1930 48G Switch features four SFP ports, offering flexibility in uplink connectivity. These ports support both copper and fiber optic connections, allowing organizations to choose the medium that best suits their infrastructure and distance requirements.
- The inclusion of SFP ports is particularly valuable in scenarios where long-distance connections or high bandwidth demands are prevalent. This ensures that the switch can adapt to a variety of networking needs, making it a versatile solution for diverse environments.
- Scalability and Future-Proofing: The 48 ports on the Aruba 1930 48G Switch provide ample room for connecting a multitude of devices, making it suitable for small to medium-sized businesses with growing network requirements. As the switch is managed, administrators can easily scale and adapt the network to accommodate new devices and changing demands.
- Security Features: Security is a paramount concern in modern networking, and the Aruba 1930 48G Switch addresses this with a range of security features. The switch supports IEEE 802.1X network access control, enhancing the overall network security by authenticating devices before granting them access. This prevents unauthorized access and helps safeguard sensitive data.
- Additionally, the switch supports Access Control Lists (ACLs) for fine-grained control over network traffic. By defining rules based on source and destination IP addresses, administrators can regulate the flow of data within the network, mitigating potential security risks.
The JL686A HPE Aruba 4 PoE SFP 48 Ports Managed Rack Mountable Switch is a high-performance switch that offers advanced switching features and performance capabilities. Some of the key features of this switch include:
- Power over Ethernet (PoE): This switch supports PoE, which allows it to power connected devices such as IP phones, wireless access points, and cameras directly through the Ethernet cable. This eliminates the need for additional power sources and makes it easier to deploy and manage these devices.
- SFP Ports: The switch includes 4 SFP ports, which allow for the connection of high-speed optical transceivers for increased bandwidth and distance capabilities. This allows for the connection of devices such as servers, storage, and other networking equipment at faster speeds and over longer distances.
- Managed Switch: The JL686A is a managed switch, which means it can be configured and monitored using a web-based interface or through a command-line interface (CLI). This allows for advanced features such as VLANs, Quality of Service (QoS), and link aggregation to be configured and managed.
- High Port Density: The switch features 48 ports, which allows for a large number of devices to be connected to it. This makes it ideal for use in large networks or data centers where a high number of devices need to be connected.
- Rack Mountable: The switch is rack mountable, which allows it to be easily installed in a standard 19-inch rack. This makes it easy to integrate into existing network infrastructure.
- Quality of Service (QoS) is a feature that allows for the prioritization of network traffic to ensure that certain types of traffic receive higher priority than others. This can be useful for applications that require a higher level of bandwidth, such as video conferencing or online gaming.
- The JL686A HPE Aruba 4 PoE SFP 48 Ports Managed Rack Mountable Switch has built-in QoS functionality that allows for the prioritization of traffic based on various criteria, such as IP address, port number, and protocol. This allows the switch to give priority to critical traffic, such as voice or video, while still allowing other traffic to pass through the network.
- Traffic prioritization is a feature that allows the switch to assign different levels of priority to different types of traffic. For example, the switch can be configured to give priority to voice traffic over data traffic, ensuring that voice calls are clear and free of interruption.
- The JL686A HPE Aruba 4 PoE SFP 48 Ports Managed Rack Mountable Switch also can assign priorities to specific ports, allowing for the prioritization of traffic from specific devices or applications. This can be useful for ensuring that critical applications receive the bandwidth they need, while still allowing other traffic to pass through the network.
- The JL686A HPE Aruba 4 PoE SFP 48 Ports Managed Rack Mountable Switch is designed to be highly efficient in terms of power and energy consumption. This switch is equipped with Power over Ethernet (PoE) capabilities, which allows it to power devices connected to the switch without the need for additional power sources. This feature helps to reduce the overall power consumption of the switch and the devices connected to it.
- In addition to PoE, the JL686A also has energy-efficient features that help to reduce power consumption. For example, the switch has an Energy Efficient Ethernet (EEE) feature that reduces power consumption during periods of low network activity. Additionally, the switch can be configured to automatically power off ports that are not in use, further reducing power consumption.
- The JL686A also has a power-saving mode that can be activated to reduce power consumption during periods of low network activity. This mode reduces the power consumption of the switch by reducing the speed of the fans and other components.
- Manufacturer: HPE
- Part Number or SKU# JL686A
- Product Type: Switch 48 Ports
- Product Name: Networking Switch
- Enclosure Type: Rack-Mountable 1u
- 48 X 10/100/1000 + 4 X 1 Gigabit / 10 Gigabit Sfp+
- Power Over Ethernet (Poe): Poe
- Poe Budget: 370 W
- Mdi/mdi-x), Igmp Snooping, Ipv6 Support, Half Duplex Mode, Full Duplex Mode, Spanning Tree Protocol (STP) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (ACL) Support, Quality Of Service (QoS), Trusted Platform Module (TPM), Lldp Support, Link Aggregation Control Protocol (lap), Energy Efficient Ethernet, Class Of Service (cos), Bpdu Filter, Poe Class 4.
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3af, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1ab (lldp), Ieee 802.3at, Ieee 802.3az, Ieee 802.2af
- Switching Capacity: 176 GBPS ¦ Throughput: 130.95 MPPS ¦ Latency (1 GBPS ): 2.2 ?s ¦ Latency (10 GBPS ): 1.2 ?s
- Capacity : Link Aggregation Ports: 8 ¦ Ipv4 Routes (Static): 32 ¦ Vlans
- Supported: 256 ¦ Access Control Entries (Aces) Per Acl: 480 ¦ Packet Buffer
- Jumbo Frame Support: 9216 Bytes
- Routing Protocol: Static IP Routing
- Remote Management Protocol: Snmp 1, Rmon, Snmp 3, Snmp 2c, Http, Https, Tftp, Radius.
- 1 X Arm Cortex-a9: 800 Mhz
- Ram: 512 Mb Sdram
- Flash Memory: 256 MB
- Status Indicators: Port Status, Power, Poe
- 48 X 10/100/1000 Base-T Rj-45 Poe - 370 W
- 4 X 1/10gbit Lan Sfp+
- Power Device: Internal Power Supply
- Voltage Required: Ac 120/230 V (50/60 Hz)
- Power Consumption Operational: 460 Watt
Finally, the HPE JL686A Aruba 1930 Managed Switch stands as a powerful and versatile networking solution. Its combination of PoE support, SFP ports, high switching capacity, and user-friendly management interface makes it well-suited for a variety of networking environments. Whether in a large office, data center, or any other scenario where reliable and scalable networking is essential, the HPE JL686A proves to be a valuable asset. With its feature-rich design, this switch caters to the demands of modern networking, providing organizations with the tools they need for efficient and secure data connectivity.
Here, you can check more available conditions of your desired product JL686A at a competitive price. We are trying our best to meet your needs on the enterprise-level computer, server, data centre, and networking hardware. You are welcome to ask our live chat or get live representative support over the phone.
