Description
Overview about the Brocade 57-0000089-01
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver is a high-speed optical transceiver module used in fiber optic communication systems. It is designed to provide reliable and high-performance data transmission over long distances.
SFP+ Form Factor
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver is based on the Small Form-factor Pluggable Plus (SFP+) form factor. The SFP+ form factor is a popular industry-standard form factor for high-speed optical transceivers used in data communication networks. SFP+ modules are hot-swappable, which means they can be inserted and removed from a network device without shutting down the system. SFP+ modules are also compact and require minimal power, making them ideal for use in high-density networking environments.
Data Rate and Distance
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver supports a data rate of 16 Gigabits per second (Gb/s). This high data rate makes it suitable for use in high-performance data center and enterprise networking applications. The transceiver can transmit data over a distance of up to 10 kilometers using single-mode fiber (SMF). SMF is a type of optical fiber that has a small core diameter, which allows it to transmit data over long distances with minimal signal attenuation.
DDM Functionality
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver also supports Digital Diagnostics Monitoring (DDM) functionality. DDM allows network administrators to monitor the performance of the transceiver in real-time. DDM provides information such as temperature, voltage, and optical power levels, which can be used to troubleshoot network issues and ensure optimal network performance.
1310nm Wavelength
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver operates at a wavelength of 1310nm. The 1310nm wavelength is commonly used in fiber optic communication systems because it provides low attenuation and dispersion in single-mode fiber. This wavelength is also less affected by fiber bends and micro-bending, making it more reliable over long distances.
Duplex LC Connector
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver is equipped with a duplex LC connector. The duplex LC connector is a popular industry-standard connector used in fiber optic communication networks. The connector is designed to allow for easy and reliable connection and disconnection of fiber optic cables. The duplex LC connector has two fibers, one for transmitting data and one for receiving data.
Compatibility
The 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver is compatible with Brocade networking equipment. Brocade is a leading provider of networking equipment, and their equipment is widely used in data centers and enterprise networks. The transceiver is also compatible with other networking equipment that supports the SFP+ form factor.
Overall, the 57-0000089-01 Brocade Duplex SFP+ 16GB 10KM SMF DDM 1310NM Transceiver is a high-performance optical transceiver module that provides reliable and high-speed data transmission over long distances.
Main Specifications about the Brocade 57-0000089-01
- Manufacturer: Brocade
- Part Number or SKU# 57-0000089-01
- Device Type: Transceiver
Key Features
- Brocade 16GFC Fibre Channel SFP+
- Up-To 10 KM Over Smf 14.025gbps
- 1310nm Duplex Sfp+ Transceiver
- 0°C – 70°C Operating Case Temperature
- Sff-8724 Digital Optical Monitoring
- Hot-Swappable For SFP+ FC Ports
- Compliant With Sff-8431 & Sff-8432
