C8R24A is the part number for a 4-pack of HPE MSA 2040 compatible 16GB short wave fibre channel SFP+ transceivers. These transceivers are small form-factor pluggable modules that enable fibre channel communication over optical fibre cables.
Here are the general steps to install and configure these transceivers:
- Physically install the transceivers into the appropriate ports on your HPE MSA 2040 storage array or fibre channel switch. Follow the instructions provided by the manufacturer to properly insert the SFP+ transceivers.
- Connect the optical fibre cables to the SFP+ transceivers. Make sure to use the appropriate type of fibre cables (e.g., multi-mode or single-mode) that match the transceivers and the distance requirements.
- Power on your storage array or switch and check the status of the transceivers. You may need to log in to the management console to verify that the transceivers are properly detected and identified.
- Configure the settings for the fibre channel ports that are using the SFP+ transceivers. This may include setting the speed, mode, zoning, and other parameters depending on your specific environment and requirements.
- Test the connectivity and performance of the fibre channel connections that are using the SFP+ transceivers. You can use various tools and utilities to check the link status, bandwidth, latency, and other metrics.
- Monitor the health and status of the SFP+ transceivers over time. Keep an eye on the error rates, temperature, voltage, and other parameters to ensure that the transceivers are operating within the expected range.
Security Features and Protocols
The C8R24A HPE MSA 2040 16GB Short Wave Fibre Channel SFP+ 4 Pack Transceiver is a small form-factor pluggable (SFP+) transceiver module that provides high-speed connectivity for fiber optic networks. This transceiver has security features and protocols designed to ensure secure and reliable data transmission.
Here are some of the security features and protocols of the C8R24A transceiver:
- Authentication: The C8R24A transceiver supports authentication protocols such as the SFP+ Enhanced Small Form-Factor Pluggable (SFP+ E) Authentication, which provides a secure way to authenticate transceivers and prevent unauthorized access to the network.
- Encryption: The C8R24A transceiver supports encryption protocols such as the Fibre Channel Security Protocol (FC-SP), which provides secure data transmission over the network by encrypting data in transit.
- Digital Diagnostics Monitoring (DDM): The C8R24A transceiver supports DDM, which provides real-time monitoring and reporting of important performance parameters such as temperature, voltage, and power. This allows for proactive maintenance and troubleshooting to ensure optimal network performance.
- Ingress/Egress Filtering: The C8R24A transceiver supports ingress and egress filtering, which prevents unauthorized access to the network by filtering out unwanted traffic.
- Port Security: The C8R24A transceiver supports port security, which allows network administrators to limit access to the network by only allowing authorized devices to connect to the network.
Maintenance and Troubleshooting
C8R24A is a part number for the HPE MSA 2040 16GB Short Wave Fibre Channel SFP+ 4 Pack Transceiver. These transceivers are small form-factor pluggable (SFP+) devices that allow connectivity over fiber optic cables, specifically in short-range applications up to 300 meters.
Maintenance and troubleshooting of these transceivers typically involve the following steps:
- Check for compatibility: Ensure that the transceivers are compatible with the host device and the fiber optic cables being used. Check the specifications of the host device to ensure that it supports the transceiver’s data rate and connector type.
- Check the connections: Verify that the transceivers are properly seated in their slots or ports on the host device. Check the fiber optic cables for proper insertion and secure connections.
- Check for errors: Use the diagnostic tools available in the host device to check for any errors related to the transceivers or fiber optic cables. Errors may indicate faulty transceivers, faulty cables, or issues with the host device’s hardware or software.
- Replace faulty transceivers: If a transceiver is found to be faulty, replace it with a new one. Make sure to follow proper installation procedures and ensure compatibility with the host device.
- Contact support: If troubleshooting does not resolve the issue, contact HPE support for further assistance. They may be able to provide additional diagnostic tools or escalate the issue to an expert technician.
Product Information
- Manufacturer: HPE
- MPN: C8R24A
- Spare Part Number: 717874-001
- Model Number: FTLF8529P3BCV-1H
- Assembly Number: 720999-001
- SKU: C8R24A
- Transceiver Type: SFP+ Transceiver Module
- Form Factor: Plug-in Module
- Packaged Quantity: 4 (Specifications are for Single Item)
Networking
- Cabling Type: Fibre Channel
- Connectivity Technology: Wired
- Data Link Protocol: 16Gb Fibre Channel (Short Wave)
- Data Transfer Rate: 14.025 Gbps
Expansion / Connectivity
- Compatible Slots: 1 x SFP+
- Interfaces: 1 x 16Gb Fibre Channel (Short Wave)
Dimensions
- Height: 3.00 inch
- Width: 5.00 inch
- Depth: 8.00 inch
Compatibility
- HPE Modular Smart Array 2040 10Gb iSCSI Dual Controller SFF Bundle, 2040 Dual Controller SFF Bundle, 2040 FC Dual Controller SFF Bundle, 2040 LFF Disk Enclosure, 2040 SAN Dual Controller LFF Storage, 2040 SAN Dual Controller SFF Bundle, 2040 SAN Dual Controller SFF Storage, 2040 SAS Dual Controller SFF Bundle, 2040 SFF Chassis, 2040 SFF DC-power Chassis
