Description
Overview of the CXP-100G-SR10 100Gigbits Ethernet Transceiver
In the rapidly evolving landscape of networking, the demand for high-speed data transmission has led to the development of advanced technologies, and one such innovation is the CXP-100G-SR10. This comprehensive guide aims to break down the intricacies of the CXP-100G-SR10, focusing on its key features, functionality, and role in facilitating 100 Gigabit Ethernet over multi-mode fiber.
Unveiling the CXP-100G-SR10Definition and Purpose
The CXP-100G-SR10 is a type of transceiver module designed to support 100 Gigabit Ethernet (100GbE) over short distances using multi-mode fiber. It operates at a staggering speed of 100 gigabytes per second (GBPS), making it a crucial component in high-performance networking environments.
Understanding 100 Gigabit Ethernet Optical Fiber Transceiver ModuleEvolution of Ethernet Speeds
The evolution of Ethernet has seen a constant quest for higher speeds to meet the ever-increasing demands of data-intensive applications. From the early days of 10 Mbps Ethernet to the contemporary era of 100 Gigabit Ethernet, the CXP-100G-SR10 plays a pivotal role in pushing the boundaries of data transmission.
Importance of 100GBase-SR10 Standard
The CXP-100G-SR10 adheres to the 100GBase-SR10 standard, which specifies the parameters for 100GbE over multi-mode fiber. This standard ensures interoperability and compatibility across different networking equipment, promoting a seamless integration of the CXP-100G-SR10 into diverse network environments.
Data Rate and Protocol
The CXP-100G-SR10 achieves a data rate of 100GBPS, making it suitable for bandwidth-intensive applications. It operates using the 100 Gigabit Ethernet protocol, a widely adopted standard in modern data centers and networking infrastructure.
Maximum Transmission Distance
With a maximum transmission distance of 100 meters, the CXP-100G-SR10 is well-suited for short-range connections within data centers or high-performance computing environments. The limited distance ensures optimal signal integrity and performance.
Technical Deep DiveSpeed and Performance
The standout feature of the CXP-100G-SR10 is its remarkable speed of 100GBPS. This speed is achieved through advanced signal processing technologies and efficient modulation techniques, enabling the swift and reliable transmission of large volumes of data.
Multi-Mode Fiber Compatibility
Multi-mode fiber is chosen for its ability to carry multiple light rays simultaneously, allowing for increased data capacity. The CXP-100G-SR10’s compatibility with multi-mode fiber makes it suitable for short-distance connections, making it ideal for data centers and high-performance computing environments.
Wavelength and MPO Connector
Operating at a wavelength of 850nm, the CXP-100G-SR10 leverages the unique properties of this spectrum for efficient data transmission over short distances. The MPO connector, short for Multi-Fiber Push-On, facilitates the connection of multiple fibers in a single connector, streamlining the installation process and minimizing cabling complexity.
Use Cases and ApplicationsData Centers
The CXP-100G-SR10 finds widespread application in data centers where high-speed connectivity is essential for seamless operations. Its compatibility with multi-mode fiber allows for efficient data transfer within the confined spaces of a data center.
High-Performance Computing
In high-performance computing environments, where the processing of complex algorithms and massive datasets is common, the CXP-100G-SR10 ensures that data is transmitted at ultra-high speeds, reducing latency and optimizing overall system performance.
Emerging Technologies
As technology continues to advance, new applications and services demand faster data transmission. The CXP-100G-SR10 is well-positioned to meet the requirements of emerging technologies such as augmented reality, virtual reality, and the Internet of Things.
Future Trends and DevelopmentsBeyond 100G
While the CXP-100G-SR10 currently supports 100GbE, the networking landscape is ever-evolving. This section explores potential developments in networking speeds beyond 100G and how the CXP-100G-SR10 might adapt to future requirements.
Integration with Emerging Technologies
The CXP-100G-SR10 is poised to play a significant role in the integration of emerging technologies. Whether it be the adoption of artificial intelligence, edge computing, or 5G networks, the CXP-100G-SR10 provides a foundation for seamless and high-speed data transmission.
Performance and Reliability
The model Cisco 100Gbps 100GBase-SR10 Multi-mode CXP Transceiver Module is designed to provide high-performance and reliable data communication over multi-mode fiber (MMF) cable.
In terms of performance, the CXP-100G-SR10 is capable of transmitting and receiving data at a rate of 100 gigabits per second (100 Gbps), which is significantly faster than previous generations of transceiver modules. The module is also compliant with the 100 Gigabit Ethernet (100 GbE) standard, which is the industry standard for high-speed data communication.
In terms of reliability, this item is designed to meet or exceed industry standards for optical transceiver modules. It is manufactured using high-quality components and is tested to ensure it meets the specified performance and reliability requirements. The module also has built-in diagnostic capabilities which can help identify and diagnose any issues that may occur during operation.
Additionally, the CXP form factor is designed to be used in high-density, high-speed environments such as data centers and high-performance computing environments. This form factor is known for its compact and energy-efficient design, which can help to improve the overall reliability of the module by reducing the risk of damage or failure due to heat or other environmental factors.
Compliant Standards
The CXP-100G-SR10 Cisco 100Gbps 100GBase-SR10 Multi-mode CXP Transceiver Module is compliant with some industry standards, which ensure that it is capable of performing to a certain level of quality and interoperability with other devices. Some of the standards that this module complies with are:
- IEEE 802.3bm: This is the standard for 100 Gigabit Ethernet over multi-mode fiber (MMF), which this item is designed to support.
- RoHS: This stands for Restriction of Hazardous Substances Directive, which is a European Union directive that limits the use of certain hazardous substances in electrical and electronic equipment.
- SFF-8472: This is a specification for a digital diagnostic monitoring interface for transceiver modules. This standard includes a set of diagnostic parameters and management functions that allow the host device to monitor the module’s status and performance.
- MSA: The Multi-Source Agreement (MSA) is a set of standards that specify the mechanical, electrical, and optical specifications for transceiver modules. The model is compliant with the CXP4 Multi-Source Agreement (MSA) which is an industry standard for this type of transceiver module.
- TIA-942: This is a standard for data center infrastructure, which defines the requirements for data center design, including cabling, power, and cooling.
- UL: The Underwriters Laboratories (UL) is an American safety consulting and certification company. UL is a safety science organization that tests and certifies various products to ensure they meet safety standards.
General Information of the Cisco CXP-100G-SR10 CXP Transceiver Module
- Manufacturer: Cisco
- Model Number or SKU# CXP-100G-SR10
- Device Type: CXP Transceiver Module
- Form Factor: Plug-in Module
Technical Information for 100 GBPS Transceiver
- Media Type Supported: Optical Fiber
- Fiber Mode Supported: Multi-mode
- Data Transfer Rate: 100 GBPS
- Ethernet Technology: 100 Gigabit Ethernet
- Network Technology: 100GBase-SR10
- Connectivity Technology Wired
- Cabling Type: 100GBase-SR10
- Optical Wave Length: 850 nm
- Application/Usage: Optical Network, Data Networking
Expansion / Connectivity of Transceiver Module
- Interfaces: 1 x Ethernet 100GBase-SR10 – MPO Multi-Mode
Compatibility
- Compliant Standards: IEEE 802.3ba
- P/N: N5696-M4C, N6K-C6001-64P, N6K-C6001-64P=, N6K-C6001-64T, NC6-10X100G-L-P, NC6-10X100G-M-P
In short, the CXP-100G-SR10 represents a milestone in the realm of networking, bringing forth a solution that addresses the need for high-speed data transmission over short distances. Its compatibility with multi-mode fiber, adherence to industry standards, and remarkable speed make it a go-to choice for various applications, from data centers to emerging technologies. As technology continues to advance, the CXP-100G-SR10 is likely to remain a key player in shaping the future of high-performance networking.
