Description
Understanding the 32 Ports SFP+ 10 Gigabit Ethernet Fabric Extender Module
Introduction: The N2K-C2232PF-10GE is a crucial component of the Nexus 2000 Series, designed to enhance network capabilities through its 32-ports + 8 Uplink Ports Small Form-Factor Pluggable Plus (SFP+) 10 Gigabit Ethernet Fabric Extender Expansion Module. This module comes equipped with 2 AC Power Supply units and 1 Fan Module, contributing to its robust performance and reliability in diverse networking environments.
Overview of Nexus 2000 Series 32 Ports Fabric Module
The Nexus 2000 Series is a family of fabric extenders that provide flexible and scalable connectivity solutions for modern data center networks. These fabric extenders play a pivotal role in expanding the reach and efficiency of Ethernet networks, and the N2K-C2232PF-10GE is a standout model within this series.
Technical Specifications of Cisco N2K-C2232PF-10GE 32 Ports Fabric Extender Ports and Uplink Ports
The N2K-C2232PF-10GE boasts 32 Ports, ensuring ample connectivity for various devices within the network. Additionally, it features 8 Uplink Ports with Small Form-Factor Pluggable Plus (SFP+) technology, supporting high-speed 10 Gigabit Ethernet connections for seamless data transfer.
Fabric Extender Expansion Module
As a fabric extender, this module enhances the network’s fabric by providing additional ports and connectivity options. It acts as a bridge between end devices and the parent switch, enabling efficient communication and data flow within the network.
AC Power Supply
The inclusion of 2 AC Power Supply units ensures reliable and redundant power sources, minimizing the risk of downtime due to power failures. This feature is crucial for maintaining continuous network operations in mission-critical environments.
Fan Module
The module incorporates a dedicated Fan Module to regulate temperature and prevent overheating. This not only ensures optimal performance but also extends the lifespan of the hardware components, contributing to the overall longevity and reliability of the Nexus 2000 Series.
Key Features for SFP+ 10 Gigabit Ethernet Fabric Extender Plug-and-Play
The N2K-C2232PF-10GE is designed for ease of installation with a plug-and-play setup. This simplifies the deployment process, allowing network administrators to quickly integrate the module into their existing infrastructure without extensive configuration requirements.
Scalability
With 32 Ports and 8 Uplink Ports, this fabric extender offers scalability to accommodate the growing needs of a network. Whether in a small or large-scale environment, the N2K-C2232PF-10GE provides flexibility for expanding network connectivity as demand increases.
High-Speed Connectivity
The 10 Gigabit Ethernet support through Small Form-Factor Pluggable Plus (SFP+) technology ensures high-speed data transfer, meeting the bandwidth requirements of modern applications and facilitating efficient communication between devices.
Redundancy for Reliability
The inclusion of dual AC Power Supply units and a dedicated Fan Module adds redundancy to the system. This redundancy not only enhances reliability but also safeguards against potential hardware failures, ensuring uninterrupted network operations.
Use Cases of 10 Gigabit Ethernet Fabric Extender Expansion ModuleData Centers
The N2K-C2232PF-10GE is well-suited for data center environments where high-performance networking is crucial. Its scalability and high-speed connectivity make it an ideal choice for connecting servers, storage devices, and other critical components within a data center infrastructure.
Enterprise Networks
In enterprise settings, where a reliable and scalable network is essential for day-to-day operations, this fabric extender module provides the necessary features to support diverse connectivity requirements. Its plug-and-play installation makes it particularly convenient for network expansions in corporate environments.
Telecommunication Networks
Telecommunication networks, with their increasing demand for high-speed data transfer, benefit from the N2K-C2232PF-10GE’s 10 Gigabit Ethernet support. The module’s redundancy features make it a reliable choice for telecommunications infrastructure where uptime is a critical factor.
Advanced Networking Features
The N2K-C2232PF-10GE Cisco Nexus 32 Ports Fabric Extender Expansion Module supports several advanced networking features that can enhance network performance, security, and manageability. Here are some of the key advanced networking features supported by the device:
- Virtual Port Channels (vPC): The N2K-C2232PF-10GE supports vPC, which allows two upstream switches to be configured as a single logical switch. This provides redundancy and increases bandwidth by allowing traffic to be load-balanced across both switches.
- Quality of Service (QoS): The N2K-C2232PF-10GE supports QoS, which allows network administrators to prioritize traffic based on its importance or criticality. This can help ensure that critical applications or services receive the necessary network resources to operate effectively.
- Multicast: The N2K-C2232PF-10GE supports multicast routing protocols, which enable efficient distribution of multicast traffic to multiple recipients. This can be useful for applications such as video conferencing or streaming media.
- Access Control Lists (ACLs): The N2K-C2232PF-10GE supports ACLs, which provide a mechanism for filtering traffic based on criteria such as source or destination IP addresses, ports, or protocols. This can be useful for restricting access to certain network resources or preventing malicious traffic from entering the network.
- Port Security: The N2K-C2232PF-10GE supports port security, which allows network administrators to limit the number of devices that can connect to a given port. This can help prevent unauthorized access to the network.
- Spanning Tree Protocol (STP): The N2K-C2232PF-10GE supports STP, which provides a mechanism for preventing network loops by blocking redundant paths in the network. This can help ensure network stability and reliability.
- Link Aggregation Control Protocol (LACP): The N2K-C2232PF-10GE supports LACP, which allows multiple physical links between two switches to be combined into a single logical link. This provides redundancy and increases bandwidth.
By supporting these advanced networking features, the N2K-C2232PF-10GE Cisco Nexus 32 Ports Fabric Extender Expansion Module can provide network administrators with greater control over their network infrastructure and improve network performance, security, and manageability. It is important to consult the Cisco documentation and follow best practices when configuring and using these features to ensure optimal network performance and reliability.
General Information for Cisco N2K-C2232PF-10GE Nexus 2000 Fabric Extender
- Manufacturer: Cisco
- Model Number or SKU: N2K-C2232PF-10GE
- Product Line: Nexus
- Product Series: 2000
- Product Name: Nexus 2000 Fabric Extender
- Product Type: Fabric Extender
Technical Specifications of 10 Gigabits Expansion Module
- Number of Ports: 32
- Data Link Protocol: 10 Gigabit Lan, FCoE
- Auxiliary Ports: 8 x SFP+ (uplink)
- Form Factor: Rack-mountable
- Connectivity Technology: Wired
Power Details
- Power Device: Power Supply – Hot-plug / Redundant – Plug-in Module
- Voltage Required: AC 120/230 V (50/60 Hz)
- Power Consumption Operational: 270 Watts
Features & Protocol
- Network/Transport Protocol: TCP/IP, UDP/IP, ICMP/IP
- Remote Management Protocol: SNMP 1, SNMP 2, RMON, SNMP 3
- Status Indicators: Port Status, Power, System
- Features: Flow Control, Uplink, Auto-negotiation, VLAN Support, IGMP Snooping, Syslog Support, Weighted Round Robin (WRR) Queuing, Spanning Tree Protocol (STP) Support, Access Control List (ACL) Support, Quality of Service (QoS), Jumbo Frames Support
- Compliant Standards: IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3ae
- Expansion Slot(s): 40 (total) / 24 (free) x SFP+
Finally, the N2K-C2232PF-10GE Nexus 2000 Series 32 Ports + 8 Uplink Ports SFP+ 10 Gigabit Ethernet Fabric Extender Expansion Module with 2 AC Power Supply and 1 Fan Module stands as a versatile and robust solution for enhancing network capabilities. Its technical specifications, key features, and diverse use cases make it a valuable component in building efficient and reliable networking infrastructures for various applications. Whether in data centers, enterprises, or telecommunication networks, this fabric extender module provides the necessary scalability, high-speed connectivity, and redundancy to meet the demands of modern networking environments.
