Description
Overview of the Cisco ONS-CXP-100G-SR10
The ONS-CXP-100G-SR10 is a transceiver module from Cisco Systems that provides 100 Gbps Ethernet connectivity. It is part of the 100GBASE-SR10 standard for 100 Gbps optical communication and is designed to work over multimode fiber.
The “ONS” in the product name stands for “Optical Networking System”, while “CXP” stands for “CXP-12” which is a type of transceiver connector. The “100G” in the name indicates the data rate of 100 Gbps and “SR10” stands for “Short Reach 10 km”, indicating the maximum distance over which this transceiver can transmit data.
This transceiver has a Commercial Temperature rating, meaning it is designed to operate in an environment with temperatures between 0 and 70°C. The “TEMP” in the product name indicates that it is a Commercial Temperature rated transceiver.
Purpose of a Transceiver Module
A transceiver module, like the Cisco ONS-CXP-100G-SR10, is a crucial component in networking equipment. It combines the functions of both a transmitter and a receiver, enabling the transmission of data over communication networks. This module is particularly designed for high-speed data transfer in networking environments.
Understanding the Technical Specifications100 Gigabytes Per Second (GBPS)
- High-Speed Data Transfer: The Cisco ONS-CXP-100G-SR10 supports an impressive speed of 100 Gigabytes per second. This high data transfer rate is vital for swiftly transmitting large volumes of data in networking applications.
100GBase-SR
- 100GBase-SR Standard: This indicates that the transceiver module adheres to the 100GBase-SR standard, which defines the specifications for 100 Gigabit Ethernet over short distances using multi-mode fiber optics.
Multi-mode Fiber
- Fiber Type Compatibility: The module is designed to work with multi-mode fiber optics. Multi-mode fibers are commonly used for shorter-distance communication within data centers and similar environments.
860nm Wavelength
- Wavelength Specification: The transceiver module operates at a wavelength of 860nm. Wavelength is a critical parameter in optical communication, and this specific wavelength ensures efficient data transmission.
Commercial Temperature
- Temperature Range: The module is built to operate within the commercial temperature range. This makes it suitable for deployment in standard environmental conditions typically found in commercial settings.
Low Current (LC) Connector
- Connector Type: The module features a Low Current (LC) connector. Connectors are vital for ensuring a secure and efficient connection between networking devices.
CXP Form Factor
- Compact Form Factor: The module follows the CXP form factor. CXP is a standardized form factor for high-density optical transceivers, providing a compact design suitable for various networking applications.
Importance of 100GBase-SR and Multi-mode Fiber in NetworkingHigh-Speed Networking
- 100GBase-SR is a standard specifically designed for high-speed networking applications, ensuring seamless communication at 100 Gigabits per second.
Short-Distance Connectivity
- Multi-mode fiber optics are well-suited for shorter-distance communication, making them ideal for connections within data centers and other confined spaces.
Scalability and Future-Proofing
- Adhering to the 100GBase-SR standard ensures scalability and future-proofing, allowing networks to evolve and accommodate increasing data demands.
Application in Networking EnvironmentsData Centers
- The Cisco ONS-CXP-100G-SR10 is well-suited for deployment in data centers, where high-speed data transfer and short-distance connectivity are crucial for efficient operations.
High-Performance Networks
- In networks requiring top-tier performance, such as those in enterprises or telecommunications, this transceiver module plays a key role in ensuring rapid data transmission.
Benefits of Cisco ONS-CXP-100G-SR10 Transceiver ModuleHigh-Speed Data Transfer
- The module’s 100 GBPS capability ensures rapid data transfer, facilitating quick and efficient communication within the network.
Compatibility and Standardization
- Adhering to the 100GBase-SR standard ensures compatibility with other devices following the same standard, promoting seamless integration into existing networks.
Versatile Connectivity
- The use of multi-mode fiber optics makes the module versatile, allowing for deployment in various networking scenarios, especially those involving shorter-distance communication.
Features and Benefits of Transceiver
The ONS-CXP-100G-SR10 is a Cisco 100Gbps 100GBASE-SR commercial temperature transceiver. Here are some of its key features and benefits:
Features:
- 100 Gbps Data Rate: The transceiver supports 100Gbps data rate, which is ideal for high-speed data transfer and bandwidth-intensive applications.
- 100GBASE-SR Form Factor: It is compliant with the 100GBASE-SR standard and supports both short-range (up to 100 meters) and multimode fiber.
- Commercial Temperature Range: The commercial temperature range (0°C to 70°C) makes it suitable for use in a variety of data center and enterprise environments.
- Digital Optical Monitoring (DOM): The transceiver supports Digital Optical Monitoring (DOM), which provides real-time optical transceiver diagnostics and monitoring.
- MSA Compliance: It is compliant with Multi-Source Agreement (MSA) standards, ensuring interoperability with other MSA-compliant devices.
Benefits:
- High-Speed Data Transfer: With a 100Gbps data rate, the transceiver enables fast and reliable data transfer, making it ideal for high-bandwidth applications such as big data analytics, cloud computing, and virtualized environments.
- Improved Network Efficiency: The 100GBASE-SR form factor helps improve network efficiency by providing a high-speed and high-density solution for data center and enterprise networks.
- Easy Deployment: The commercial temperature range and MSA compliance make the transceiver easy to deploy and integrate into existing networks.
- Reliable Operations: The Digital Optical Monitoring (DOM) feature enables real-time monitoring of transceiver performance, helping to ensure reliable and stable network operations.
- Cost-Effective Solution: The ONS-CXP-100G-SR10 provides a cost-effective solution for high-speed data transfer, making it a great choice for organizations looking to upgrade their networks to 100Gbps.
Connecting to the Network
To connect to the Network of ONS-CXP-100G-SR10 Cisco 100Gbps 100GBASE-SR Commercial TEMP Transceiver, you will need to follow these steps:
- Verify that the equipment you have is compatible with the ONS-CXP-100G-SR10 transceiver. You need to have a Cisco switch or router that supports 100Gbps and CXP connections.
- Check that your switch or router is configured for 100Gbps connectivity. Some switches or routers require software or firmware upgrades to support 100Gbps connections.
- Connect the transceiver to the switch or router using a CXP optical cable. The cable should be inserted into the CXP port of the transceiver and the CXP port of the switch or router.
- Ensure that both the transceiver and the switch or router are powered on.
- The connection should automatically be detected by the switch or router and should start working immediately. If the connection is not automatically detected, you may need to configure the switch or router manually to enable 100Gbps connectivity.
- You can verify the connection by checking the switch or router’s status or by pinging another device on the network.
General Information about this Cisco ONS-CXP-100G-SR10
- Manufacturer: Cisco
- Model Number or SKU# ONS-CXP-100G-SR10
- Product Name: CXP Module
- Product Type: CXP
Technical Information
- Application/Usage: Optical Network
- Application/Usage: Data Networking
Interfaces/Ports
- Interfaces/Ports Details: 1 x 100GBase-SR10 Network
Media & Performance
- Media Type Supported: Optical Fiber
- Fiber Mode Supported: Multi-mode
- Ethernet Technology: 100 Gigabit Ethernet
- Network Technology: 100GBase-SR10
In summary, the Cisco ONS-CXP-100G-SR10 100GBase-SR Multi-mode Fiber CXP Transceiver Module stands as a vital component in high-performance networking environments. Its impressive data transfer speed, compatibility with industry standards, and versatility in connectivity make it an essential choice for organizations seeking efficient and reliable networking solutions.
