Description
Product overview for the Cisco QSFP-H40G-ACU10M
In the world of networking and data transmission, the QSFP-H40G-ACU10M is a critical component that plays a crucial role in ensuring high-speed data transfer. This 10-meter Direct-Attach Copper (DAC) Active Twinaxial Network Cable, often referred to simply as the QSFP-H40G-ACU10M cable, is designed to facilitate the rapid exchange of data between devices in a network. In this comprehensive guide, we will delve into the details of this cable, exploring its key features, applications, benefits, and how it contributes to efficient data transmission.
What is the QSFP-H40G-ACU10M Cable
The QSFP-H40G-ACU10M is a specific type of network cable designed to connect various networking equipment, such as switches, routers, and servers, in high-performance data centers and enterprise environments. Its name breaks down as follows:
QSFP: This stands for Quad Small Form-factor Pluggable, which refers to the type of connector used in the cable. QSFP connectors are known for their compact size and high data transmission capabilities.
H40G: This part of the name indicates that the cable is designed for 40 Gigabit Ethernet (40GbE) applications. In other words, it’s capable of transferring data at a speed of 40 gigabits per second (Gbps).
ACU10M: ACU stands for Active Copper Cable, implying that this cable is an active twinaxial copper cable. The “10M” specifies the cable’s length, which is 10 meters.
40GBASE-CR4: This is another way of indicating that the cable is designed for 40GbE applications. The “CR4” refers to the electrical interface, which is used for 40GbE over copper connections.
Now that we understand the name and its components, let’s dive deeper into the various aspects of this cable.
Key Features of the QSFP-H40G-ACU10M Cable
The QSFP-H40G-ACU10M cable comes with several key features that make it a popular choice for high-speed networking applications:
High Data Transfer Rate: As mentioned earlier, this cable is designed for 40GbE applications, which means it can transmit data at an impressive rate of 40 gigabits per second. This high data transfer rate is essential for data centers and networks that require rapid data exchange.
Active Twinaxial Cable: The “ACU” in its name indicates that this cable is an active twinaxial cable. Active cables have built-in signal processing electronics that help maintain signal integrity over longer distances. Twinaxial cables consist of two inner conductors surrounded by insulation and a shield. This design minimizes signal interference and enhances data transmission quality.
10-Meter Length: The 10-meter length of this cable provides flexibility in network design and allows for efficient data transmission over moderate distances. It’s suitable for connecting devices within the same rack or adjacent racks in a data center.
QSFP Connector: The QSFP connector is known for its compact size, which helps save space in networking equipment. Additionally, it’s hot-swappable, meaning it can be plugged and unplugged without powering down the connected devices.
40GBASE-CR4 Compatibility: The cable is specifically designed for 40GBASE-CR4 applications. 40GBASE-CR4 is a standard for 40GbE over copper connections, and this cable meets its requirements for reliable data transmission.
Active Electronics: The active electronics in this cable help compensate for signal loss, ensuring that the data signal remains strong and clear even over longer distances. This is particularly important in data centers where devices may be located some distance apart.
Applications of the QSFP-H40G-ACU10M Cable
The QSFP-H40G-ACU10M cable finds applications in a wide range of networking scenarios due to its high-speed data transfer capabilities and other features. Some of its primary applications include:
Data Centers: Data centers are the nerve centers of modern businesses, housing servers, storage systems, and networking equipment. The QSFP-H40G-ACU10M cable is commonly used in data centers to connect servers to switches or routers, facilitating the fast exchange of data between various components.
High-Performance Computing (HPC): In HPC environments, where massive computational power is required, fast data transfer is essential. This cable is used to connect high-performance servers and workstations to the network, ensuring that data can flow seamlessly to support complex calculations and simulations.
Enterprise Networks: Large enterprises often require high-speed network connections to support their day-to-day operations. The QSFP-H40G-ACU10M cable can be used to connect switches and routers in enterprise networks, providing the bandwidth needed for efficient communication.
Telecommunications: Telecommunication providers use high-speed cables like the QSFP-H40G-ACU10M in their infrastructure to support the transfer of large volumes of data, including voice, video, and internet traffic.
Cloud Computing: In cloud computing environments, where virtual servers and resources are accessed remotely, the QSFP-H40G-ACU10M cable helps maintain fast and reliable connections between servers and the cloud infrastructure.
Benefits of Using the QSFP-H40G-ACU10M Cable
Choosing the QSFP-H40G-ACU10M cable for your networking needs offers several notable benefits:
High Speed: The cable’s 40GbE capability ensures that data can be transferred quickly, reducing latency and improving overall network performance.
Reliability: The active electronics and twinaxial design of the cable enhance signal integrity, reducing the risk of data transmission errors or packet loss.
Flexibility: With a 10-meter length, this cable provides flexibility in network design and deployment. It’s suitable for both short-range and moderate-range connections.
Compatibility: The cable is designed to meet the 40GBASE-CR4 standard, ensuring compatibility with a wide range of networking equipment and devices.
Space Savings: The compact QSFP connector helps save space in networking equipment, which can be crucial in densely populated data center environments.
Hot-Swappable: The hot-swappable nature of the QSFP connector allows for easy installation and replacement without interrupting network operations.
Cost-Effective: Considering its high data transfer rate and reliability, the QSFP-H40G-ACU10M cable provides a cost-effective solution for high-speed networking needs.
How the QSFP-H40G-ACU10M Cable Works
To understand how the QSFP-H40G-ACU10M cable works, it’s essential to grasp the basics of data transmission in a network.
Data Transmission: In a network, data is transmitted in the form of electrical signals or light pulses, depending on the type of cable and equipment used. In the case of the QSFP-H40G-ACU10M cable, it transmits electrical signals.
Connector Interface: The QSFP connector at each end of the cable is connected to the respective ports
General Information about this Cisco QSFP-H40G-ACU10M
Manufacturer: Cisco
Part Number (SKU#): QSFP-H40G-ACU10M
Product Type: Direct Attach Cable
Technical Details of Cisco Direct Attach Cable
Cable Type: Twinaxial
Cable Length: 10 Meters
Connector on First End: SFF-8436 QSFP+
Connector on Second End: SFF-8436 QSFP+
Device Supported: Network Device
The Cisco QSFP-H40G-ACU10M is a direct attach cable designed for use with network devices. It is a 10-meter long cable with twinaxial wiring, featuring SFF-8436 QSFP+ connectors on both ends. This cable is intended for connecting and supporting network equipment.
