Description
The Key Components of Network Processing Engine
The UBR7200-NPE-G2 is a network processing engine (NPE) developed by Cisco Systems. It is a critical component in the company’s Universal Broadband Router (UBR) platform.
- Processor: The UBR7200-NPE-G2 has a powerful processor that runs the IOS (Internetwork Operating System) software, which provides the routing and switching functionality of the device.
- Memory: The device has a large amount of memory to store routing tables, configuration files, and network data. This memory is essential for the router’s performance and stability.
- Interfaces: The UBR7200-NPE-G2 has multiple interfaces that provide connectivity to other network devices, such as routers, switches, and modems. It also provides the ability to connect to multiple network topologies, such as Ethernet, T1/E1, and ATM.
- Power Supply: The UBR7200-NPE-G2 has a redundant power supply to ensure that the device remains operational even in the event of a power failure. This feature is essential for mission-critical networks where downtime is not an option.
- Management Interface: The device has a management interface that provides a secure and easy-to-use interface for configuring, monitoring, and maintaining the router. This interface is critical for network administrators to manage the network effectively.
- Network Security: The UBR7200-NPE-G2 provides network security features, such as firewalls, VPNs, and access control lists, to secure the network against unauthorized access and attacks.
The Advantages of Network Processing Engine
- Increased Performance: The UBR7200-NPE-G2 provides a significant increase in performance compared to previous models, which is essential for high-bandwidth applications and large networks.
- Scalability: The network processing engine is designed to accommodate future network growth, making it easy to add new services and capabilities.
- Advanced Features: The UBR7200-NPE-G2 offers a wide range of advanced features, including Quality of Service (QoS), Virtual Private Network (VPN) support, and advanced security features.
- Improved Reliability: The network processing engine has been designed with reliability in mind, with features such as redundant power supplies, automatic failover, and hot-swappable components.
- Ease of Use: The UBR7200-NPE-G2 is easy to install, configure and manage, reducing the burden on IT teams and improving the overall efficiency of the network.
- Cost-Effective: The network processing engine offers a cost-effective solution for organizations looking to upgrade their network infrastructure without breaking the bank.
- Cisco Integration: As a part of the Cisco product line, the UBR7200-NPE-G2 integrates seamlessly with other Cisco products, providing a seamless, integrated solution for customers.
Impact on Network Performance
The UBR7200-NPE-G2 Cisco Network Processing Engine (NPE) is a network device that is designed to enhance the performance of the Cisco 7200 series routers. The device provides the necessary processing power to support advanced routing features, such as Quality of Service (QoS), traffic management, and security.
The impact of the UBR7200-NPE-G2 on network performance can be significant, as it can enhance the overall efficiency and scalability of the network. Some of the key ways in which the NPE can impact network performance are as follows:
- Increased Routing Performance: The NPE provides enhanced routing performance, enabling the router to handle more complex network configurations, including large-scale routing tables and multiple VPNs. This leads to faster route lookups and improved routing stability.
- Improved QoS: The NPE supports advanced QoS features, such as differentiated services (DiffServ), traffic policing, and traffic shaping, which help to optimize network bandwidth utilization and ensure that critical applications receive the necessary bandwidth and priority.
- Enhanced Security: The NPE provides advanced security features, such as firewalls, intrusion prevention, and VPNs, to protect against network threats and protect sensitive information.
- Improved Traffic Management: The NPE supports advanced traffic management features, such as policy-based routing, traffic classification, and congestion management, which help to optimize network traffic flow and ensure that critical applications receive the necessary bandwidth and priority.
General Information
- Manufacturer: Cisco Systems, Inc
- MPN: UBR7200-NPE-G2
- Product Name: UBR7200-NPE-G2 Network Processing Engine
- Product Type: Network Processing Engine
Technical Information
- Application/Usage Wide Area Network
Interfaces / Ports:
- Interfaces/Ports Details 1 x Auxiliary Management
- Interfaces/Ports Details 1 x Console Management
- Interfaces/Ports Details 1 x RJ-45 10/100Base-TX Management
- Interfaces/Ports Details 2 x USB
- Interfaces/Ports Details 3 x RJ-45 10/100/1000Base-T
Performance
- Media Type Supported : Twisted Pair
- Ethernet Technology: Fast Ethernet
- Ethernet Technology Gigabit Ethernet
- Network Technology 10/100/1000Base-T
- Network Technology 10/100Base-TX
- Maximum Data Transfer Rate: 100
I/O Expansions:
- Number of Total Expansion Slots: 4
- Expansion Slot Type: SFP (mini-GBIC)
Miscellaneous
- Compatibility:
- Performance of up to 1.3 Million Packets per Second (Mpps) in Cisco Express Forwarding Switching
- Digital Diagnostics on SFP Interfaces
- Time Domain Reflectometry (TDR) on Copper Interfaces
- Support for Third Peripheral-Component-Interconnect (PCI) Bus to the I/O Controller Slot
- 1-GB default DRAM
- 256-MB default flash memory
- Cisco uBR7200 Series Universal Broadband Routers
Dimensions & Weight
- Width: 15.2 inch
- Depth: 11.1 inch
- Height : 1.4 inch
- Weight: 3.31 lbs
