Description
Performance Monitoring and TroubleshootingUCS-EP-MDS9148S-1 is a performance monitoring and troubleshooting tool for the Cisco MDS 9148S Fiber Channel switch. It provides visibility into the performance of the switch and helps in identifying and resolving any issues. The tool allows administrators to monitor switch performance metrics such as bandwidth utilization, error rates, and resource utilization. Additionally, it provides real-time alerts for critical events and facilitates troubleshooting by allowing for detailed analysis of switch logs and statistics. The tool also supports the configuration of thresholds and alerts, enabling proactive monitoring and resolution of potential issues before they become major problems. With its comprehensive monitoring and troubleshooting capabilities, UCS-EP-MDS9148S-1 helps ensure the reliability and optimal performance of the Cisco MDS 9148S Fiber Channel switch.High Availability and Redundancy Options
UCS-EP-MDS9148S-1 is a performance monitoring and troubleshooting tool for the Cisco MDS 9148S Fiber Channel switch. It provides visibility into the performance of the switch and helps in identifying and resolving any issues. The tool allows administrators to monitor switch performance metrics such as bandwidth utilization, error rates, and resource utilization. Additionally, it provides real-time alerts for critical events and facilitates troubleshooting by allowing for detailed analysis of switch logs and statistics.
Network Scalability and Flexibility
The UCS-EP-MDS9148S-1 Cisco MDS 9148S Fiber Channel switch supports high availability and redundancy options to ensure continuous operation and minimize downtime. Some of these options include:
- Redundant Power Supplies: The switch supports redundant power supplies to ensure continuous operation even in case of a power supply failure.
- Fabric Shortest Path First (FSPF): The switch uses the FSPF protocol to dynamically route data in the network, providing automatic failover in case of link failures.
- Virtual SAN (VSAN): The switch supports multiple virtual storage area networks (VSANs) that can be used to isolate storage traffic and provide redundancy at the storage level.
- Port Channeling: The switch supports port channeling, which allows multiple physical ports to be grouped together to increase bandwidth and provide redundancy.
- Dual-Active Detection: The switch supports dual-active detection to ensure that only one switch in a pair is active at any given time, preventing data loss and ensuring high availability.
These high availability and redundancy options help ensure the reliability and uptime of the Cisco MDS 9148S Fiber Channel switch and support mission-critical applications and storage environments.
General Information
- Manufacturer Cisco Systems, Inc
- Manufacturer Part Number UCS-EP-MDS9148S-1
- Brand Name Cisco
- Device Type Switch – 48 ports – managed
Key Features
- Enclosure Type Rack-mountable 1U
- Subtype Fibre Channel
- Ports 12 x 8Gb Fibre Channel
- Fibre Channel FC-DA, FC-FLA, FC-FS, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PLDA, FC-SB-2, FC-SB-3, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-4, FC-BB-2, FCP, FCP-2, FC-PI-2, FC-BB-5, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FCP-3, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5, FC-BB-4, FC-IFR, FAIS, FAIS-2, FC-PI-5, FC-LS-2, FC-SP-2, FC-SB-4, FC-DA-2, FC-MI-3, FC-MSQS, FC-BB-6
- Remote Management Protocol RMON, SNMP 3, HTTP, SMI-S, SSH-2, CLI
- Encryption Algorithm AES
- Authentication Method RADIUS, TACACS+, Secure Shell v.2 (SSH2), LDAP, Active Directory
- Features Auto-sensing per device, ISL support, Virtual Route Redundancy Protocol (VRRP) support, Access Control List (ACL) support, Quality of Service (QoS), back to front airflow, Remote Switch Port Analyzer (RSPAN), role based access control, Registered State Change Notification (RSCN) support, SFTP client
Expansion / Connectivity
- Interfaces-
- 1 x 1000Base-T RJ-45 management
- 1 x serial (RS-232) RJ-45 management
- 1 x USB Type A
- 12 x 8Gb Fibre Channel LC multi-mode x 2
- 36 x 16Gb Fibre Channel SFP+ Ports on Demand
Power
- Power Device Internal power supply – hot-plug
- Installed Qty 2 (installed) / 2 (max)
- Power Redundancy Yes
- Power Redundancy Scheme 1+1
- Power Provided 300 Watt
- Voltage Required AC 120/230 V (50/60 Hz)
Compliant Standards
- CISPR 22 Class A, EN 60950, EN 61000-3-2, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, EN 61000-6-1, ACA TS001, AS/NZS 3260, EMC, ICES-003 Class A, FIPS 140-2, FCC CFR21 Part 1040, EN 60825, IEC 60825, CAN/CSA C22.2 No. 60950
- Software / System Requirements
- Software Included Cisco Data Center Network Manager (DCNM) for SAN Advanced Edition, Cisco MDS 9000 Family Enterprise Package
