Product Overview of the Cisco WS-C3560X-24T-S 24 Ports Ethernet Switch
The WS-C3560X-24T-S is a Cisco Catalyst 3560-X series switch that is designed for enterprise-class access and distribution layer network deployments. This switch features 24 Gigabit Ethernet ports, which provide high-speed connectivity for wired devices in the network. This feature provides network administrators with the flexibility to manage the switch remotely and network issues as they arise. The WS-C3560X-24T-S supports advanced features such as Quality of Service (QoS) which allows for prioritizing different types of traffic to ensure that critical applications receive the bandwidth they need. Additionally, the switch supports security features that enable network administrators to secure their network from potential threats.
Power over Ethernet (PoE) is also supported, which allows for powering devices such as IP phones and wireless access points directly from the switch, eliminating the need for additional power supplies.
Key Features of Cisco WS-C3560X-24T-S Catalyst Switch24 Port
The WS-C3560X-24T-S switch boasts
24 ports, supporting 10/100/1000Base-T RJ-45 interfaces. This versatile port configuration accommodates a wide range of devices, from legacy systems with lower bandwidth requirements to modern, high-speed devices.
Universal Serial Bus (USB) Port
The inclusion of a Universal Serial Bus (USB) port enhances the switch’s connectivity options. USB ports are valuable for various purposes, including firmware upgrades, configuration backup, and the connection of external storage devices.
Layer 3 Capabilities
The switch operates at Layer 3 of the OSI model, providing advanced routing capabilities. Layer 3 switches can make dynamic routing decisions, improving network efficiency and facilitating communication between different subnets.
Rack-Mountable Design
The Cisco WS-C3560X-24T-S is designed to be rack-mountable, allowing for efficient use of space in data center environments. The 1U form factor ensures that it occupies minimal vertical space, making it suitable for various rack configurations.
Ethernet Expansion Slot
This switch comes equipped with a 1x Expansion Slot, providing flexibility for future expansion or customization. The expansion slot can be utilized for additional interfaces or modules, tailoring the switch to specific networking requirements.
Manageability
With 24 manageable ports, the switch offers a high degree of control over network traffic. Administrators can configure and monitor individual ports, implement security measures, and optimize the network for performance and reliability.
Scalability
The Catalyst 3560-X Series is known for its scalability, making it suitable for growing networks. Whether your organization is expanding or undergoing a digital transformation, these switches can seamlessly integrate into your network infrastructure.
Applications and Use CasesEnterprise Networks
The Cisco WS-C3560X-24T-S is an ideal choice for medium to large enterprises. Its robust feature set and scalability make it suitable for serving as the backbone of the network, connecting various departments, and handling diverse workloads.
Data Centers
In data center environments, where space is often at a premium, the rack-mountable design of the switch proves advantageous. The 1U form factor allows for efficient use of rack space, enabling data center managers to optimize the layout for better airflow and accessibility.
Telecommunication Networks
Telecommunication service providers can leverage the switch’s high-speed ports and Layer 3 capabilities to facilitate the seamless flow of data across their networks. The scalability of the Catalyst 3560-X Series is particularly advantageous in the dynamic and evolving telecommunications sector.
Advanced Routing and Switching
The WS-C3560X-24T-S Cisco Catalyst 3560-X series switch supports advanced routing and switching capabilities that provide improved network performance and flexibility. Some of these features include:
- Layer 3 routing: The switch supports IPv4 and IPv6 routing protocols such as Routing Information Protocol (RIP), Open Shortest Path First (OSPF), and Enhanced Interior Gateway Routing Protocol (EIGRP) which allows for routing packets between VLANs and different networks.
- Virtual LANs (VLANs): The switch supports VLANs, which allows for segmenting a physical network into multiple logical networks. This improves the security and organization of a network.
- Link Aggregation Control Protocol (LACP): The switch supports LACP, which allows for bundling multiple physical ports into a single logical link. This increases bandwidth and provides redundancy in case of a port failure.
- Quality of Service (QoS): The switch supports QoS which allows for prioritizing different types of traffic to ensure that critical applications receive the bandwidth they need.
- Access Control Lists (ACLs): The switch supports ACLs which allow for filtering of inbound and outbound traffic based on specified criteria. This improves security by blocking unwanted traffic and allowing only authorized traffic to pass through the network.
- Multi-Protocol Label Switching (MPLS): The switch supports MPLS, which allows for efficient routing of data packets by using labels instead of traditional IP addresses and routing tables.
- Advanced Security: The switch supports various security features such as Cisco TrustSec and Cisco Identity Services Engine (ISE) for advanced network access control and security management.
These advanced routing and switching capabilities of the WS-C3560X-24T-S Cisco Catalyst 3560-X series switch provide network administrators with the flexibility and control they need to optimize network performance and security.
Security FeaturesAccess Control Lists (ACLs)
Access control lists can be configured to control traffic flow based on defined rules. This enhances network security by restricting access to specific resources and preventing unauthorized communication.
Port Security
Port security features enable administrators to control the number of devices connected to individual ports. This prevents unauthorized devices from gaining access to the network and helps mitigate security risks.
802.1X Authentication
802.1X authentication enhances network security by requiring devices to authenticate before being granted access. This is especially critical in environments where stringent security measures are necessary, such as corporate networks or government institutions.
Secure Shell (SSH) and Secure Sockets Layer (SSL)
Secure communication is ensured through the implementation of SSH and SSL protocols. These encryption protocols protect against unauthorized access and eavesdropping, securing sensitive data transmitted to and from the switch.
Quality of Service (QoS) Capabilities
The WS-C3560X-24T-S Cisco Catalyst 3560-X series switch supports a variety of Quality of Service (QoS) capabilities that allow network administrators to prioritize different types of traffic to ensure that critical applications receive the bandwidth they need. Some of the QoS capabilities of the WS-C3560X-24T-S include:
- Class-Based Weighted Fair Queuing (CBWFQ): This feature allows for prioritizing traffic based on class, ensuring that critical traffic is sent before less important traffic.
- Low Latency Queuing (LLQ): This feature allows for prioritizing delay-sensitive traffic such as voice and video, ensuring that these types of traffic are sent with minimal delay.
- Weighted Random Early Detection (WRED): This feature allows for controlling congestion by randomly dropping less important traffic when the switch’s buffer is full.
- Traffic shaping and policing: This feature allows for controlling the rate at which traffic is sent and received, ensuring that the switch does not become overwhelmed with traffic.
- Multi-Field Classifier (MFC): This feature allows for creating complex policies based on multiple match conditions such as IP address, protocol, and port number.
- Queue Management: The switch supports different types of queue management such as priority queue, custom queue, and weighted round-robin queue.
These QoS capabilities of the WS-C3560X-24T-S Cisco Catalyst 3560-X series switch provide network administrators with the tools they need to ensure that critical traffic is sent before less important traffic, reducing the chances of congestion and ensuring that delay-sensitive traffic is sent with minimal delay.
General Information for the Cisco WS-C3560X-24T-S Ethernet Switch
- Manufacturer: Cisco
- Part Number or SKU# WS-C3560X-24T-S
- Product Line Catalyst
- Product Series 3560-X
- Product Type: Ethernet Switch
Technical Information
- Total Number of Network Ports: 24
- USB: Yes
- Number of Network (RJ-45) Ports: 24
- Port/Expansion Slot Details: 24 x Gigabit Ethernet Network
Performance
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 10/100/1000Base-T
I/O Expansions
- Number of Total Expansion Slots: 2
Network & Communication
- Layer Supported: 2
Memory
- Standard Memory: 256 MB
- Memory Technology: DRAM
- Flash Memory: 128 MB
Power Description
- Input Voltage: 110 V AC, 220 V AC
- Power Source: Power Supply
- Redundant Power Supply: Yes
In general, the Cisco WS-C3560X-24T-S Catalyst 3560-X Series switch is a powerful and versatile networking solution that caters to the diverse needs of modern enterprises. Its combination of high-speed ports, Layer 3 capabilities, and advanced security features positions it as a reliable choice for organizations looking to build a scalable and secure network infrastructure. Whether deployed in enterprise networks, data centers, educational institutions, or telecommunication networks, this switch provides the performance, flexibility, and manageability required to meet the demands of today’s dynamic digital landscape.
