Description
Installation and Configuration of 544-BBCN
The installation and configuration process for the Dell 544-BBCN Emulex LPM32002 32GB Dual-Port FC Mezzanine Card for PowerEdge MX740C involves the following steps:
- Install the card in the mezzanine slot of the PowerEdge MX740C server.
- Connect the appropriate cables to the card’s ports.
- Power on the server and boot into the operating system.
- Install the latest Emulex driver and firmware for the card. This can be done through the operating system’s package manager or by downloading the driver and firmware from Emulex’s website.
- Configure the card using the operating system’s device manager or the Emulex OneCommand Manager software.
- Set up the storage area network (SAN) and configure the zoning and LUN masking as necessary.
- Test the connectivity between the server and the SAN by performing read and write operations.
It is important to follow all relevant safety guidelines and instructions when installing the card and to consult the server and card documentation for more detailed instructions.
In conclusion, the installation and configuration process for the Dell 544-BBCN Emulex LPM32002 32GB Dual-Port FC Mezzanine Card is straightforward and can be done quickly and easily with the right tools and resources.
Management and Monitoring Tools for 544-BBCN
The Dell Emulex LPe32002 32GB Dual-Port FC Mezzanine Card for PowerEdge MX740C can be managed and monitored using the following tools:
- Emulex OneCommand Manager: A web-based management tool for monitoring, managing, and configuring Emulex FC HBAs.
- Dell OpenManage Server Administrator: A system management software that provides a comprehensive view of the hardware components and allows administrators to manage and monitor server components, including the Emulex FC HBA.
- Emulex LightPulse HBAnyware Utility: A command-line interface for managing and monitoring Emulex HBAs.
- Microsoft Windows Device Manager: A native Windows tool for managing and monitoring hardware devices, including the Emulex FC HBA.
It is important to ensure that the latest version of these tools is installed and used to take advantage of the latest features and bug fixes.
Operating System Compatibility
The 544-BBCN Dell Emulex LPM32002 32GB Dual-Port FC Mezzanine Card is compatible with the following operating systems:
- Microsoft Windows Server 2019, 2016, 2012 R2, 2008 R2
- VMware vSphere 6.7, 6.5, 6.0, 5.5
- Red Hat Enterprise Linux (RHEL) 8.x, 7.x, 6.x, 5.x
- SUSE Linux Enterprise Server (SLES) 15 SP1, 12 SP4, 11 SP4
- Oracle Linux 7.x, 6.x, 5.x
- CentOS 7.x, 6.x, 5.x
General Information
- Manufacturer: Dell
- MPN: 544-BBCN
- Type: Controller
- Controller Type: Mezzanine Card
- SKU: 544-BBCN
Technical Information
- Device Type: Mezzanine Card
- Ports: 32 GB Fibre Channel X 2
- Form Factor: Plug-in Card
- Data Link Protocol: 32 GB Fibre Channel
- Connectivity Technology: Wired
