Description
Product Overview for the Dell MC0GV SAS-SATA Raid Controller
In the rapidly evolving landscape of computer hardware, RAID controllers play a crucial role in ensuring data integrity, performance, and reliability. The MC0GV Dell Perc H730 is a noteworthy addition to the market, offering advanced features and capabilities. In this comprehensive guide, we will delve into the intricacies of the MC0GV Dell Perc H730 12GBPS SAS 6GBPS SATA Mini Mono Raid Controller, exploring its key features, benefits, and how it functions within a storage infrastructure.
Key Features of MC0GV Dell Perc H730
- High Performance with 12GBPS SAS and 6GBPS SATA Support: The MC0GV Dell Perc H730 boasts a high-speed data transfer rate, supporting both 12GBPS SAS (Serial Attached SCSI) and 6GBPS SATA (Serial ATA) interfaces. This ensures optimal performance and compatibility with a wide range of storage devices.
- Mini Mono Form Factor: The Mini Mono form factor of the MC0GV Dell Perc H730 is designed to fit into compact spaces, making it suitable for environments where space is a constraint. Despite its small size, it delivers powerful RAID capabilities, making it an ideal choice for various applications.
- RAID (Redundant Array of Independent Disks) Support: One of the primary functions of the MC0GV Dell Perc H730 is to manage and organize multiple drives into a RAID configuration. This enables users to achieve improved performance, data redundancy, and fault tolerance. The controller supports various RAID levels, including RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, and more, catering to different storage needs.
- Cache Memory for Enhanced Performance: To enhance data access speed and overall system performance, the MC0GV Dell Perc H730 comes equipped with cache memory. The cache acts as a buffer, storing frequently accessed data for quicker retrieval. This feature is especially beneficial in environments with high I/O (Input/Output) demands.
- Integrated Battery Backup Unit (BBU) for Data Protection: Data protection is a critical aspect of any storage solution. The integrated Battery Backup Unit (BBU) in the MC0GV Dell Perc H730 ensures that in the event of a power outage, cached data can be written to the storage media, preventing data loss and maintaining the integrity of the stored information.
- Support for Self-Encrypting Drives (SED) and Secure Data Erase: Security is a paramount concern in modern storage solutions. The MC0GV Dell Perc H730 supports Self-Encrypting Drives (SED), which provide hardware-based encryption for sensitive data. Additionally, the controller features Secure Data Erase capabilities, allowing for the secure and permanent removal of data from drives.
Benefits of MC0GV Dell Perc H730
- Improved Performance: With support for high-speed SAS and SATA interfaces, the MC0GV Dell Perc H730 significantly improves data transfer rates, leading to enhanced overall system performance. The inclusion of cache memory further contributes to faster data access.
- Data Redundancy and Fault Tolerance: The RAID capabilities of the MC0GV Dell Perc H730 ensure data redundancy and fault tolerance, reducing the risk of data loss due to drive failures. This is particularly critical in enterprise environments where uninterrupted access to data is essential.
- Space-Efficient Design: The Mini Mono form factor of the MC0GV Dell Perc H730 makes it suitable for environments where space is limited. This allows for more flexibility in server configurations and deployments.
- Versatility in RAID Configurations: The support for various RAID levels provides users with the flexibility to choose a configuration that aligns with their specific performance, capacity, and redundancy requirements.
- Enhanced Security Features: The inclusion of Self-Encrypting Drives (SED) support and Secure Data Erase feature ensures that sensitive data is protected and can be securely wiped when necessary, meeting the security needs of modern IT environments.
RAID Levels Supported
The PERC H730 controller supports the following RAID levels:
- RAID 0 (Striping): Provides improved performance by spreading data across multiple drives, but does not provide any redundancy.
- RAID 1 (Mirroring): Provides data redundancy by creating an exact copy (or mirror) of data on two or more drives.
- RAID 5 (Parity): Provides data redundancy by distributing parity information across all drives in the array, allowing the controller to reconstruct data in the event of a single drive failure.
- RAID 6 (Double Parity): Provides data redundancy by distributing double parity information across all drives in the array, allowing the controller to reconstruct data in the event of two drive failures.
- RAID 10 (Striping and Mirroring): Provides both improved performance and data redundancy by combining RAID 0 and RAID 1.
- RAID 50 (Striping and Parity): Provides data redundancy and improved performance by combining RAID 5 and RAID 0.
- RAID 60 (Striping and Double Parity): Provides data redundancy and improved performance by combining RAID 6 and RAID 0.
It’s worth mentioning that RAID-level support for MC0GV is an optional feature that needs to be added to the controller to support this RAID level.
Performance and Scalability
The PERC H730 controller with the MC0GV option provides both high performance and scalability.
- The 1GB of cache memory on the controller can help to improve the performance of the storage system by storing frequently accessed data for quick retrieval. This can help to reduce the amount of time it takes to access data, which can help to improve the overall performance of the system.
- The controller also supports a variety of RAID levels, which can be configured to meet the specific performance requirements of your application. For example, RAID 0 provides improved performance by stripping data across multiple drives, while RAID 10 provides both improved performance and data redundancy by combining RAID 0 and RAID 1.
- The controller can support up to 30 physical drives with a single controller, providing a large amount of storage capacity. This allows you to scale up the storage capacity of your system as needed without having to replace the controller.
- The controller also supports both SAS and SATA drives, which provides flexibility in terms of drive type and cost. This allows you to choose the drive type that best meets the needs of your application in terms of performance and cost.
- The advanced data protection features such as online capacity expansion, online RAID level migration, and automatic data recovery allow you to easily make changes to the RAID configuration without having to take the system offline, making the scalability process more seamless.
The PERC H730 controller with the MC0GV option provides high performance and scalability by providing a large amount of storage capacity, supporting a variety of RAID levels, and advanced data protection features, allowing for easy scaling and configuration changes.
General Information about this Dell MC0GV
- Manufacturer: Dell
- Part Number or SKU# MC0GV
- Product Type: SAS-SATA
- Product Name: Controller
Technical Specifications
- Device Type: Storage Controller (RAID) Plug-In Card
- Bus Type: PCIe 3.0 x8
- Interface: 12Gb/s SAS / 6Gb/s SATA
- Data Transfer Rate: 1.2GB/s
- Buffer Size: 1GB
- Channel Qty: 8
- Max Storage Device Qty: 255
- RAID Level: RAID 0, 1, 5, 6, 10, 50, 60
- Max Operating Temperature: 55°C
- Form Factor: Mini Mono
Finally, the MC0GV Dell Perc H730 12GBPS SAS 6GBPS SATA Mini Mono Raid Controller stands out as a reliable and versatile solution for managing storage in a variety of environments. Its high-performance capabilities, space-efficient design, and advanced RAID features make it a valuable component in modern server configurations. By understanding its key features, benefits, and proper installation and configuration procedures, users can harness the full potential of the MC0GV Dell Perc H730 for their storage needs. Whether in enterprise data centers or smaller business environments, this RAID controller plays a pivotal role in ensuring data integrity, performance, and security.
