Description
Introduction to the Fujitsu SCSI Hard Drive
MAW3300NC is a high-end enterprise hard disk drive (HDD) designed for data-intensive applications that require high-speed access and reliability. This HDD is manufactured by Fujitsu, a leading Japanese electronics company. The MAW3300NC offers a storage capacity of 300 gigabytes (GB) with a rotational speed of 10000 revolutions per minute (RPM) and an 8 megabytes (MB) buffer. It is designed to fit into a small form factor (3.5 inches) with an Ultra 320 80 Pin Small Computer System Interface (SCSI) interface, making it suitable for use in small and large-scale enterprises. In this article, we will delve into the features and capabilities of the MAW3300NC HDD.
300GB Storage Capacity
The MAW3300NC offers a generous storage capacity of 300GB, making it suitable for applications that require large amounts of data storage. This capacity is adequate for storing large files, such as multimedia files, databases, and virtual machines. Enterprises that require fast access to vast amounts of data will find the MAW3300NC HDD to be an ideal solution.
10000 RPM Rotation Speed
The MAW3300NC boasts a rotational speed of 10000 RPM, which is significantly faster than typical consumer-grade hard drives. The faster rotational speed enables the drive to read and write data at a faster rate, reducing data access time and improving application performance. The high-speed performance of the MAW3300NC makes it suitable for high-demand applications, such as servers, database systems, and other data-intensive applications.
8MB Buffer & Small Form Factor
The MAW3300NC has an 8MB buffer, which acts as a temporary storage area for frequently accessed data. The buffer helps to reduce the amount of time taken to access data from the hard drive, resulting in faster application performance. The buffer also helps to reduce the wear and tear on the hard drive by reducing the number of disk reads and writes, which can prolong the lifespan of the drive.
The MAW3300NC is designed to fit into a small form factor (3.5 inches), making it suitable for use in small desktop computers, workstations, and servers. The small form factor of the drive also makes it easy to install and remove, which can be advantageous in applications where the hard drive needs to be swapped out frequently.
Ultra 320 80 Pin SCSI Interface
The MAW3300NC features an Ultra 320 80 Pin SCSI interface, which provides a high-speed data transfer rate of up to 320 MB/s. The SCSI interface is widely used in enterprise-level systems, making the MAW3300NC compatible with many server platforms. The high-speed data transfer rate of the SCSI interface also helps to improve application performance by reducing data access time.
Reliability
The MAW3300NC is designed for use in enterprise environments, where data availability and reliability are critical. The drive has a mean time between failures (MTBF) of 1.4 million hours, indicating a high level of reliability. The drive is also equipped with a number of features that enhance data reliability, such as error correction code (ECC), which helps to detect and correct data errors, and a built-in self-test (BIST), which tests the drive’s integrity before and after each use.
The MAW3300NC is a high-performance enterprise hard drive that offers a range of features and capabilities designed for data-intensive applications. With a storage capacity of 300GB, a rotational speed of 10000 RPM, and an 8MB buffer, this hard drive is suitable for use in a range of enterprise-level applications, including servers, databases, and other data-intensive applications. The drive’s small form
General Information about the Fujitsu MAW3300NC
- Manufacturer/Supplier : Fujitsu
- Manufacturer Part Number# MAW3300NC
- Product Type: Hard Disk Drive (HDD)
- HDD Type: Ultra320 SCSI
Technical Features for 300GB Hard Drive
- Form Factor : 3.5Inch x 1/3H
- Capacity : 300 GB
- Interface Type : Ultra320 SCSI
- Connector : 80 pin Centronics (SCA-2)
- Buffer Size : 8 MB
Performance of Fujitsu SCSI Hard Disk
- Drive Transfer Rate : 320 MBps (External)
- Seek Time : 4.5 ms (average) / 10 ms (MAX)
- Track-to-Track Seek Time : 0.2 MS
- Average Latency : 2.99 MS
- Spindle Speed : 10000 RPM
Expansion / Connectivity
- Interfaces : 1 x Ultra320 SCSI – 80 pin Centronics (SCA-2)
- Compatible Bays : 1 x internal – 3.5Inch x 1/3H
