Description
Overview of 507613-002 HP 2TB Hard Disk
The 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk is a high-capacity hard drive designed for use in servers and storage systems that require fast and reliable data storage. It offers a large storage capacity of 2TB and a spindle speed of 7,200 revolutions per minute (RPM). The hard drive uses the SAS interface and has a data transfer rate of up to 6Gbps. This article will provide a detailed explanation of the features, benefits, and limitations of the 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk.
Features and Specifications
The 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk is a 3.5-inch form factor hard drive that uses the SAS interface to transfer data. It has a spindle speed of 7,200 RPM and a data transfer rate of up to 6Gbps. The hard drive has a large storage capacity of 2TB and uses advanced technologies to improve performance and reliability.
The hard drive features a dual-port SAS interface that allows for redundancy and load balancing. It also has a 64MB cache buffer that helps to optimize read and write speeds. The hard drive is designed for use in midline and nearline applications and is compatible with a wide range of servers and storage systems.
Compatibility
The 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk is compatible with a wide range of servers and storage systems, including HP ProLiant servers, HP StorageWorks systems, and other systems that support the SAS interface. The hard drive is also compatible with various operating systems, including Windows, Linux, and Unix.
Benefits
The 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk offers several benefits for servers and storage systems that require high-capacity and high-performance storage. The large storage capacity of 2TB makes it an ideal choice for storing large amounts of data, including files, images, videos, and other digital content.
The hard drive’s high spindle speed of 7,200 RPM allows for fast access to data and improves overall system performance. The SAS interface provides a high data transfer rate of up to 6Gbps, which is ideal for applications that require fast data access and transfer.
The hard drive’s dual-port SAS interface allows for redundancy and load balancing, which improves reliability and performance. The 64MB cache buffer helps to optimize read and write speeds, further improving performance.
Limitations
While the 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk offers several benefits, it also has some limitations. Its high-capacity and high-performance features come at a premium price, which may be a limiting factor for some users.
Additionally, the hard drive’s large storage capacity and high spindle speed can generate more heat and noise than lower-capacity and lower-speed drives. This may be a concern for users who require a quieter and cooler environment.
Summary, the 507613-002 HP 2TB 7.2K RPM LFF SAS 6GBPS Midline Hard Disk is a high-capacity and high-performance hard drive that is ideal for servers and storage systems that require fast and reliable data storage. Its large storage capacity, high spindle speed, and advanced technologies make it a reliable and versatile option for many different applications.
Main Specifications about the HP 507613-002
- Brand: HP
- Part Number or SKU# 507613-002
- Type : Hard Drive (HDD)
- HDD-Type : 2TB 7.2K RPM SAS 6GBPS
- Option Part Number: 507616-B21
- Spare Part Number: 508010-001
- Assembly Part Number: 507613-002
- Model Number: MB2000FAMYV
Technical Information
- HDD Capacity: 2 TB
- Form Factor: 3.5 inch LFF
- Bytes per Sector: 512
- Buffer: 16 MB
- Drive Technology (Fill): Air
- Carrier Type: Standard Carrier
- Workload: Midline
- Features: Dual Port
- Bundled with: HP Standard Carrier
Performance
- Seek Time: 8.5 MS (average) / 16.2 MS (max)
- Spindle Speed: 7200 RPM
- External Data Transfer Rate: 600 MBPS
- Track-to-Track Seek Time: 0.5 MS
- Expansion & Connectivity
- Interfaces: 1 x SAS 6 GB/S
- Compatible Bay: 3.5″ LFF
Dimension and Weight
- Width : 4 Inch
- Depth : 5.8 Inch
- Height : 1 Inch
- Weight : 1.52 LBS
Environmental Parameters
- Min Operating Temperature: 50 °F
- Max Operating Temperature: 95 °F
Compatibility Information
- HP ProLiant DL Series: DL1000 DL120 (G6 G7) DL160 (G6 G7) DL160se (G6 G7) DL165 (G6 G7) DL170e (G6 G7)DL170h (G6 G7) DL180 (G6 G7) DL320 (G6 G7) DL360 (G4p G5 G6 G7) DL365 (G1 G5 G6 G7)DL370 (G6 G7) DL380 (G4 G5 G6 G7) DL385 (G1 G2 G3 G4 G5/G5p G6 G7)DL580 (G3 G4 G5 G6 G7) DL585 (G2 G3 G4 G6 G7) DL785 (G6)
- HP ProLiant ML Series: ML 110 (G7) ML350 (G5 G6 G7) ML370 (G5 G6 G7) ML570 (G3 G4 G5)
- HP Storage Systems: D2700 MSA 1040 MSA70 P2000 (G3) X1500 (G2) X16000 (G2) X1800 (G2) X3400 (G2)
- HP StoragEeasy: X3800 (G2) 2000i (G2) 2000sa (G2)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
