Description
Introduction to the HP 10GBPS Adapter
The 586444-001 HP 10GBPS PCI Express SFP+ Dual Port Network Adapter is a network card that can be installed in a computer to provide 10 gigabits per second (Gbps) of data transfer speed over a PCI Express interface. It has two Small Form-Factor Pluggable (SFP+) ports, which are used to connect to fiber-optic or copper networking cables. These ports allow for high-speed data transfer and increased bandwidth for applications such as virtualization, high-definition video streaming, and large file transfers. This network adapter is compatible with HP ProLiant servers and is designed to work with HP’s Intelligent Resilient Framework (IRF) technology, which improves network resiliency and availability.
Features and Specifications
The 586444-001 HP 10GBPS PCI Express SFP+ Dual Port Network Adapter is a high-performance network adapter that provides dual-port 10 Gbps connectivity for servers and workstations. Some of its key features and specifications include:
- SFP+ connectivity: The adapter uses Small Form-Factor Pluggable (SFP+) transceivers to provide 10 Gbps connectivity over fiber optic or copper cables.
- Dual-port design: The adapter has two ports, allowing for dual-port connectivity and failover protection.
- PCI Express interface: The adapter connects to the host computer via a PCI Express x8 interface, providing high-speed data transfer and low latency.
- Support for advanced features: The adapter supports advanced features such as Quality of Service (QoS), VLAN tagging, and jumbo frames.
- Compatible with a wide range of operating systems: The adapter is compatible with a wide range of operating systems including Windows, Linux, and VMware.
- Low-profile design: The adapter has a low-profile design, making it suitable for use in 1U and 2U servers.
- HP-branded: The adapter is an HP-branded product, providing assurance of compatibility and support with HP servers and workstations.
Some of the other technical specifications of the 586444-001 HP 10GBPS PCI Express SFP+ Dual Port Network Adapter include:
- Data transfer rate of 10 Gbps
- PCI Express x8 interface
- SFP+ connector
- Maximum power consumption of 8.5W
- Operating temperature range of 0°C to 55°C
- Operating humidity range of 10% to 90% (non-condensing)
- Compliant with IEEE 802.3ae, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3ad (LACP)
Compatible systems and operating systems
The 586444-001 HP 10GBPS PCI Express SFP+ Dual Port Network Adapter is a network card designed for use in HP servers and workstations. It is compatible with the following systems:
- HP ProLiant DL380 G6
- HP ProLiant DL380 G7
- HP ProLiant DL580 G7
- HP ProLiant DL980 G7
- HP ProLiant ML350 G6
- HP ProLiant ML370 G6
- HP ProLiant BL460c G7
- HP ProLiant BL660c G8
- HP ProLiant SL230s G8
- HP ProLiant SL250s G8
- HP ProLiant SL270s G8
- HP ProLiant WS460c G6
- HP ProLiant WS460c G8
The adapter is also compatible with the following operating systems:
- Windows Server 2008 R2
- Windows Server 2012
- Windows Server 2012 R2
- Windows Server 2016
- Windows Server 2019
- Red Hat Enterprise Linux 6
- Red Hat Enterprise Linux 7
- SUSE Linux Enterprise Server 11
- SUSE Linux Enterprise Server 12
- VMware vSphere 5.5
- VMware vSphere 6.0
- VMware vSphere 6.5
- VMware vSphere 6.7
Please note that this list may not be exhaustive and compatibility may depend on the specific version of the system or operating system being used. It is recommended to check with HP for the latest information on compatible systems and operating systems.
Detail Description
- Manufacturer: HP
- MPN: 586444-001
- Type : Networking
- Adapter-Type : Server Adapter Dual Port
- SKU: 586444-001
- Interface (Bus) Type : Pci Express 2.0 X8
- Pci Specification Revision : Pcie 2.0
- Connectivity Technology : Wired
- Data Link Protocol : 10 Gigabit Ethernet
- Features : Ipv6 Support, Tcp/Ip Offloading,
- Quality Of Service (Qos), Jumbo Frames Support
- Minor-Latin;Mso-Hansi-Theme-Font:Minor-Latin;Mso-Bidi-Font-Family:”Times New Roman”;
- IEEE 802.1q, IEEE 802.1p, IEEE 802.3x,
- IEEE 802.3ad (Lacp), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3
Dimension and Weight
- Height: 6.6inch
- Width: 2.7inch
- Weight: 2.20 Lbs
