Description
Power Consumption and Efficiency
Power consumption and efficiency are important considerations when choosing a hard disk drive such as the 614826-001 HP 3TB 7.2K RPM 3.5inch SATA-3GBPS Midline HDD. Here are some subheadings to consider when discussing these aspects:
- Power Consumption: The 614826-001 HP 3TB Midline HDD has a maximum power consumption of 6.9 watts during read/write operations, and an idle power consumption of 5.7 watts. This makes it a relatively energy-efficient option compared to some other high-capacity hard drives.
- Energy Efficiency: The 614826-001 HP 3TB Midline HDD is compliant with the European Union’s Energy-related Products (ErP) Directive, which sets minimum energy efficiency standards for products sold in the EU.
- Power Management: The hard drive supports Advanced Power Management (APM), which enables it to automatically enter low-power modes when not in use, further reducing power consumption.
- Environmental Considerations: The 614826-001 HP 3TB Midline HDD is designed to be RoHS compliant, meaning that it is free of hazardous substances such as lead and mercury.
Operating Temperature and Altitude
Operating temperature and altitude are important considerations when using the 614826-001 HP 3TB 7.2K RPM 3.5inch SATA-3GBPS Midline HDD. Here are some subheadings to consider when discussing these aspects:
- Operating Temperature: The hard drive is designed to operate within a temperature range of 0°C to 60°C (32°F to 140°F). It is important to ensure that the ambient temperature of the environment in which the hard drive is installed does not exceed these limits, as this could lead to decreased performance or even damage to the drive.
- Storage Temperature: The 614826-001 HP 3TB Midline HDD can be stored at temperatures ranging from -40°C to 70°C (-40°F to 158°F). It is important to note that these temperatures are for storage only, and the drive should not be operated outside the recommended operating temperature range.
- Altitude: The hard drive can operate at altitudes of up to 3,048 meters (10,000 feet) above sea level without any impact on performance. However, it is important to note that operating the hard drive at higher altitudes could lead to decreased performance due to lower air pressure.
Shock and Vibration Tolerance
Shock and vibration tolerance are important factors to consider when using the 614826-001 HP 3TB 7.2K RPM 3.5inch SATA-3GBPS Midline HDD. Here are some subheadings to consider when discussing these aspects:
- Shock Tolerance: The hard drive is designed to withstand shock events of up to 70G for 2ms while in operation and up to 300G for 2ms while not in operation. Shock events outside of these limits could cause damage to the drive and result in data loss.
- Vibration Tolerance: The 614826-001 HP 3TB Midline HDD is designed to withstand vibration events of up to 0.75G at 5-500 Hz while in operation and up to 3.5G at 5-500 Hz while not in operation. Vibration events outside of these limits could cause decreased performance or damage to the drive.
- Operating and Non-Operating Vibration: The hard drive has different tolerance levels for operating and non-operating vibrations. While in operation, it can withstand up to 0.25G at 5-500 Hz, while while not in operation, it can withstand up to 1.0G at 5-500 Hz.
Detail Description
- Manufacturer : HP
- MPN : 614826-001
- Type : Hard Disk Drive
- HDD -Type : SATA 3GBPS
- Option Part Number: 628059-B21
- Spare Part Number: 628180-001
- Model Number: MB3000EBKAB
- Model Number: MB3000EBUCH
- SKU : 614826-001
Key Features
- Storage Capacity : 3TB
- Form Factor: 3.5 inch
- Plug Type: Hot Plug
Dimension and Weight
- Width : 4 Inch
- Depth : 5.8 Inch
- Height : 1 Inch
- Weight : 1.52 Lbs
Compatibility Information
- ProLiant DL Series: DL1000 DL120 (G5 G6 G7) DL140 (G3) DL145 (G3) DL160 (G5 G5p G6 G7) DL160se (G6 G7) DL165 (G5 G5p G6 G7) DL170e (G6) DL170h (G6) DL2x170h (G6) DL4x170h (G6) DL180 (G5 G6 G7) DL185 (G5) DL320 (G3 G4 G5 G5p G6 G7) DL320s DL370 (G6 G7) DL380 (G4 G5 G6 G7) DL385 (G5 G5p G6 G7) DL580 (G4 G5 G6 G7) DL585 (G2 G5 G6 G7) DL785 (G5 G6)
