Description
Virtualization Technology Integration
The HPE Virtual Connect C-Class Blade System Flex-10/10D Module is designed to support virtualization technology integration. It allows multiple virtual machines to share network resources and can be easily configured to provide dedicated bandwidth to specific virtual machines or groups of virtual machines.
The module provides a flexible and scalable virtualization solution that can help organizations optimize their network resources and improve application performance. With support for industry-standard virtualization technologies such as VMware and Microsoft Hyper-V, the module can help simplify virtual machine management and reduce the need for manual configuration.
By integrating virtualization technology into the network infrastructure, the HPE Virtual Connect C-Class Blade System Flex-10/10D Module can help organizations achieve greater efficiency and flexibility in their data centers. Virtual machines can be easily migrated between physical servers, allowing organizations to quickly adapt to changing business requirements and workload demands.
In addition, the module supports network virtualization technologies such as VLAN tagging, which allows multiple virtual networks to share a single physical network interface. This can help organizations reduce the complexity and cost of managing their network infrastructure while improving network security and performance.
Scalability and Flexibility
The HPE Virtual Connect C-Class Blade System Flex-10/10D Module is designed to provide high scalability and flexibility in network configuration for data centers. The module supports virtualization technologies such as VMware, Microsoft Hyper-V, and Citrix XenServer, which allows for the creation of virtual machines (VMs) and the allocation of virtual network resources to these VMs.
With Flex-10 technology, each physical network port can be divided into multiple virtual network ports, providing up to four times the bandwidth capacity of traditional 1Gb Ethernet. This flexibility enables users to create more complex and larger virtual environments with higher performance and throughput, while also reducing the number of physical connections and network devices required.
In addition, the module supports up to 8 FlexNICs and 4 FlexHBA ports per blade server, enabling multiple network and storage configurations, and providing greater flexibility and scalability for different workloads.
Simplified Network Management
The HPE Virtual Connect C-Class Blade System Flex-10/10D Module provides simplified network management through its Virtual Connect technology. The Virtual Connect technology allows for the creation of virtual networks, called Virtual LANs (VLANs), which can be dynamically assigned to individual servers or entire blade enclosures.
This means that network administrators can manage the entire network from a single interface, without having to manually configure each individual server. They can easily create and modify VLANs, assign them to specific servers or groups of servers, and configure network settings such as Quality of Service (QoS) and bandwidth allocation.
Additionally, the HPE Virtual Connect Manager software provides a web-based interface that allows network administrators to monitor and manage the network from anywhere, using any device with an internet connection. This means that they can quickly identify and troubleshoot network issues, and make changes to the network configuration on-the-fly, without having to be physically present in the server room.
Specification
- Manufacturer: HPE
- MPN: 639852-001
- Spare Part Number: 638526-B21
- Type: Networking
- Module Type : Expansion Module 10 Ports
- SKU: 639852-001
- Form Factor : Plug-In Module
Networking
- Connectivity Technology : Wired
- Data Link Protocol : 10 Gigabit Ethernet
- Data Transfer Rate : 10 GBPS
- Mac Address Table Size : 128k Entries
- Remote Management Protocol : Snmp 1, Snmp 2, Https, Cli
Expansion / Connectivity
- Interfaces :
- 10 X Network – 10GB Ethernet – Sfp
- 1 X Management – Usb
- 16 X Network – 10GB Ethernet
- 1 X Serial – Rs-232
- Compatible Slots :
- 1 X Expansion Slot
