Description
Product Overview Of J9150-69001 HPE X132 10GbE SFP+ LC SR 10GBPS
The HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is a high-performance networking component manufactured by Hewlett Packard Enterprise (HPE). The module is designed to provide reliable and fast network connectivity between servers, switches, and storage devices in data center environments. In this article, we will discuss the features, benefits, and specifications of the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module.
Features of the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module
The HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is a hot-pluggable SFP+ transceiver that supports 10 Gigabit Ethernet (10GbE) data rates. The module has an LC duplex connector interface that supports multimode fiber (MMF) cabling. The transceiver operates over a wavelength range of 850nm and has a maximum transmission distance of up to 300 meters.
The HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is compliant with the Small Form-factor Pluggable (SFP) Multi-Source Agreement (MSA) and the IEEE 802.3ae 10GBASE-SR standard. The transceiver is also compatible with HPE networking equipment such as switches and routers that support SFP+ interfaces.
Benefits of the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module
The HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module provides several benefits for data center networking environments. Firstly, the module is hot-pluggable, which means that it can be inserted or removed from a network device without shutting down the system. This feature allows network administrators to add or replace modules without interrupting network traffic.
Secondly, the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is a high-performance component that supports 10GbE data rates. This allows for faster data transfer speeds and reduces network latency, which is essential for data-intensive applications such as cloud computing, video streaming, and big data analytics.
Thirdly, the module supports LC duplex connector interfaces that are commonly used in data center environments. The LC connector is a small form-factor connector that provides high-density fiber cabling and is ideal for connecting multiple network devices in a limited space.
Lastly, the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is compliant with industry standards such as the SFP MSA and the IEEE 802.3ae 10GBASE-SR standard. This ensures that the module is interoperable with other networking equipment from different vendors, allowing for a flexible and scalable network infrastructure.
Specifications of the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module
The HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module has the following specifications:
- Form Factor: SFP+
- Interface (Bus) Type: Plug-in module
- Connectivity Technology: Wired
- Data Link Protocol: 10 Gigabit Ethernet
- Optical Wave Length: 850 nm
- Max Transfer Distance: 300m
- Connector Type: LC Dup
In summary, the HPE J9150-69001 X132 10GbE SFP+ LC SR 10GBPS Transceiver Module is a high-performance networking component designed for data center environments. It supports 10GbE data rates, has a maximum transmission distance of up to 300 meters, and is compliant with industry standards such as the SFP MSA and the IEEE 802.3ae 10GBASE-SR standard. The module is hot-pluggable, supports LC duplex connector interfaces, and is interoperable with other networking equipment from different vendors. It provides benefits such as faster data transfer speeds, reduced network latency, high-density fiber cabling, and a flexible and scalable network infrastructure.
Main Specification about this HPE J9150-69001
- Manufacturer: HPE
- Part Number or SKU # J9150-69001
- Device Type : Transceiver Module
Networking
- Connectivity Technology : Wired
- Cabling Type : Ethernet 10gbase-Sr
- Data Link Protocol : 10 Gigabit Ethernet
- Max Transfer Distance : 1000 Ft
- Optical Wave Length : 850 Nm
- Compliant Standards : Ieee 802.3ae
Expansion / Connectivity
- Interfaces : 1 X Network – Ethernet 10gbase-Sr – Lc Multi-Mode
- Compatible Slots : 1 X Sfp+
