Description
Overview of Managed Switch
The J9626-61001 HP 2620 48 Ports L4 Managed Switch is a high-performance, enterprise-grade switch designed for use in data center, enterprise, and campus networks. It features 48 Gigabit Ethernet ports, two SFP+ ports for 10 Gigabit Ethernet connectivity, and a compact 1U form factor.
The switch is L4 (layer 4) managed, meaning it has advanced management capabilities and can support Quality of Service (QoS) features such as traffic prioritization and bandwidth control. It also has a variety of security features, including Access Control Lists (ACLs), port security, and dynamic VLAN assignment.
The switch also supports a variety of advanced features such as Virtual LANs (VLANs), Link Aggregation Control Protocol (LACP), and Spanning Tree Protocol (STP) for network redundancy. Additionally, it has a built-in web interface for easy management and monitoring.
Network Management and Configuration Options
The J9626-61001 HP 2620 48 Ports L4 Managed Switch is a high-performance network switch that offers advanced network management and configuration options for businesses and organizations. This switch is designed for use in large networks and offers a wide range of features and capabilities to help businesses manage and optimize their networks.
One of the key features of the J9626-61001 HP 2620 48 Ports L4 Managed Switch is its L4 (layer 4) network management capabilities. This allows for advanced monitoring and control of network traffic, including the ability to prioritize and shape traffic based on specific criteria such as protocol, port, or IP address.
Another important feature of this switch is its extensive configuration options. The switch can be configured through a web-based interface, which allows for easy management of the switch’s settings and features. The switch also supports SNMP (Simple Network Management Protocol) and RMON (Remote Monitoring) for remote management and monitoring of the network.
In addition, the J9626-61001 HP 2620 48 Ports L4 Managed Switch also supports VLANs (Virtual Local Area Networks) which allows for segmentation of the network into different virtual networks, providing increased security and improved network performance. The switch also supports Quality of Service (QoS) which allows for the prioritization of certain types of traffic, such as voice or video, to ensure optimal performance.
Security and Access Control
The J9626-61001 HP 2620 48 Ports L4 Managed Switch is a high-performance network switch that provides advanced security and access control features to help protect your network from unauthorized access and malicious attacks. Some of the key security and access control features include:
- Port security: This feature allows you to limit the number of MAC addresses that can be learned on a given port, preventing unauthorized devices from accessing your network.
- 802.1X authentication: This feature allows you to authenticate devices before they are allowed to access your network, using a RADIUS server for authentication.
- Access control lists (ACLs): This feature allows you to create rules that control access to your network based on various criteria, such as IP address, MAC address, and VLAN.
- VLANs: This feature allows you to segment your network into different logical groups, providing a higher level of security and isolation.
- Quality of Service (QoS): This feature allows you to prioritize different types of traffic, ensuring that mission-critical applications receive the bandwidth they need.
- SNMPv3: This feature allows you to monitor and manage your network remotely, using a secure protocol that provides encryption and authentication.
General Information about the HP J9626-61001
- Manufacturer: HP
- Part Number or SKU# J9626-61001
- Sub-Type: Switch 48 Ports
- Device Type : Switch – 48 Ports – L4 – Managed
Technical Information
- Enclosure Type : Rack-Mountable – 1u
- Ports : 48 X 10/100 + 2 X 10/100/1000 + 2 X Sfp
- Performance : Routing/Switching Capacity : 17.6 Gbps Throughput : Up To 13 Mpps
- Mac Address Table Size : 16000 Entries
- Jumbo Frame Support : 9220
- Routing Protocol : Rip-1, Rip-2, Igmpv3, Mldv2, Mld
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Http, Https, Tftp, Smon, Cli
- Encryption Algorithm : Ssl
- Authentication Method : Radius, Tacacs+, Secure Shell V.2 (Ssh2)
Performance
- Features : Flow Control, Auto-Sensing Per Device, Dhcp Support, Arp Support, Vlan Support, Auto-Uplink (Auto Mdi/Mdi-X), Igmp Snooping, Port Mirroring, Ipv6 Support, Half Duplex Mode, Full Duplex Mode, Sflow, Multiple Spanning Tree Protocol (Mstp) Support, Access Control List (Acl) Support, Quality Of Service (Qos), Jumbo Frames Support, Mld Snooping, Stp Root Guard, Lldp Support, Mac Address Lockout, Dynamic Arp Protection, Dhcp Protection, Per-Port Broadcast Throttling
- Compliant Standards : Ieee 802.3u, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1v, Ieee 802.1ab (Lldp)
- Processor : 1 X Freescale Mpc8313 : 400 Mhz
- Ram : 512 Mb – Sdram
- Flash Memory : 512 Mb
