Description
Key Features and Benefits of the HPE 491505-001 Proliant DL380
The HPE 491505-001 Proliant DL380 G6 8SFF -1p Intel Xeon Quad-core 2 GHz 1x 460w Ps 2-way 2u Rack Server is a powerful server that is designed to meet the growing demands of businesses. Here are some of the key features and benefits of this server:
- Powerful Processor: The server is powered by a powerful Intel Xeon Quad-core 2 GHz processor, which provides high performance and reliability.
- Large Memory Capacity: The server can support up to 144 GB of DDR3 memory, which can be expanded to 192 GB with the use of registered memory. This makes it an ideal choice for businesses that require high memory capacity to handle large amounts of data.
- Scalability: The HPE 491505-001 Proliant DL380 G6 server is highly scalable and can be easily expanded to meet the growing needs of a business. With support for up to 8 small form factor (SFF) hard drives, businesses can add more storage capacity as needed.
- RAID Support: The integrated Smart Array P410i RAID controller with 256MB cache provides hardware RAID support for RAID 0, 1, 10, 5, 6, and 50. This ensures data protection and enhances data reliability.
- Connectivity Options: The server comes with four Gigabit Ethernet ports, two USB 2.0 ports, and one serial port, which allows for easy connectivity and integration with other devices.
- Remote Management: The server comes with an integrated Lights-Out 2 (iLO 2) remote management card, which allows for remote access and management of the server. This feature is especially useful for businesses that have remote employees or multiple locations.
- Energy Efficiency: The server comes with a 1x 460w Ps power supply, which makes it energy-efficient and reduces the overall cost of ownership.
- High Availability: The HPE 491505-001 Proliant DL380 G6 server is designed for high availability and comes with two hot-swappable power supplies and eight hot-swappable SFF hard drive bays. This ensures that the server stays up and running even in the event of a hardware failure.
- Operating System Compatibility: The server supports a wide range of operating systems, including Windows, Linux, and VMware, making it easy to integrate with existing IT infrastructure.
RAID Controller of HPE 491505-001 Proliant DL380 G6 Server
The HPE 491505-001 Proliant DL380 G6 server comes with an integrated Smart Array P410i RAID controller. This RAID controller offers hardware RAID support for RAID 0, 1, 10, 5, 6, and 50.
RAID, or Redundant Array of Independent Disks, is a technology that allows multiple hard drives to be configured in a way that provides data redundancy, improved performance, or both. RAID 0, also known as striping, splits data across multiple disks to improve performance, but provides no data redundancy. RAID 1, also known as mirroring, duplicates data across two disks to provide data redundancy, but offers no performance improvement.
RAID 10, also known as RAID 1+0, combines both striping and mirroring to provide both improved performance and data redundancy. RAID 5, on the other hand, distributes parity data across multiple disks to provide data redundancy and improved performance, but with higher disk utilization. RAID 6 is similar to RAID 5, but with two parity disks instead of one, providing greater data redundancy.
The HPE Smart Array P410i RAID controller provides hardware-based RAID support, which offloads RAID processing from the server’s CPU to improve performance. It also comes with a 256MB cache, which helps improve performance by reducing the number of disk accesses required to retrieve data.
The RAID controller also supports hot-swappable drives, which means that failed disks can be replaced without shutting down the server. This helps to reduce downtime and ensure that the server stays up and running.
Operating System Compatibility of HPE 491505-001
The HPE 491505-001 Proliant DL380 G6 server supports a wide range of operating systems, including:
- Microsoft Windows Server – This server is compatible with various versions of Windows Server, including Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, and Windows Server 2019.
- Red Hat Enterprise Linux (RHEL) – The server supports various versions of RHEL, including RHEL 5, RHEL 6, and RHEL 7.
- SUSE Linux Enterprise Server (SLES) – The server is compatible with SLES 10, SLES 11, and SLES 12.
- VMware – The server is certified to work with VMware ESX and ESXi versions 4.0, 4.1, 5.0, 5.1, 5.5, 6.0, 6.5, and 6.7.
- Oracle Linux – The server supports Oracle Linux 5, 6, and 7.
- Citrix XenServer – The server is compatible with Citrix XenServer versions 5.5, 5.6, 6.0, 6.1, 6.2, and 6.5.
- Ubuntu – The server is compatible with Ubuntu 14.04 and 16.04 LTS.
It is important to note that some operating systems may require additional drivers or firmware updates to work with the HPE 491505-001 Proliant DL380 G6 server. Therefore, it is recommended to consult the HPE website or the operating system vendor for the latest compatibility information and driver downloads.
General Information About this HPE 491505-001
- Manufacturer Part Number: 491505-001
- Brand Name: HPE
- Product Type: Server
- Server Type: Proliant DL380
Processor & Chipset of Intel Xeon Quad-core 2 GHz
- Number of Processors Supported 2
- Number of Processors Installed 1
- Processor Manufacturer Intel
- Processor Type Xeon
- Processor Model E5504
- Processor Core Quad-core (4 Core)
- Processor Speed 2.00 GHz
Memory for Proliant DL380 8SFF Server
- Standard Memory 4 GB
- Maximum Memory 144 GB
- Memory Technology DDR3 SDRAM
- Number of Total Memory Slots 18
Storage of HPE Rack Server
- Optical Drive Type No
- Controllers
- Controller Type Serial Attached SCSI (SAS)
- RAID Supported Yes
- RAID Levels 0, 1, 10
Display & Graphics
- Graphics Controller Manufacturer ATI
- Graphics Controller Model ES1000
- Graphics Memory Capacity Up to 32 MB
- Network & Communication
- Ethernet Technology Gigabit Ethernet
- Power Description
- Input Voltage 110 V AC
- 220 V AC
- Number of Power Supplies Installed 1
- Maximum Power Supply Wattage 460 W
Miscellaneous
- Environmentally Friendly Yes
- Environmental Certification WEEE
Weight & Dimension
- Form Factor Rack
- Rack Height 2U
- Height 3.4 Inch
- Width 17.5 Inch
- Depth 27.3 Inch
