Description
Enhanced Security Features of 4 Ports Quad Card
The 539931-001 HPE PCI Express Quad 4 Port Gigabit Network Card does not have any specific enhanced security features. It is a standard Ethernet card that provides high-speed network connectivity for server and workstation applications. It supports standard network protocols such as TCP/IP and is compliant with IEEE 802.3ab standards. It does not have any built-in security features such as encryption, firewalls, or VPN support. To enhance the security of your network, you will need to implement additional security measures such as a firewall or VPN software on your server or workstation.
Performance and Speed for Quad Card
The HPE 4 Port Gigabit Network PCI Express Quad Card (539931-001) is designed to provide high-performance and fast network connectivity for servers and workstations. It uses PCI Express x4 interface to provide a high-bandwidth connection to the motherboard, allowing for data transfer rates of up to 1000Mbps (1Gbps) per port.
The card is equipped with four Gigabit Ethernet ports, which support full-duplex operation and jumbo frames up to 9KB. This allows for efficient transfer of large files and video streams, as well as improved network performance in virtualized environments.
In terms of speed, the card is capable of achieving full-duplex data transfer rates of up to 2000Mbps (2Gbps) on each port, providing a total aggregate throughput of 8000Mbps (8Gbps) when all four ports are utilized.
Security Features of the HPE PCI Express Network Card
The HPE PCI Express Quad 4 Port Gigabit Network Card does not have any specific security features built-in. However, it does support standard network security protocols such as TCP/IP, SSL, SSH and so on. These protocols can be used to secure the network and protect against common threats such as hacking and data breaches. Additionally, the network card can be used in conjunction with other security measures, such as firewalls and intrusion detection/prevention systems, to provide multiple layers of protection for your network.
Detail Description
- Manufacturer: HP
- MPN: 539931-001
- Type: Networking
- NIC -Type: 4 Ports
- SKU: 539931-001
Networking
- Connectivity Technology : Wired
- Cabling Type : Ethernet 10base-T, Ethernet 100base-Tx, Ethernet 1000base-T
- Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
- Data Transfer Rate : 1 Gbps
- Features : Flow Control, Vlan Support, Tcp/Ip Offloading, Quality Of Service (Qos), Jumbo Frames Support
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp)
Expansion / Connectivity
- Interfaces : 4 X Network – Ethernet 10base-T/100base-Tx/1000base-T – Rj-45
- Compatible Slots : 1 X Pci Express 2.0 X4
Dimensions & Weight
- Width: 10.50 inch
- Depth : 8.25 inch
- Height : 1. inch
- Weight : 1 lbs
