Description
Specifications of HPE 625618-006 1TB 7.2K RPM SATA Hard Drive
The specifications of the HPE 625618-006 1TB 7.2K RPM SATA hard drive are:
- Storage capacity: 1TB
- Form factor: 3.5-inch
- Interface: SATA 3.0 Gb/s
- Rotational speed: 7,200 RPM
- Buffer size: 32 MB
- Average latency: 4.16 ms
- Maximum external transfer rate: 300 MB/s
- Average seek time: 8.5 ms (read) / 9.5 ms (write)
- Power consumption: 8.3 watts (operational), 5.6 watts (idle)
- Acoustic noise: 29 dBA (operational), 27 dBA (idle)
- Dimensions (H x W x D): 1.03″ x 4″ x 5.79″
- Weight: 1.38 lbs
- Part number: 625618-006
- Compatible with various HPE servers and storage systems, including the HPE ProLiant DL380e Gen8, DL360e Gen8, and ML350e Gen8 servers.
Compatibility with Different Systems and Servers
The HPE 625618-006 1TB 7.2K RPM SATA Hard Drive is compatible with various HPE servers and storage systems, including:
- HPE ProLiant DL360e Gen8, DL360p Gen8, DL380e Gen8, DL380p Gen8, and DL385p Gen8 servers
- HPE ProLiant ML310e Gen8, ML350e Gen8, ML350p Gen8, and ML370e Gen8 servers
- HPE ProLiant BL420c Gen8, BL460c Gen8, BL465c Gen8, and BL660c Gen8 server blades
- HPE ProLiant SL230s Gen8, SL250s Gen8, and SL270s Gen8 scalable system servers
- HPE StoreEasy 1430, 1630, and 1830 storage systems
- HPE StoreVirtual 4130, 4330, and 4730 storage systems
It is important to check the compatibility with the specific server or storage system before purchasing the hard drive.
Capacity and Performance of HPE 625618-006 1TB 7.2K RPM SATA Hard Drive
The HPE 625618-006 1TB 7.2K RPM SATA hard drive has a storage capacity of 1 terabyte, which can hold a large amount of data, including files, documents, images, videos, and more.
In terms of performance, the hard drive has a rotational speed of 7,200 RPM, which allows for faster access to data and improved performance. It also has a buffer size of 32 MB, which helps to enhance the transfer rate of data to and from the hard drive. The average seek time is 8.5 ms for reads and 9.5 ms for writes, which is relatively fast.
The maximum external transfer rate for the hard drive is 300 MB/s, which enables faster data transfer between the hard drive and other devices. The hard drive also has a low average latency of 4.16 ms, which reduces the amount of time it takes to access data. Overall, the HPE 625618-006 1TB 7.2K RPM SATA hard drive offers a good balance of capacity and performance for various server and storage applications.
Main Information For HPE 625618-006
- HPE 625618-006 1TB 7200RPM 2.5inch Small Form Factor Digitally Signed Firmware SATA-6Gbps Smart Carrier Midline Hard Disk Drive
- Manufacturer :HPE
- Model Number or SKU# 625618-006
- Device Type: Hard Drive – Hot-Swap
- Capacity: 1 TB
- Form Factor: 2.5 inch SFF
- Interface Type: SATA (Serial ATA) 6Gbps
- Logical Blocks: 1953525168
- Bytes per Sector: 512
- Drive Technology (Fill): Air
- Plug Type: Hot Pluggable
- Carrier Type: Smart Carrier (SC)
- Workload Type: Midline
- Features: Digitally Signed Firmware
- Bundled with: HPE Smart Carrier
Performance about SATA 6GBPS HDD
- Drive Transfer Rate (Maximum): 6 Gb/sec
- Single Track Seek Time: 0.70 ms
- Average Seek Time: <8.5 ms
- Full-Stroke Seek Time: 16.96 ms
- Drive Rotational Speed: 7200 RPM
Expansion & Connectivity of 7.2K RPM Hard Disk Drive
- Interfaces: 1 x SATA 6 Gb/s
- Compatible Bay: 2.5″ SFF
Product Dimensions & Weight of 2.5 inch HDD
- Height: 0.62 inch (15.60 mm)
- Width: 2.98 inch (75.70 mm)
- Depth: 4.67 inch (118.70 mm)
Compatibility of HPE 1TB 7.2K RPM
- HPE Apollo 4200 Gen9 for Google (2.5 inch)
- HPE ProLiant DL Series: DL180 Gen10 SMB (2.5 inch), DL20 Gen10 (2.5 inch), DL20 Gen10 Entry (2.5 inch), DL20 Gen10 Performance (2.5 inch), DL20 Gen10 solution (2.5 inch), DL20 Gen9 Solution (2.5 inch), DL325 Gen10 Base (2.5 inch), DL325 Gen10 Plus (2.5 inch), DL325 Gen10 Solution (2.5 inch), DL360 Gen10 Entry (2.5 inch), DL360 Gen10 Low (2.5 inch), DL360 Gen10 SMB (2.5 inch), DL360 Gen10 Solution (2.5 inch), DL380 Gen10 Entry SMB (2.5 inch), DL380 Gen10 for Cohesity DataPlatform (2.5 inch), DL380 Gen10 High Performance (2.5 inch), DL380 Gen10 Network Choice (2.5 inch), DL380 Gen10 Network Choice for SAP HANA Compute Block (2.5 inch), DL380 Gen10 SMB (2.5 inch), DL380 Gen10 SMB Networking Choice (2.5 inch), DL380 Gen10 Solution (2.5 inch), DL385 Gen10 (2.5 inch), DL385 Gen10 Base (2.5 inch), DL385 Gen10 Entry (2.5 inch), DL385 Gen10 High-Performance (2.5 inch), DL385 Gen10 Performance (2.5 inch), DL385 Gen10 Plus (2.5 inch), DL385 Gen10 Plus Entry (2.5 inch), DL385 Gen10 SMB (2.5 inch), DL385 Gen10 Solution (2.5 inch), DL388 Gen10 (2.5 inch), DL560 Gen10 Base (2.5 inch)
- HPE ProLiant ML Series: ML110 Gen10 Solution (2.5 inch), ML30 Gen10 (2.5 inch), ML30 Gen10 Entry (2.5 inch), ML30 Gen10 Performance (2.5 inch), ML30 Gen10 Solution (2.5 inch), ML30 Gen9 Entry (2.5 inch), ML30 Gen9 Solution (2.5 inch), ML350 Gen10 (2.5 inch), ML350 Gen10 Base (2.5 inch), ML350 Gen10 Entry (2.5 inch), ML350 Gen10 High Performance (2.5 inch), ML350 Gen10 Performance (2.5 inch), ML350 Gen10 Solution (2.5 inch), ML350 Gen10 Special Server (2.5 inch), ML350 Gen10 Sub-Entry (2.5 inch)
- HPE ProLiant SL Series: SL4540 Gen8 Tray 3x Node Server (2.5 inch)
- HPE Synergy 480 Gen10 Base Compute Module (2.5 inch), 480 Gen10 Entry Compute Module (2.5 inch), 480 Gen10 Performance Compute Module (2.5 inch), 480 Gen10 Premium Backplane Compute Module (2.5 inch), 480 Gen10 Standard BackPlane Compute Module (2.5 inch), 480 Gen10 w/o Drives Compute Module (2.5 inch), 660 Gen10 Base Compute Module (2.5 inch), 660 Gen10 Compute Module (2.5 inch), 660 Gen10 Entry Compute Module (2.5 inch), 660 Gen10 Performance Compute Module (2.5 inch), 660 Gen10 Premium Compute Module (2.5 inch)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system
