Product Overview
The HPE 628059-B21 is a 3 Terabytes (TB) 7200 Revolutions Per Minute (RPM) Serial Advanced Technology Attachment (SATA) 3 (GBPS) Gigabytes Per Second 3.5 Inch Large Form Factor (LFF) Midline Hard Disk Drive (HDD) designed for use in servers. This article will explain each of these technical terms in detail and explore the features and benefits of this particular hard drive.
3 Terabytes (TB) Storage Capacity:
The 3 Terabytes (TB) storage capacity of the HPE 628059-B21 hard drive means that it can store up to 3 trillion bytes of data. This is a significant amount of storage space that is ideal for use in servers that need to store a large amount of data, such as in data centers or other large-scale computing environments.
7200 Revolutions Per Minute (RPM) Speed:
The HPE 628059-B21 hard drive has a 7200 Revolutions Per Minute (RPM) speed, which means that it can read and write data at a rate of 7200 revolutions per minute. This is a relatively fast speed for a hard drive and allows for quick access to data stored on the drive.
Serial Advanced Technology Attachment (SATA) 3 (GBPS) Interface:
The HPE 628059-B21 hard drive uses a Serial Advanced Technology Attachment (SATA) 3 (GBPS) interface, which is a standard interface used for connecting hard drives to computers and other devices. SATA 3 supports data transfer speeds of up to 6 Gigabytes per second (Gbps), which is a significant improvement over previous SATA interfaces.
3.5 Inch Large Form Factor (LFF):
The 3.5 Inch Large Form Factor (LFF) of the HPE 628059-B21 hard drive refers to its physical size. A 3.5 inch hard drive is larger than a 2.5 inch hard drive, which is the other common form factor used in servers. The larger size of the 3.5 inch drive allows for more storage space and can provide better performance in some cases.
Midline Hard Disk Drive:
The HPE 628059-B21 hard drive is a midline hard disk drive, which is a type of hard drive that is designed for use in servers and other high-performance computing environments. Midline drives are typically designed to provide a balance between performance, capacity, and cost.
Tray for Server
The HPE 628059-B21 hard drive comes with a tray that is designed to fit into a server or other compatible device. The tray makes it easy to install the hard drive into the server and ensures that it is properly secured.
Features and Benefits:
The 628059-B21 is a 3TB, 7200 RPM SATA hard disk drive with a 3.5 inch large form factor (LFF) that is designed for use in servers. Some of the features and benefits of this hard disk drive include:
- Large Storage Capacity: The 3TB storage capacity of the 628059-B21 is ideal for storing large amounts of data, such as media files, databases, and virtual machines.
- High Speed: With a 7200 RPM spindle speed, this hard disk drive can read and write data quickly, making it ideal for applications that require fast data access.
- SATA 3 Interface: The 3GBPS SATA 3 interface allows for fast data transfer rates of up to 6 Gbps.
- Large Form Factor: The 3.5 inch large form factor (LFF) makes this hard disk drive compatible with many server systems.
- Midline Hard Drive: The midline designation means that this hard disk drive is designed for reliable, high-capacity storage for mid-level server applications.
- Tray Included: This hard disk drive comes with a tray for easy installation in compatible server systems.
General Information about the HPE 628059-B21
- Manufacturer Name: HPE
- Part Number or SKU# 628059-B21
- Type: Internal Hard Drive
- HDD Type: SATA-3GBPS
- Spare Part Number: 628180-001
- Model Number: MB3000EBKAB
- Model Number: MB3000EBUCH
- Assembly Part Number: 614826-001
Technical Information
- HDD Capacity: 3TB
- Form Factor: 3.5 Inch LFF
- Spindle Speed: 7200 RPM
- External Data Transfer Rate: 300 MBps
- Enclosure: Hot Swap
- Features: Native Command Queuing (NCQ)
Dimension and Weight
- Width : 4 Inch
- Depth : 5.8 Inch
- Height : 1 Inch
- Weight : 1.52 Lbs
Performance
- Seek Time: 8.1 ms (average) / 15.5 ms (max)
- Track-to-Track Seek Time: 0.5 ms
Expansion & Connectivity
- Interfaces: 1 x SATA 3 Gbps – 7 pin Serial ATA
- Compatible Bays: 3.5 inch x 1/3H
Environmental Parameters
- Min Operating Temperature: 50 °F
- Max Operating Temperature: 95 °F
Compatibility Information
- ProLiant DL Series: DL1000 DL120 (G5 G6 G7) DL140 (G3) DL145 (G3) DL160 (G5 G5p G6 G7) DL160se (G6 G7) DL165 (G5 G5p G6 G7) DL170e (G6) DL170h (G6) DL2x170h (G6) DL4x170h (G6) DL180 (G5 G6 G7) DL185 (G5) DL320 (G3 G4 G5 G5p G6 G7) DL320s DL370 (G6 G7) DL380 (G4 G5 G6 G7) DL385 (G5 G5p G6 G7) DL580 (G4 G5 G6 G7) DL585 (G2 G5 G6 G7) DL785 (G5 G6)
- ProLiant ML Series: ML110 (G7) ML150 (G5 G6 G7) ML310 (G5p) ML330 (G6) ML350 (G5 G6 G7) ML370 (G5 G6 G7)
- HPE Storage Systems: D2600 MDS600 MSA60 P4300 P4500 P4000 (G2) 60 Modular Array StoreAll 9730
- HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
